Summary of Contents for Boss 820BRGB
-
Page 2: Table Of Contents
CONTENTS Precautions........................1 Precautions & Warnings....................1 Lithium Battery Cell Warnings..................1 Drivers and Connections.....................1 Other Warnings......................1 Installation........................2 Installation Opening....................2 To Install the Car Radio....................2 Electrical Connections....................3 Control Panel Button Locations..................4 General Operation......................5 Turn Unit On/Off......................5 Adjust Volume (VOL)....................5 Adjust Menu Options (SEL)..................5 Set the Clock (CLK)....................5 Change the Source (SRC)...................6 Mute on/off........................6... -
Page 3: Precautions
PRECAUTIONS Precautions & Warnings • To reduce the risk of fire, electric shock, and interfer-ence, do not attempt to repair this unit yourself. Refer all service to a qualified technician. • Some MP3/WMA files may not be playable. • Keep the volume at a reasonable level to avoid distracted driving. High volume levels may make it difficult to concentrate on traffic and road conditions while driving. -
Page 4: Installation
INSTALLATION Installation Opening This unit can be installed in any dashboard Having an opening as shown the right figure. 103 mm 182 mm If installation angle exceeds 30 horizontal, the unit may not perform properly. To Install the Car Radio 1. -
Page 5: Electrical Connections
Electrical Connections WIRING DIAGRAM 1. Radio antenna socket 2. Front left PRE-AMP output (White) 3. Front right PRE-AMP output (Red) 4. Rear right PRE-AMP output (Red) 5. Rear left PRE-AMP output (White) 6. ISO Socket: 8PIN connector 7. ISO Socket: 4PIN connector CAUTION +12V DC... -
Page 6: Controlpanelbutton Locations
CONTROLPANELBUTTON LOCATIONS (power)/Volume knob and SEL (select/menu) button SRC (source) button 3. BAND(band) button (answer call) button 4. AMS (automatic store / preset station scan, automatic music search) button (pause/play), Preset station1 button 6. INT (intro) , Preset station 2 button 7. -
Page 7: General Operation
GENERAL OPERATION Turn Unit On/Off Press any button on the front panel or on the remote control to turn on the unit. Press and hold the power ( ) button on the front panel or briefly press the power ( ) button on the remote control to turn the unit on or off. -
Page 8: Change The Source (Src)
GENERAL OPERATION (CONT.) Change the Source (SRC) Press the button to switch between RADIO, BT(Bluetooth), USB(with USB device inserted), SD(with SD card inserted) and AUX-IN(auxiliary input) modes. Mute on/off MUTE In power on mode, briefly press the button to toggle mute on or off. The muted state will be also released when the volume knob is used. -
Page 9: Radio Operation
RADIO OPERATION Switch Between USA area and Europe area Frequency In radio mode, press the button to enter the switch state of the US(USA) and EU(europe) frequency, then rotate it to switch between US(USA) and EU(europe) frequency. The system will change the frequency setting in about 3 seconds. Change Bands (BAND) Press the BAND... -
Page 10: Usb/Sd Card Operation
USB / SD CARD OPERATION To insert USB / SD CARD To play files in a USB device, open the USB port & micro SD card slot cover, then insert a USB storage device into the USB port. Playback will begin automatically. To play files in an micro SD card, open the USB port &... -
Page 11: Auxiliary Input Operation
AUXILIARY INPUT OPERATION This car radio is equipped an external auxiliary input jack (3.5mm) on the front panel, it is compatible with audio output from an MP3 music player. If you have plugged such a player into the AUX IN jack with a audio cable. Press the button to switch to the AUX input mode, then you can listen to music from external devices. -
Page 12: Bluetooth Operation
2. When the phone finds the car audio system, the “BOSS 820BRGB” name will be displayed. 3. Choose the “BOSS 820BRGB” from the device list to pair and connect with the car audio system. Upon confirming, the BT logo will stop flashing. -
Page 13: Remote Control
REMOTE CONTROL Remove Insulating Sheet The remote control comes with an insulating sheet attached to the underside of the remote control, as illustrated on the right. The remote control will not work until the insulating sheet is removed. Replace Lithium Battery Cell 1. -
Page 14: Specifications
SPECIFICATIONS General Chassis Dimensions.............178(W) x 125(D) x 100(H) mm Power Supply Requirement ..................DC 12V Current Consumption ..................15A (max.) Maximum Power Output ..................60W x 4CH Radio USA/ Europe Frequency Range..........87.5 - 107.9 MHz (200KHz/Step) 87.5 - 108.0 MHz(50KHz/Step) Usable Sensitivity ....................30 dBu I.F. -
Page 15: Tr O U B L E S H O O T I N
TROUBLESHOOTING If you suspect something is wrong, immediately switch power off. Do not use the unit in abnormal condition, for example without sound, or with smoke or foul smell, can cause fire or electric shock. Immediately stop using it and call the store where you purchased it. Never try to repair the unit by yourself because it is dangerous to do so.
