- Page 1 AV260C Plus Color Image Scanner User's Manual (D/N 250-0171-E Rev. A) Avision Inc. 1998...
- Page 2 Avision. Material scanned by this product may be protected by governmental laws and other regulations, such as copyright laws, the customer is solely responsible for complying with all such laws and regulations.
- Page 3 Warranty The information contained in this document is subject to change without notice. Avision makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of fitness for a particular purpose. Avision shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
-
Page 4: Fcc Radio Frequency Interference Statement
FCC Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 5: Table Of Contents
Table of Contents 1. INTRODUCTION ..................... 1-1 2. SCANNER INSTALLATION ................. 2-1 2.1 P ......................2-1 RECAUTIONS 2.2 U ..................2-2 NLOCKING THE CANNER 2.3 C ................... 2-3 ONNECTING THE ABLE 2.4 D .................... 2-4 OCUMENT LACEMENT 3. SCANNER DRIVER INSTALLATION ..............3-1 3.1 A .................. -
Page 6: Introduction
1. Introduction Congratulations on your purchase of Avision AV260C Plus color image scanner. The AV260C Plus is designed in a compact size and weight to save more space possible and at the same time maintain the high quality scanning image. - Page 7 1. Power Adapter, 2. Cushion 3. Manual,Driver Kit CD. 4. D25P Cable, etc 5. Scanner 6. Carton Figure 1-1 Scanner packing...
-
Page 8: Scanner Installation
2. Scanner Installation 2.1 Precautions Keep the scanner out of direct sunlight. Direct exposure to the sun or excessive heat may cause damage to the unit. Do not install the scanner in a humid or dusty place. Be sure to use the proper AC power source. Place the scanner securely on an even, flat surface. -
Page 9: Unlocking The Scanner
Unlocking the Scanner As shown below, unlock the scanner by turning the scanner lock to the Use position. 1. “Shipping” Position 2. “Use” Position Figure 2-1 Unlocking the Scanner... -
Page 10: Connecting The Cable
Connecting the Cable Connect the power cable and signal cable as shown below. 1. Scanner 2. Power Supply 3. D25P Cable 4. PC Parallel Port 5. Printer Cable Figure 2-2 AV260C Plus scanner cable connection... -
Page 11: Document Placement
Document Placement As shown in Figure 2-3, place the document on the glass with the text facing away from you. 1. Document Cover 2. Document Pad 3. Reference Frame 4. Glass 5. Document Board 6. Document Figure 2.3 Document Placement... -
Page 12: Scanner Driver Installation
Scanner Driver Installation To run at optimum speed, the AV260C Plus color image scanner is recommended to have the following minimum requirements: * IBM compatible PC 386/486, Pentium or later; * Microsoft Windows 3.1,Windows 95, Windows NT; * One printer port available (enhanced parallel port recommended);... - Page 13 In Windows 95 or Windows NT 3. Press the Start button, choose RUN, type d:\driver\AV260CP.exe (d: the CD-ROM drive in use), and then click O.K. (See Figure 3-1,3-2) 4. Follow the on-screen instructions to complete the installation. Fig. 3.1 Fig. 3.2...
-
Page 14: Uninstall The Scanner
Uninstall the Scanner You can uninstall the scanner by selecting Start>Programs>Avision Scanner AV260C Plus and double clicking the Uninstall command from the Avision Scanner AV260C Plus . -
Page 15: Scanner Operation & Document Printing
When you have used the dialog box to select a different source, you will need to select AV260C Plus as the source again before you can reuse the Avision AV260C Plus scanner. Place the image to be scanned face down on the glass. - Page 16 AV260C Plus TWAIN user interface:...
-
Page 17: Image Type
Image Type AV260C Plus provides five image types as explain in below: Line art Error Diffusion Scanning Source Halftone Gray Color Scanning Source Two scanning sources are provided- flatbed as well as transparency. Line art Line art presents the image in black and white only and there are no intermediate shades of gray in between. - Page 18 Gray (256 levels gray scale) Gray presents a 256 shades of gray in an image. Color (Internal one billion colors) The 30 bits True Color presents 16.7 million color and give much more tonal range and details in a color image.
-
Page 19: Scanning Parameters & Image Control
Scanning Parameters & Image Control Resolution Brightness Contrast Resolution: The number of dpi (dots per inch) that AV260C Plus uses for a scan. Usually the greater the number, the higher the resolution. Yet up to a certain level, the resolution will not be visually increased but the disk space will be increased. - Page 20 Auto Level Auto Area Descreen Color Matching Reset Invert Calibration Quality Mode Speed Mode Pixel/Inch/Cm Set Gama Image Information Auto Level: Optimizes the scanned image. Auto Area: Automatically sets the whole document as the scan area, no matter what its size. Descreen: Eliminates the Moire patterns commonly found in printed matter.
- Page 21 Color Matching: Adjusts the color quality of the image to make it close to the original. This function uses default parameters to adjust the image. Reset: Resets the scanning parameters you set. Invert: The invert command reverses the brightness and the color in the image.
- Page 22 Set Gamma: Adjusts the midtone of the image yet without losing details of the lightest and the darkest areas at the same time. Image Information: Gives related information of the scanned image.
-
Page 23: Scanning
Scanning Preview: Previews your image roughly and allocates the area to be scanned. Scan: Execute the Scans action. Exit: Cancels the current job. Document Size: To designate the size of your document, just click on its icon on the margin of the preview window As shown in the figure below, in the Preview window, you can define the area to be scanned by dragging the four cursor auxiliary lines. -
Page 24: Printing
Printing Connect the printer cable as shown below. 1. Scanner 2. Power Supply 3. D25P Cable 4. PC Parallel port 5. Printer Cable Caution: 1. Be sure to power on the scanner if you want to do pass- through printing. 2. -
Page 25: Maintenance
Maintenance Clean the Document Board Glass: As shown in Figure 5-1, wipe the scanner glass with a piece of soft clean cloth to rid the glass of dust or toner particles. 1. Document Board Glass Figure 5-1 Clean the document board glass. -
Page 26: Troubleshooting
Troubleshooting If you have any operational problem, please check the following troubleshooting hints. Questions and Answers Question: Why the scanned image always comes out to be too dark? Answer: 1) Modify the Gamma setting to 1.8 for your monitor and, when printing, set Gamma to 2.2 for your printer. - Page 27 From: [MS Text Converters] MSWorksWin=Works for Windows 2.0,C:\WINDOWS\MSAPPS\TEXTCONV\worksdos.cnv, Works for Dos 2.0=Works for DOS 2.0 MSAPPS\TEXTCONV\workswin.con, wps [MS Text Converters] MSWorksWin=Works for Windows 2.0,C:\WINDOWS\MSAPPS\TEXTCONV\worksdos.cnv Works for DOS 2.0=Works for DOS 2.0, C:\WINDOWS\MSAPPS\TEXTCONV\workswin.con Question: The printer does not print the documents. Why? Answer: Pass-through printing may pose a problem for some printers.
- Page 28 Question: Why some parallel port devices and software’s keypro do not work with the AV260C Plus? Answer: The AV260C Plus can do pass-through printing all right , but the pass-through printing may not work if you connect the parallel port with devices other than printer.
-
Page 29: Technical Service
Technical Service Technical support for Avision scanner is provided at the Avision Technical Assistance Center. Before you contact us, please prepare the following information for a quick solution: Scanner serial & revision number (located on the bottom of the scanner);... - Page 30 European Area: Avision B.V. Address: De Limiet 15 4131 NR Vianen, Netherland Tel: 31-347-329901 Support: 31-347-329902 Fax: 31-347-329903 Email: wanjon@worldonline.nl Note: 1. You can find the latest driver and document in our home page located at the World Wide Web(WWW) or BBS. Our web site: http://www.avision.com...
-
Page 31: Specifications
Specifications All specifications are subject to change without notice. Model: AV260C Plus Scanner Type: Flatbed Scanner Optical Resolution: Up to 300 dpi * 600 dpi (H*V) Maximum Resolution: 9600 dpi Scanning Modes: Black & White mode Halftone mode (64-step) Error diffusion... -
Page 32: Ec Declaration Of Conformity
Manufacturer's Address: No. 20, Creation Road I, Science-Based Industrial Park, Hsin-Chu, Taiwan, R.O.C. declare that the product Model Number : AV260C Plus conforms to the following Product Specifications: Emission: EN 50081-1 (1992) EN 55022 (Class B) (Conducted Radiated) (1994) EN 60555-2 (Harmonics) (1987)
