9) CD_IN (CD IN Connector)
Connect CD-ROM or DVD-ROM audio out to the connector.
10) SUR_CEN
Please contact your nearest dealer for optional SUR_CEN cable.
Pin No.
1
1
2
3
4
Pin No.
1
2
3
2 6
4
5
5
1
6
- 21 -
Definition
CD-L
GND
GND
CD-R
Definition
SUR OUTL
SUR OUTR
GND
No Pin
CENTER_OUT
BASS_OUT
Hardware Installation
