REMOTE HANDSET
1.
STAND BY : turn unit on/off (STANDBY mode)
2 .
SKIP/SEARCH
:
skip the CD track or search within a track.
3 .
X-BASS : turn X-bass on/off
4 .
EQ : select FLAT, POP, ROCK or JAZZ sound effect
5 .
VOLUME + / - : turn volume up / down
6 .
: play or pause CD play.
7 .
AUX : turn aux mode on
8 .
PRESET STATIONS
/
: select the preset station.
9 .
MUTE : cut the sound
10. CD : turn CD mode on
11. TUNER : turn tuner mode on and select waveband
12.
: stop CD play
13. REPEAT : repeat a single track, one disc, or all discs.
14. TUNING + / - : tune radio up or down
15. MIX : play CD track randomly
16. PROG. : Memorise the CD program or radio preset station
USE OF REMOTE CONTROL
1 .
Open the Battery Compartment
2 .
Insert two AAA batteries (not supplied), make sure to match
"+" and "-" of the batteries to marks in the battery
compartment.
3 .
Close the battery compartment.
4 .
Point the remote control at the remote sensor, operate in the range of 5 meters and 60º from the front of the
remote sensor. Make sure there is no barrier between them.
Notes:
1. Batteries can last for about 6 months generally. Change the batteries if the remote control does not work.
2. If the remote control is not used for a long time, remove the batteries to prevent battery leakage.
3. Do not charge, heat open, or short-circuit the batteries. Do not throw batteries into a fire.
4. Use only the size and type of batteries specified.
5. Do not mix different types of batteries together (e.g. alkaline and carbon-zinc) or old batteries with fresh ones.
6. Weak batteries can leak and severely damage the unit.
7. Always remove batteries as soon as they become weak.
8. For the best performance it is recommended the batteries of remote control handset be replaced on a
yearly basis, or when remote control operation becomes erratic.
CONNECT THE SPEAKER
1.
Connect the right and left speaker Wire (28) to the Speaker Terminal(25),
BLACK/WHITE wire connect to RED terminal,
BLACK wire connect to BLACK terminal.
2.
For better stereo effect, place two Speakers Box(29) in a certain distance.
Note : Keep the speaker wires away from the antennas to prevent noise.
-GB- 7 -
CONNECT THE HEADPHONE
1. This unit can accept stereo headphones (not included) with a 3.5 mm plug and an impedance of 32 ohms or greater.
2. Connect your headphone to the phones jack (13) of the unit, and the speakers will cut off automatically.
POWER SUPPLY AND SET TIME
This set operates on AC 230V ~ 50Hz
1.
Insert the AC Power Cord(27) into a convenient standard outlet. "
2.
Press
STANDBY Button(18) to turn on the unit, LCD will show "
3.
Open the Control Button Cover(23).
4.
Press CLOCK button(14) once, then display become "
digital will blinks, then press
SKIP/FAST SEARCH
/ SET / MEMO Button (9) again to store your adjusted hour and minute digital will blinks. Press
/
TUNING
(10) button to adjust minute.
5.
Press PROG. / SET / MEMO Button(9) immediately to store your desired time and the LCD Display(1) will return to
"
".
6.
Press
STANDBY Button(18) to turn it to standby mode, the LCD backlight will be off and the time is displayed.
LISTENING TO THE RADIO
1.
Press
STANDBY Button(18) or direct press TUNER/BAND Button(16)to turn the unit on, the LCD Display(1) will show
"
" (already default at FM band in the unit), select waveband by pressing TUNER/BAND Button (16).
2.
Tune your radio station by press
TUNING
3.
Press and hold
TUNING
Button(10) one second, the frequency start to change, and the tuner will search up or
down at the select band and stop at the receivable station. When scanning stop, the frequency of the received station will
displayed.
4.
Adjust the volume level by pressing VOLUME
5.
Select your favorite music mode FLAT-CLASSIC-ROCK-POP by press EQ Button(11).
6.
Select the BASS BOOST "ON" or "OFF" by pressing X-BASS Button (12). And the BASS BOOST status will indicate by X-BASS
LED & show by LCD display for few seconds.
7.
To stop listening the radio, press
STANDBY Button(18). It will return to Standby mode and the time is shown.
PROGRAMMING STATIONS
This unit is capable of memorizing the location of 20 MW/FM intermix preset stations.
1.
Refer to LISTEN TO THE TUNER step 1) to 3) to tune in a radio station.
2.
Press SET / MEMO Button(9), Indicators of MEMO and the preset station number "
3.
Press SET / MEMO Button(9) again to store the tuned station into the selected preset location. The LCD Display(1) will
show "
" in FM band, if in MW band will showing "
4.
Repeat step 1 through 3 to preset other stations.
LISTENING TO THE PRESET STATIONS
1.
Press PRESET STATION
/
Button(5) repeatedly to select your desired preset number, the band and preset number
will show on the LCD Display(1), after one second the preset number will change to show the radio frequency.
FOR BEST RECEPTION :
FM : Extend and move the FM Antenna Wire (25).
If stereo broadcast received, the STEREO indicator will be displayed at LCD Display(1).
If the broadcast signal is weak, change to MONO mode by press TUNER/BAND Button(16).
MW : This unit is equipped with a built-in directional ferrite antenna, move and rotate the unit.
" shown on display(1) blinks.
".
", press PROG. / SET / MEMO button(9) the hour
/
TUNING
button(10) to adjust hour, press PROG.
Button(10). Press one time, the frequency will change one step.
/
Button(17).
" will flash.
".
-GB- 8 -
SKIP/FAST SEARCH
