Tripp Lite NetCommander B070-008-19 Specifications

Model Number: B070-008-19
NetCommander 19" VGA Console Cat5 KVM Switch - 8 Port
Description
Tripp Lite's B070-008-19 NetCommander Rackmount Console KVM switch is a cost effective and highly flexible system for controlling up to 128
computers from a single 19" display console. This console can be cascaded with Tripp Lites stand-alone B072 NetCommander series KVM switches.
Switching between attached servers can be accomplished via the On Screen Display (OSD) menu or Hotkey commands.
Utilizing Tripp Lite's B078-101-Series server interface units, KVM cabling is kept to a minimum via inexpensive Cat5/5e/6 patch cables. Servers can
be located up to 100 ft. away from the switch.
Add Remote access over IP by connecting Tripp Lite
Password feature provides additional security to prevent unauthorized access to attached computers. All rackmount hardware is included, and is
designed for easy, one person installation. Fits into any rack from 27" to 42" deep. 2-post rackmounting available using Tripp Lite's B019-000.
Compatible with all major operating systems. Constructed of heavy-duty steel housing.
System Requirements
PS/2 or USB computer / server
(1) B078-101-PS2 (PS/2) or
Compatible with all major operating systems
Package Includes
B070-008-19, 8-port Cat5 KVM 19" Console
Power Cord
Serial Firmware Upgrade Cable
KVM/Console Jumper cable
Owners manual CD
Features
8-port Cat5 KVM Switch with built-in 19" Monitor, Keyboard, and Mouse
Supports resolutions up to 1280 x 1024 (60Hz)
Connect and control up to 128 computers locally or remotely
Standard EIA 19" rackmounting
Highlights
B051-000 Remote IP Access Unit.
B078-101-USB (USB) Server Interface Unit is required for each connected computer/server
8-port Cat5 KVM Switch with built-in 19" Monitor, Keyboard, and Mouse
Expandable: Connect and control up to 128 computers
Compatible with all major operating systems
