CHAINTECH ES-676M User Manual

Intel socket 478 via p4m266a + vt8235 u-atx motherboard
Hide thumbs
Table of Contents

Advertisement

Quick Links

Enlarged version

Declaration of Conformity

ES-676M
According to 47 CFR, Parts 2 and 15 of the FCC Rules
The following designated product:
Intel Socket 478
EQUIPMENT: MAINBOARD
VIA P4M266A + VT8235
MODEL NO.: ES-676M
u-ATX Motherboard
is a Class B digital device that complies with 47 CFR Parts 2 and 15 of the FCC
Rules. Operation is subject to the following two conditions:
User's Guide
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may
cause undesired operation.
This declaration is given to the manufacturer:
CHAINTECH-EXCEL COMPUTER INC.
4427 Enterprise St. Fremont, CA 94538, U.S.A.
Version 1.0
http://www.chaintech-excel.com
Chaintech President: Simon Ho
Signature:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ES-676M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CHAINTECH ES-676M

Summary of Contents for CHAINTECH ES-676M

  • Page 1: Declaration Of Conformity

    Intel Socket 478 EQUIPMENT: MAINBOARD VIA P4M266A + VT8235 MODEL NO.: ES-676M u-ATX Motherboard is a Class B digital device that complies with 47 CFR Parts 2 and 15 of the FCC Rules. Operation is subject to the following two conditions: User’s Guide...

  • Page 2: Table Of Contents

    15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a 1-3 ES-676M Motherboard Layout................2 residential installation. This equipment generates, uses, and can radiate radio frequency energy. If this equipment is not installed and used in accordance with the manufacturer's instructions, it may cause harmful interference to radio Hardware Setup .............

  • Page 3: Chapter 1 Introduction

    Chapter 1 Chapter 1 1-3 ES-676M Motherboard Layout Introduction Chapter 1 1-1 Product Specifications Processor Page 6 Page 5 Supports Intel Celeron/Pentium 4 Socket 478 CPU Supports Intel Celeron/Pentium 4 system bus at 400/533MHz Page 6 Chipset Page 4 VIA P4M266A + VT8235...

  • Page 4: Chapter 2 Hardware Setup

    Chapter 2 Chapter 2 and if you use two or more banks, it does not matter which bank you install first. Hardware Setup Chapter 2 DRAM Specifications DIMM type: 2.5V, unbuffered 184 pin 64/128/265/512-bit DDR DRAM. If your motherboard has already been installed in your computer you may still need to Module size: Single/double-sided 64/128/256/512 Mbytes or 1GB.
  • Page 5 Chapter 2 Chapter 2 When the Soft-OFF by PWR-BTTN function is enabled, pushing the power button screen. You must also set this jumper's cap to pins 2-3 to use this function. rapidly will switch the system to Suspend mode. Any occurrence of external activities such as pressing a key on the keyboard or moving the mouse will bring the system back FAN1 / FAN2 (CPU/System Cooling Fan Connectors) to Full-On.

  • Page 6: Chapter 3 Bios Setup Program

    Chapter 3 Chapter 3 Select the type of video adapter present in your system. You can ignore this setting if you BIOS Setup Program Chapter 3 are using a VGA monitor; VGA BIOS will automatically configure this setting. Halt On Phoenix-Award BIOS ROM has a built-in setup program that allows users to modify the When the system is powered on, BIOS performs a series of diagnostic tests called POST basic system configuration.

  • Page 7: Advanced Chipset Features

    Chapter 3 Chapter 3 2. Typematic Rate (Chars/Sec) DRAM Clock/DRAM Timing The typematic rate sets the rate at which characters on the screen repeat when a key is 1. DRAM Clock pressed and held down. This selecting option allows you to control the DRAM speed. 3.

  • Page 8: Integrated Peripherals

    Chapter 3 Chapter 3 Press [Enter] to enter the sub-menu, which contains the following items for advanced Video RAM Cacheable control: Enabling this function will allows caching of the video RAM, resulting in better system 1. VIA AC97 Audio performance. However, if any programs write to this memory area, a system error may occur.

  • Page 9: Power Management Setup

    Chapter 3 Chapter 3 connect a USB device to your system. Note that if this setting is disabled, you can still the result will be the same as if you had selected Blank. This function serves as both a screen saver and a power saver. temporarily use a USB keyboard during boot up so that you can enter BIOS and enable 3.

  • Page 10: Pnp/Pci Configurations

    Chapter 3 Chapter 3 wants to gain the attention of the operating system, it signals this by causing an IRQ to CPU Clock occur. When the operating system is ready to respond to the request, it interrupts itself and It is recommended to keep the default setting for stable system operation. performs the service.

  • Page 11: Chapter 4 Driver Setup

    Chapter 4 Chapter 4 4-4 LAN Driver Setup DRIVER Setup Chapter 4 1. Click [LAN Driver] 2. Please select [OK] to complete setup. Insert the support CD that come with your motherboard into your CD-ROM driver or double-click the CD drive icon in [My computer] to open the setup screen. 4-5 USB 2.0 Driver 1.
  • Page 12 NOTE How To Contact CHAINTECH How To Contact CHAINTECH Please do not hesitate to contact us if you have any problem about our products. Any opinion will be appreciated. NOTE For Asia, Africa, Australia and Pacific Island: For America: CHAINTECH COMPUTER CO., LTD CHAINTECH AMERICA CORP.
