American Standard 9075 Specification Sheet

EVOLUTION™ 5' X 32" IA-LHO / RHO
Comfortable bathing design with form-fitted
backrest and molded-in armrests
❏ 2425VC-LHO Built-In Integral Apron
Left Hand Drain Outlet (specify color)
❏ 2425VC-RHO Built-In Integral Apron
Right Hand Drain Outlet (specify color)
• EverClean System
®
• Acrylic with fiberglass reinforcement
• Integral apron with removable access panel
• Integral three-sided, tiling/water retention flange
• 1.25 HP self-draining pump/motor
• Eight flow adjustable jets including:
- Two adjustable Comfort Jets™ Hi Flo
- Six adjustable Comfort Jets™
• Two silent air volume controls
• Side-mounted On/Off control
• Deep Soak Overflow Drain for maximum
water depth
• Complete factory installed and tested
whirlpool system
❏
2425V-LHO Built-In Integral Apron
Left Hand Drain Outlet (specify color)
❏
2425V-RHO Built-In Integral Apron
Right Hand Drain Outlet (specify color)
• Same as above without the EverClean
❏ 2425V-LHO.002 Bathing Pool
❏ 2425V-RHO.002 Bathing Pool
Nominal Dimensions:
60" x 32" x 21-1/2"
(1524 x 813 x 546mm)
Compliance Certifications -
Meets or Exceeds the Following Specifications:
• Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
American Standard whirlpools with EverClean
incorporate a patented silver-ion additive right
into the circulation piping to protect the pipes
from mold, mildew, algae and fungus that could cause
deterioration or staining of the pipes.
© 2008 AS America Inc.
EVOLUTION™ 5' X 32" IA-LHO / RHO
WHIRLPOOL AND BATHING POOL
System
®
Components Required:
❏ Bath Filler*: (specify finish)
❏ Bath Drain: 1599.205.XXX (specify color)
Custom Accessories Available:
❏ Safe-T-Heater: 9075.120
* See American Standard Faucet Selector
For color/finish availability and other faucet choices, please
see the Product Selector and Pricing Guide.
NOTE: Whirlpool Heater is designed to maintain water
temperature during operation. It will not heat cold water to
desired bathing temperature.
SEE REVERSE FOR ROUGHING-IN DIMENSIONS
®
AND PRODUCT SPECIFICATIONS
H89
HIGH GLOSS
Revised 3/06
