American Standard ANSI Z 124.1.2 Features & Dimensions

Walk-in Bath 30" x 51" Soaking Tub, Air Spa And Whirlpool

3051.110.SXX Soaking Tub
•
Acrylic with fiberglass reinforcement.
•
Free standing metal support frame with five
adjustable leveling feet
•
Easy access, powder coated aluminum door system
•
Contoured, built-in seat.
•
Built-in grab bar and textured bottom.
•
Faucet / accessory deck areas.
•
Color match cable driven drain assembly.

3051.110.WXX Whirlpool system
•
Electronic control with timer.
•
1 HP variable flow pump system.
•
12 adjustable massage jets with
•
Automatic Tub Cleaning System - Ozone.

3051.110.AXX Air Spa system
•
Electronic control with timer.
•
1 HP variable flow heater blower.
•
Multiple seat and floor air injectors.
•
Automatic purge cycle

3051.110.CXX Combo system
•
Combines Whirlpool And Air System
Nominal Dimensions
30" x 51" x 37 1/2"
Compliance Certifications
• ETL – INTERTEK SEMKO
• IAPMO - USPC
• ANSI Z 124.1.2 –for Plastic Bathtubs
• ASME A112.19.7 – Whirlpool Appliances
• ASME A112.19.15 –for Walk-in Bathtubs
• CSA B-45.5 – Canadian Plumbing Fixtures
Soaking Tub, Air Spa And Whirlpool
To Be Specified – Required:

Drain Configuration: Left (L) Or Right (R)

Color: White (W) Or Linen (L)

Faucet

Quick Drain™: 9QUD

Whirlpool Heater*: 9ILH (Whirlpool System Only)

Chromatherapy: 9CTP

Neck Rest: 9NR

Tub Extender: 9EXT (specify color)
* NOTE: The whirlpool heater is designed to
maintain water temperature during operation.
It will not heat cold water to desired bathing
temperature
SEE REVERSE FOR ROUGHING –IN
DIMENSIONS AND PRODUCT SPECIFICATIONS
30" x 51" Walk-In
High Gloss
