Summary of Contents for Caple Wi3115
- Page 1 Instruction manual for slot-in wine cabinet Model code: Wi3115 Contact Caple on 0844 800 3830 or for spare parts www.4caple.co.uk ...
-
Page 2: Important Safety Instructions
The wine cellar should be installed in a suitable place in order to avoid touching the compressor with the hand. If the supply cord is damaged it must be replaced by a Caple service agent or a similarly qualified person in order to avoid a hazard. -
Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS Before using your wine cabinet • Remove the exterior and interior packing. • Before connecting the Wine cabinet to the power source, let it stand upright for approximately 12 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation. - Page 4 OPERATING YOUR WINE CABINET AND SETTING THE TEMPERATURE CONTROL Please use the cabinet within a ambient temperature of 5-32 , if the ambient temperature is °C higher than or lower than this temperature, it will cause a temperature fluctuation in the cabinet and may prevent is reaching 5-18 °C Controls...
- Page 5 Note • If the unit is unplugged, power lost, or turned off, you must wait 3 to 5 minutes before restarting the unit. If you attempt to restart before this time delay, the Wine cabinet will not start. • When you use the Wine cabinet for the first time or restart the Wine cabinet after having been shut off for a long time, there could be a few degrees variance between the temperature you select and the one indicated on the LED readout.
- Page 6 1. When open the door 90 degree, take out 2 screws (2) from lower door axis (3), remove the door (4), then pull out the door and door axis (Fig. A). 2. Put the door (4) safety and take out the plug (12) from top of door frame, unscrew 1 screw (11) at bottom and remove the Door limit device (10), then install the Door limit device (10) at top of door frame, please use spare plug (12) to block the hole at top of door frame.
- Page 7 Installing the decorative frame Take out the decorative frame form accessories box, and fix it to both sides of the compartment with the 2 supplied screws as showing in following figure. Installation dimensions...
-
Page 8: Care And Maintenance
CARE AND MAINTENANCE Cleaning your wine cabinet • Turn off the power, unplug the appliance, and remove all items including shelves and rack. • Wash the inside surfaces with a warm water and baking soda solution. The solution should be about 2 tablespoons of baking soda to a quart of water. -
Page 9: Troubleshooting Guide
PROBLEMS WITH YOUR WINE CABINET? You can solve many common Wine cabinet problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. TROUBLESHOOTING GUIDE PROBLEM POSSIBLE CAUSE Wine cabinet does not operate. -
Page 10: Humidity Maintenance System
DEFROSTING/CONDENSATION Your wine cellar is designed with an “Auto-cycle” defrost system. When the RUN cycle is OFF, the refrigerated surface of the wine cellar (interior rear wall) defrosts automatically. The defrost water is channeled into a drain pan which is located at the back of the wine cellar next to the compressor from where it evaporates. HUMIDITY MAINTENANCE SYSTEM The wine cellar is equipped with a system for maintaining the correct level of humidity.
