CARE AND CLEANING

CLEAN THE OVEN AT REGULAR INTERVALS
Exterior:
The outside may be cleaned with mild soap and warm water, wipe clean with a damp cloth. Avoid the
use of harsh abrasive cleaners.
Door:
Wipe the door and window on both sides, the door seals and adjacent parts frequently with a damp cloth
to remove any spills or spatters. Do not use abrasive cleaner.
Control Panel
Care should be taken in cleaning the control panel. Open the oven door before cleaning to inactivate the
control panel. Wipe the panel with a cloth dampened slightly with water only.
Do not scrub or use any sort of chemical cleaners. Avoid the use of excess water.
Interior walls:
To clean the interior surfaces, wipe with a soft cloth and warm water for hygienic reasons. After use
wipe the waveguide cover in the oven with a soft damp cloth to remove any food splashes. Built-
up splashes may overheat and begin to smoke or catch fire. Do not remove the waveguide cover. DO
NOT USE A COMMERCIAL OVEN CLEANER, ABRASIVE OR HARSH CLEANERS AND SCOURING
PADS ON ANY PART OF YOUR MICROWAVE OVEN. NEVER SPRAY OVEN CLEANERS DIRECTLY
ONTO ANY PART OF YOUR OVEN.
Avoid using excess water. After cleaning the oven, ensure any water is removed with a soft cloth.
Turntable/Roller Stay:
Wash with mild soapy water and dry thoroughly.

SERVICE CALL CHECK

Please check the following before calling for service:
1. Does the display light?
2. When the door is opened, does the oven lamp come on?
3. Place one cup of water (approx. 250 ml) in a glass measure in the oven and close the door securely.
Oven lamp should go off if door is closed properly. Press the INSTANT COOK/START pad once.
A. Does the oven lamp light?
B. Does the cooling fan work?
(Put your hand over the rear ventilation openings.)
C. Does the turntable rotate?
(The turntable can rotate clockwise or counterclockwise. This is quite normal.)
D. After one minute, did an audible signal sound and COOK
indicator go off?
E. Is the water inside the oven hot?
If "NO" is the answer to any of the above questions, please check your wall socket and the fuse in your
meter box.
If both the wall socket and the fuse are functioning properly, CONTACT YOUR NEAREST SERVICE
CENTRE APPROVED BY SHARP.
NOTE: If time appearing in the display is counting down very rapidly, check Demonstration Mode.
(Please see page E-20 for detail.)

SPECIFICATIONS

AC Line Voltage
AC Power Required
Output Power
Microwave Frequency : 2450 MHz (Class B/Group 2)**
Outside Dimensions
Cavity Dimensions
Cooking Uniformity
Weight
* This measurement is based on the International Electrotechnical Commission's standardised
method for measuring output power.
** This is the classification of ISM (Industrial, Scientific and Medical) equipment described in the
International Standard CISPR11.
SHARP CORPORATION
once
: Refer to the rating plate on the back of the oven.
: 1.6 kW
: 1100 W* (IEC test procedure)
: 520 mm(W) x 302 mm(H) x 436 mm(D)
: 374 mm(W) x 227 mm(H) x 399 mm(D)
: Turntable (335 mm in diameter) system
: Approx. 17 kg
YES _______ NO _______
YES _______ NO _______
YES _______ NO _______
YES _______ NO _______
YES _______ NO _______
YES _______ NO _______
YES _______ NO _______
E – 21
