Sharp R-342 Service Manual
Microwave ovens 900w 230v 50hz
Hide thumbs
Also See for R-342:
- Operation manual (268 pages) ,
- Operation manual (158 pages) ,
- Operation manual (18 pages)
Table of Contents
Advertisement
Quick Links
CHAPTER 1. SAFTY PRECAUTIONS
CHAPTER 2. CAUTIONS
CHAPTER 3. THE HEATING PRINCIPLE OF MICRO-
WAVE
CHAPTER 4. INSTALLATIONS
CHAPTER 5. SCHEMATIC DIAGRAM
CHAPTER 6. CIRCUIT DESCRIPTION
CHAPTER 7. TOOLS AND MEASURING INSTRUMENTS
CHAPTER 8. MICROWAVE LEAAGE TEST
SERVICE MANUAL
CONTENTS
SHARP CORPORATION
MICROWAVE OVEN
MODEL
In interests of user-safety the oven should be restored to its
original condition and only parts identical to those specified
should be used.
CHAPTER 9. MEASUREMENT OF MICROWAVE
POWER OUTPUT
CHAPTER 10. TROUBLE SHOOTING PROCEDURES
CHAPTER 11.
COMMON BREAKDOWN AND MEANS OF
PREPARING
CHAPTER 12. IMPORTANT THINGS TO DO PRIOR
CRITICAL PART SERVICING
CHAPTER 13. SAFTY CHEC S AND TESTS AFTER
SERVING
CHAPTER 14.
EXPLODED VIEW
Parts List
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
R342
R-342
(W)W
R-342
(IN)W
(900W 230V 50Hz)
K
Advertisement
Table of Contents
Related Manuals for Sharp R-342
Summary of Contents for Sharp R-342
- Page 1 R342 SERVICE MANUAL MICROWAVE OVEN R-342 (W)W MODEL R-342 (IN)W (900W 230V 50Hz) In interests of user-safety the oven should be restored to its original condition and only parts identical to those specified should be used. CONTENTS CHAPTER 1. SAFTY PRECAUTIONS CHAPTER 9.
-
Page 2: Safety Precautions
SAFETY PRECAUTIONS This device is to be serviced only by properly qualified service personnel. Consult the service manual for proper service procedures to assure continued safety operation and for precautions to be taken to avoid possible exposure to excessive microwave energy. PRECAUTIONS TO BE OBSERVED BEFORE AND DURING SERVICING TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY... -
Page 3: Table Of Contents
TABLE OF CONTENTS （page） SAFETY PRECAUTIONS------------------------------------ ------Inside front cover --------------- CAUTIONS------------------------------------------------------------------------------------------------1-1 THE HEATING PRINCIPLE OF MICROWAVE--------------------------------------------------2-1 INSTALLATIONS----------------------------------------------------------------------------------------3-1 OPERATING INSTRUCTIONS----------------------------------------------------------------------4-1 SCHEMATIC DIAGRAM--------------------------------------------------------------------------4-1 CIRCUIT DESCRIPTION-------------------------------------------------------------------------4-2 SERVICE INFORMATION-----------------------------------------------------------------------------5-1 TOOLS AND MEASURING INSTRUMENTS------------------------------------------------5-1 MICROWAVE LEAKAGE TEST----------------------------------------------------------------5-2 MEASUREMENT OF MICROWAVE POWER OUTPUT---------------------------------5-3 TROUBLE SHOOTING PROCEDURES------------------------------------------------------5-4 COMMON BREAKDOWN AND MEANS OF REPAIRING-------------------------------5-8 IMPORTANT THINGS TO DO PRIOR TO CRITICAL PART SERVICING-------------------------5-9 SAFETY CHECKS AND TESTS AFTER SERVING--------------------------------------5-10... -
Page 4: Cautions
CAUTIONS Unlike other appliances, the microwave oven MICROWAVE RADIATION high-voltage and high-current equipment. Personnel should not be exposed to the Though it is free from danger in ordinary use, microwave energy which may radiate from the extreme care should be taken during repair. magnetron or other microwave generating device if it is improperly used or connection. -
Page 5: The Heating Principle Of Microwave
THE HEATING PRINCIPLE OF MICROWAVE Microwave is one kind of radio wave whose wave length is very short, frequency is very high. Therefore, it is called ultrahigh frequency electromagnetic wave. Microwave can heat food mainly result in the mutual affect of the food in the microwave field and microwave field itself. -
Page 6: Installations
INSTALLATIONS BEFORE YOU BEGIN, READ THE FOLLOWING INSTRUCTIONS COMPLETELY INSTALLING EARTHING INSTRUCTIONS 1. Empty the microwave oven and clean inside it with This microwave oven is designed to be used in a fully a soft, damp cloth. Check for damage such as earthed condition. -
Page 7: Schematic Diagram
SCHEMATIC DIAGRAM... -
Page 8: Circuit Description
CIRCUIT DESCRIPTION As the door is closed, the contact of MONITOR • 3.2 volts AC is generated from the filament winding of SWITCH opens. This switch creates the short circuit to the high voltage transformer. This 3.2 volts is applied blow fuse during operation under abnormal condition. -
Page 9: Service Information
SERVICE INFORMATION TOOLS AND MEASURING INSTRUMENTS NECESSARY TOOLS NECESSARY MEASURING Tools normally used for TV servicing are sufficient. INSTRUMENTS Standard tools are listed below. • TESTER(VOLTS-DC, AC., Ohmmeter) • Diagonal pliers • Microwave survey meter • Long nose pliers - Holaday HI-1710(A) •... - Page 10 MEASUREMENT WITH OUTER CASE NOTES WHEN MEASURING REMOVED • Do not exceed meter full scale deflection. • When you replace the magnetron, measure for • The test probe must be removed no faster than microwave energy leakage before the outer case is 1 inch/sec (2.5 cm/sec) along the shaded area, installed and after all necessary components are otherwise a false reading may result.
-
Page 11: Measurement Of Microwave Power Output
MEASUREMENT OF MICROWAVE POWER OUTPUT • Microwave power output measurement is made with • The microwave power output P in watts is the microwave oven supplied at its rated voltage and calculated operated at its maximum microwave power setting with approximately from the following formula : a load of (1000±5) g of potable water. -
Page 12: Trouble Shooting Procedures
TROUBLE SHOOTING PROCEDURES Before overhauling a microwave oven, you should judge the breakdown and the cause correctly, then you can repair it with corresponding ways. The overhauling must be proceed in order, any hasty conclusion is not recommendable, otherwise overworking would be done when repair. The microwave oven may occur compound breakdown due to all kinds of different reasons, thus, when overhaul, they all should be taken into consideration. - Page 13 Examine when the oven at operating, but the food can’t be heated Pull out the power plug, take off the outer case, discharge the capacitor, measure the resistance value of the primary winding and the secondary winding of the transformer with a multi meter (FIG.5-3 and FIG.5-4). The resistance value of the primary winding should be about 2.2 ohm, the secondary winding should be about 130 ohm, otherwise, it indicates the transformer has broken, and should be replaced by a new one.
- Page 14 FIG5.10 FIG.5-9 Ⅲ.REPAIRING METHOD OF SEVERAL BREAKDOWN Repair when there occurred large amounts microwave leakage. There are many factors, which may cause microwave leaking. Following mentioned may be the main cause of microwave leakage: (1) The door deformed, the hinge loosed or damaged that caused the door can not close tightly. (2) The door pressing cover or the embed piece damaged or come off.
- Page 15 Means of repair when the oven can heat, but the turntable glass can’t move Firstly, check whether the turntable holder is placed correctly. If it is correct, then pull out the power plug and take down the turntable combination, measure the resistance value of the turntable motor with Rx1k grade of a multi meter If it is open- circuited, it indicates the turntable motor has broken, and should be replaced by a new, same model one.
- Page 16 MOTOR TEST PROCEDURE COMPONENTS TEST PROCEDURE RESULTS Measure the resistance. Fan Motor (Ohm-meter scale:R×100) Normal:Approx. 47Ω (Wire leads removed) ∞ Abnormal: or Several Ω Measure the resistance. Turntable Motor (Ohm-meter scale:R×1000) Normal:Approx. 3.2kΩ (Wire leads removed) ∞ Abnormal: or Several Ω NOTE: A MICROWAVE LEAKGE TEST MUST ALWAYS BE PERFORMED WHEN THE UNIT IS SERVICED FOR ANY REASON.
-
Page 17: Common Breakdown And Means Of Repairing
COMMON BREAKDOWN AND MEANS OF REPAIRING PHENOMENON CAUSE REPAIRING MEANS 1. fuse broken 1. Change a new fuse. 2. The primary and secondary winding of the 2. Change transformer are short-circuited. transformer. 1.When starting 3. The earthing or the polarity of the capacitor is 3. -
Page 18: Important Things To Do Prior To Critical Part Servicing
IMPORTANT THINGS TO DO PRIOR TO CRITICAL PART SERVICING The following instructions are CRITICAL to the owner’s safety. Be sure to follow all the instructions. Contact the manufacturer of distributor if you have any question. If the oven is operative prior to servicing a Microwave Leakage Test (Microwave Emission Check) should be performed prior to servicing the oven. -
Page 19: Safety Checks And Tests After Serving
SAFETY CHECKS AND TESTS AFTER SERVING Constructional Checks If mechanical or electrical(electronic) parts have been replaced be sure to follow the following steps. Check for correct wiring, adequate mechanical decrements of parts, and firm connectors. Check for adequate grounding. Check the following items before turning the oven ON. Proper door closing, seal/choke surfaces, and hinges. -
Page 22: Replacement Parts List
When ordering replacement part(s), please use part number(s) shown in this part list. Do not use description of the part. R-342(W)W or Model: Ref No. Midea Part No. Part Name&Description Pcs/Set Remarks For R-342 models 251500100473 ASS'Y CAVITY 252100100016 252100100016 COVER WAVE GUIDE COVER WAVE GUIDE T=0 35 118*99 T=0.35 118*99... - Page 23 252200100008 COUPLER C23L PPS 262200200007 RING ROTATING ASS'Y A28L PPS 252100500013 TRAY E25L Diameter315mm W01+W02 W01+W02 After assembly ASS'Y FAN (for R-342 Models) +W03 261300800100 261300800100 GUIDE FAN GUIDE FAN C23L C23L 251300900016 C23L 261200600350 MOTOR FAN 220-240V 261503202100 GUIDE WIND A28L SGCC T=0.5...
- Page 24 REPLACEMENT PARTS LIST NOTE: When ordering replacement part(s), please use part number(s) shown in this part list. Do not use description of the part. R-342(IN)W or Model: Ref No. Midea Part No. Part Name&Description Pcs/Set Remarks 252100100016 252100100016 COVER WAVE GUIDE...
- Page 25 REPLACEMENT PARTS LIST R-342(IN)W or Model: 261400300036 FILTER NOISE FES1E 261201200030 FUSE RT1-20 H 10A 250V 263600500006 LAMP 240V 25W 261201002830 POWER CORD ASS'Y VDE 1M Black 251203301548 ASS'Y H.V FUSE 800mA 5KV 261201301200 THERMOSTAT 160/95 *V 261301301500 BRKT INTERLOCK...
