GAI-Tronics 701-305 Quick Manual

Pub. 42004-365B
G A I - T R O N I C S ® C O R P O R A T I O N
A H U B B E L L C O M P A N Y
Model 701-305
Handset/Speaker Amplifier
Confidentiality Notice
This manual is provided solely as an operational, installation, and maintenance guide and contains
sensitive business and technical information that is confidential and proprietary to GAI-Tronics.
GAI-Tronics retains all intellectual property and other rights in or to the information contained herein,
and such information may only be used in connection with the operation of your GAI-Tronics product or
system. This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any
third party.

General Information

®
The Model 701-305 Handset/Speaker Amplifier is an important component of the 700 Series Page/Party
®
system. The plug-in handset/speaker amplifier mates directly with the Page/Party Series amplifier
enclosures and is suitable for indoor or outdoor use.

Installation

CAUTION
Do not install this equipment in hazardous areas or areas other than those on the equipment
approval list in the "Specifications" section. Such installation may cause a safety hazard and
consequent injury or property damage.
WARNING
Do not disconnect equipment while circuit is energized.
The Model 701-305 Handset/Speaker Amplifier plugs directly into the enclosure. The following figure
shows installation and adjustment details. Please refer to it when you are installing and adjusting the 701
Series amplifiers.
For continued IP 66 protection, torque setting for securing the amplifier to the enclosure should be 10 to
12 in-lbs. or 1.13 to 1.36 n-m.
GAI-Tronics Corporation 400 E. Wyomissing Ave. Mohnton, PA 19540 USA
610-777-1374 800-492-1212 Fax: 610-796-5954
