GAI-Tronics 723-005 Quick Manual

Model 723-005 Page/Party
Handset/Speaker Amplifier
Confidentiality Notice
This manual is provided solely as an operational, installation, and maintenance guide and contains
sensitive business and technical information that is confidential and proprietary to GAI-Tronics. GAI-
Tronics retains all intellectual property and other rights in or to the information contained herein, and such
information may only be used in connection with the operation of your GAI-Tronics product or system.
This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any third party.

General Information

The Model 723-005 Remote Handset/Speaker Amplifier is an important component of the Page/Party
communications system and an integral part of GAI-Tronics desktop, desk-edge, and flush-mount
stations. It has been designed to be remotely mounted within an enclosure, allowing the associated
subsets to be placed on a desktop, mounted on the side of a desk, or to be flush mounted. The Model
723-005 Remote Handset/Speaker Amplifier is constructed of fabricated steel durable enough for even
the toughest industrial environments.

Installation

CAUTION
Do not install this equipment in hazardous areas. Such installation may cause a safety hazard and
consequent injury or property damage.
To install the remote handset/speaker amplifier, plug the amplifier into the appropriate enclosure and
tighten the four screws in the corners of the amplifier. See Figure 1 for the typical installation details.
