GAI-Tronics 751-005 Quick Manual

Confidentiality Notice
This manual is provided solely as an operational, installation, and maintenance guide and contains
sensitive business and technical information that is confidential and proprietary to GAI-Tronics.
GAI-Tronics retains all intellectual property and other rights in or to the information contained herein,
and such information may only be used in connection with the operation of your GAI-Tronics product or
system. This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any
third party.

General Information

The Model 751-005 Speaker Amplifier is a component of the 700 Series Page/Party
directly with the Page/Party
system speakers. The Model 751-005 is constructed of 16-gauge cold-rolled steel and is suitable for
either indoor or outdoor use.

Installation

CAUTION
Do not install this equipment in hazardous areas or areas other than those on
the equipment approval list in the "Specifications" section. Such installation may cause a safety
hazard and consequent injury or property damage.
WARNING
Do not disconnect equipment while the circuit is energized.
For continued IP 66 protection, torque setting for securing the amplifier to the enclosure should be 10 to
12 in-lbs. or 1.13 to 1.36 n-m. To install, plug the Model 751-005 Speaker Amplifier into the appropriate
enclosure, and tighten the four screws in the corners of the front panel. Refer to Figure 1 for typical
installation details.
GAI-Tronics Corporation 400 E. Wyomissing Ave. Mohnton, PA 19540 USA
V
ISIT WWW
G A I - T R O N I C S ® C O R P O R A T I O N
A H U B B E L L C O M P A N Y
Model 751-005
Speaker Amplifier
®
series enclosures and broadcasts page announcements over the Page/Party
610-777-1374 800-492-1212
. - .
GAI TRONICS COM FOR PRODUCT LITERATURE AND MANUALS
®
System. It mates
Fax: 610-796-5954
Pub. 42004-366B
®
