Icom IC-M604 Instruction Manual page 51

D D Radio power
(Appears when a COMMANDMIC™ is connected)
This item sets the Radio power function ON or OFF.
ON : The transceiver's power is controlled by the optional
command microphone. When the command micro-
phone is turned OFF, the transceiver will also be turned
OFF automatically.
OFF : The transceiver's power is not controlled by the optional
command microphone. Even if the command microphone
is turned OFF, the transceiver will continue to work.
D D Scrambler type
(Appears when a scrambler unit is installed)
When an optional scrambler unit is installed, the scrambler type
can be selected in Set mode depending on dealer setting.
D D Scrambler code
When an optional scrambler unit is installed, the scrambler
(Default: 400)
code can be set depending on dealer setting.
When the UT-112 is installed, 32 codes (1 to 32) can be se-
lected.
When the UT-98 is installed, 128 codes (0 to 127) can be se-
lected.
When UT-112 is installed
D D Favorite channel
This item sets the Favorite channel function ON or OFF.
(Default: ON)
The favorite channel is programmed by the TAG channel set-
ting (p. 15).
ON : [Y Y ]/[Z Z ] keys on the microphone select the favorite
OFF : [Y Y ]/[Z Z ] keys on the microphone select all channels in
(Default: UT-112)
(Appears when a scrambler unit is installed)
(Default: 1)
channels in the selected channel group in sequence
when pushed.
the selected channel group in sequence when pushed.
8
SET MODE
When UT-98 is installed
(Default: 0)
(Default: ON)
8
45
