ï Connector cover
Attach the connector cover when the optional speaker-micro-
phone is not used.
To attach the connector
cover:
q Insert the connector cover
into the multi-connector.
w Tighten the screw.
Multi-
connector
q
w
Connector
cover
To detach the connector
cover:
e Unscrew the screw using
a phillips screwdriver.
r Detach
the
connector
cover for the speaker-
microphone connection.
r
e
1
ACCESSORIES
1
3
