Icom IC-F4162DS Instruction Manual page 27

D Rapid charging with the BC-121N+AD-106
The optional BC-121N allows up to 6 battery packs to be
charged simultaneously. Charging period: Approx. 3 hours
(with BP-232N)
The following items are additionally required.
• Six AD-106
charger adapters
• An AC adapter (BC-157) or the DC power cable (OPC-656)
Battery
pack
AC adapter
(Purchased
separately)
DC power cable (OPC-656)
(Connect with the DC power supply;
13.8 V/at least 7 A)
(purchase separately)
Turn power OFF
Transceiver
AD-106 charger
adapters are installed
in each slot.
BATTERY CHARGING
IMPORTANT: Battery charging caution
Ensure the guide lobes on the battery pack are correctly
aligned with the guide rails inside the charger adapter.
(This illustration is described with the BC-160.)
Guide rail
4
1
2
3
4
5
6
7
8
9
Lobes
10
11
12
13
14
15
16
22
