IMPORTANT PRECAUTIONS SAVE THESE INSTRUCTIONS When using an exercise product, basic precautions should always be followed, including the following: Read all instructions before using this exercise bike. It is the responsibility of the owner to ensure that all users of this exercise bike are adequately informed of all warnings and precautions.
Page 4
WARNINg REAd ANd SAVE ALL INSTRUCTIONS BEfORE ASSEMBLINg OR USINg THIS EXERCISE BIKE. IT IS STRONgLy RECOMMENdEd TO TAKE THE fOLLOWINg SAfETy INSTRUCTIONS. • CAUTION: If you experience chest pains, nausea, dizziness or shortness of breath, stop exercising immediately and consult your physician before continuing.
Page 5
ASSEMBLy WARNINg There are several areas during the assembly process that special attention must be paid. It is very important to follow the assembly instructions correctly and to make sure all parts are firmly tightened. If the assembly instructions are not followed correctly, the exercise bike could have parts that are not tightened and will seem loose and may cause irritating noises.
RECUMBENT BIKE PRE ASSEMBLy TOOLS REqUIREd: F 13/15mm flat Wrench/Screwdriver F 5mm L-Wrench UNPACKINg F 6mm L-Wrench Unpack the product where you will be using it. Place the bike carton on a level Comfort flat surface. It is recommended that you place a protective covering on your floor. Recumbent PARTS INCLUdEd: Bike...
Page 8
STEP 1 RECUMBENT BIKE ASSEMBLy HARdWARE fOR STEP 1 : Comfort Recumbent Bike Open HARdWARE fOR STEP 1. Attach the REAR STABILIzER to the MAIN fRAME using 2 BOLTS (A), 2 fLAT WASHERS (B), 2 SPRINg WASHERS (C) and 2 NUTS (d). Attach the fRONT STABILIzER to the MAIN fRAME using 2 BOLTS (A), 2 fLAT WASHERS (B), 2 SPRINg WASHERS (C) and 2 NUTS (d).
Page 9
STEP 2 RECUMBENT BIKE ASSEMBLy HARdWARE fOR STEP 2 : Comfort Recumbent Bike Open HARdWARE fOR STEP 2. Slide WATER BOTTLE HOLdER up CONSOLE MAST and align screw holes in WATER BOTTLE HOLdER with holes in CONSOLE MAST. Attach the WATER BOTTLE HOLdER using 2 SCREWS (E).
Page 10
STEP 3 RECUMBENT BIKE ASSEMBLy HARdWARE fOR STEP 3 : Comfort Recumbent Bike Open HARdWARE fOR STEP 3. Slide CONSOLE MAST gROMMET from the bottom up the CONSOLE MAST . Attach CONSOLE CABLES and carefully tuck all cables into MAIN fRAME. Slide CONSOLE MAST into MAIN fRAME.
Page 11
STEP 4 RECUMBENT BIKE ASSEMBLy HARdWARE fOR STEP 4 : Comfort Recumbent Bike Open HARdWARE fOR STEP 4. Attach SEAT fRAME to the MAIN fRAME using 6 SOCKET HEAd CAP SCREWS (I) and 6 SPRINg WASHERS (C) as shown.
Page 12
STEP 5 RECUMBENT BIKE ASSEMBLy HARdWARE fOR STEP 5 : Comfort Recumbent Bike Open HARdWARE fOR STEP 5. Attach SEAT BASE to SEAT fRAME using 4 BOLTS (J) and 4 fLAT WASHERS (B). Attach SEAT BACK to SEAT fRAME using 4 BOLTS (J) and 4 fLAT WASHERS (B).
Page 13
STEP 6 RECUMBENT BIKE ASSEMBLy HARdWARE fOR STEP 6 : Comfort Recumbent Bike Open HARdWARE fOR STEP 6. Attach PULSE gRIP HANdLEBARS to the SEAT fRAME using 2 BOLTS (K) and 2 ARC WASHERS (H). Attach SEAT fRAME COVER to MAIN fRAME as shown.
Page 14
STEP 7 RECUMBENT BIKE ASSEMBLy HARdWARE fOR STEP 7 : Comfort Recumbent Bike HARdWARE fOR STEP 7 is pre-installed. Attach the RIgHT PEdAL to the RIgHT CRANK ARM, tightening it clockwise with the provided 13mm/15mm flat wrench. Attach the LEfT PEdAL onto the left crank arm, tightening it counter-clockwise with the provided 13mm/15mm flat wrench.
Page 15
RECUMBENT BIKE ASSEMBLy ASSEMBLy COMPLETE! Comfort Recumbent Bike Comfort Ri Overall dimension: 165 x 64 x 135 cm Net Weight: 49.5 kg / 109 lbs gross Weight: 56.5 kg / 124 lbs Max. User Weight: 136 kg / 300 lbs...
Page 17
UPRIgHT BIKE PRE ASSEMBLy TOOLS REqUIREd: F 13/15mm flat Wrench/Screwdriver F 5mm L-Wrench UNPACKINg F 6mm L-Wrench Unpack the product where you will be using it. Place the bike carton on a level Comfort flat surface. It is recommended that you place a protective covering on your floor. Upright PARTS INCLUdEd: Bike...
Page 18
2 BOLTS (A), 2 fLAT WASHERS (B), 2 SPRINg WASHERS (f) and 2 NUTS (C). Note: Lifting up the machine will help your assembly. first put in place the stabilizer and then insert the bolts will also make your assembly easier. COMfORT 3 SHOWN...
Page 19
STEP 1-2 UPRIgHT BIKE ASSEMBLy (COMfORT 8i ONLy) HARdWARE fOR STEP 1-2 : Comfort Upright Bike Open HARdWARE fOR STEP 1-2. Carefully slide the ACCESSORy TRAy to the MAIN fRAME. Attach and tighten the ACCESSORy TRAy to the MAIN fRAME using 2 SCREWS (d). COMfORT 8i SHOWN...
Page 20
SEAT POST TUBE into the MAIN fRAME. Note: While assembling the SEAT please make sure the seat is in right position. Tilt up the front of the SEAT might help you gain a more stable ridding experience. COMfORT 3 SHOWN...
Page 21
Slide WATER BOTTLE HOLdER up CONSOLE MAST and align screw holes in WATER BOTTLE HOLdER with holes in CONSOLE MAST. Attach the WATER BOTTLE HOLdER using 2 SCREWS (d). Note: Be careful not to pinch any cable while assembling. COMfORT 3 SHOWN COMfORT 3 SHOWN...
Page 22
MAIN fRAME. Slide CONSOLE MAST into MAIN fRAME. Attach the CONSOLE MAST using 2 BOLTS (g) from the sides and 4 BOLTS (E), 4 fLAT WASHERS (B) . Slide CONSOLE MAST gROMMET down over MAIN fRAME. COMfORT 3 SHOWN...
STEP 4-2 UPRIgHT BIKE ASSEMBLy (fOR COMfORT 7, 7i, 8i ONLy ) HARdWARE fOR STEP 4-2 : Comfort Upright Bike Open HARdWARE fOR STEP 4-2. Holding HANdLEBAR close to CONSOLE MAST and feed the HANdLBAR WIRES through the hole in the CONSOLE MAST and out the top of the CONSOLE MAST.
Page 24
Connect the CONSOLE CABLE and carefully tuck into the CONSOLE MAST. Attach the CONSOLE to the CONSOLE MAST using 4 PRE-INSTALLEd SCREWS. Note: you may need a 15mm wrench to assemble the pedal. Please be care not to pinch yourself when COMfORT 3 SHOWN assembling.
Page 25
Max. User Weight: 136 kg / 300 lbs Comfort 8i Overall dimension: 132 x 55 x 140 cm Net Weight: 42 kg / 92.5 lbs gross Weight: 47.5 kg / 104.5 lbs Max. User Weight: 136 kg / 300 lbs COMfORT 3 SHOWN...
BIKE OPERATION This section explains how to use your bike’s console and programming. The BASIC OPERATION section in the BIKE gUIdE has instructions for the following: • LOCATION Of THE BIKE • POWER/gROUNdINg INSTRUCTIONS • SEAT POSITIONINg • MOVINg THE BIKE •...
Page 29
COMfORT 3 CONSOLE OPERATION Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before use. LCd dISPLAy WINdOWS: Time, distance, Calories, Speed, RPM, Resistance Level, Heart Rate, Calories, Watts, HR Wheel, Workout Profile.
Page 31
COMfORT 5i CONSOLE OPERATION Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before use. LCd dISPLAy WINdOWS: Time, distance, Calories, Speed, RPM, Resistance Level, Heart Rate, Calories, Watts, HR Wheel, Profile. ENERgy SAVER: to minimize energy consumption, your machine will enter energy saver mode automatically (after entering stand-by mode for 15 mins) and cab be quickly woken up with a touch of a button.
Page 33
COMfORT 7i/8i/Ri CONSOLE OPERATION Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before use. LCd dISPLAy WINdOWS: Time, distance, Calories, Speed, RPM, Resistance Level, Heart Rate, Calories, Watts, HR Wheel, Profile. ENERgy SAVER: to minimize energy consumption, your machine will enter energy saver mode automatically (after entering stand-by mode for 15 mins) and can be quickly woken up with a touch of a button.
COMfORT 3 dISPLAyS COMfORT 5i dISPLAyS Comfort 3 Comfort 5 Comfort 5i Comfort R dISPLAy WINdOWS • TIME: Shown as minutes : seconds. View the time remaining • MAXIMUM HEART RATE: Shows your maximum heart or the time elapsed in your workout.
Page 35
COMfORT 7i dISPLAyS COMfORT 8i dISPLAyS Comfort 7 Comfort 7i Comfort 8i Comfort Ri dISPLAy WINdOWS • TIME: Shown as minutes : seconds. View the time remaining • HEART RATE WHEEL: displays your current activity zone or the time elapsed in your workout. during your workout.
TO CLEAR SELECTION/RESET gETTINg STARTEd THE CONSOLE qUICK START Hold START/STOP for 3 seconds. 1) Make sure the power is on. 2) Press START / STOP to start exercise in MANUAL mode. fINISHINg yOUR WORKOUT 3) Press to adjust resistance level during the workout. When your workout is complete, the bike will stop and beep.
PROgRAM INfORMATION Comfort 3: 10 Programs (Manual / Intervals / game / Weight Loss / Rolling / Cadence / Random / Constant Watts / THR zone / Custom) Comfort 5i: 12 Programs (Manual / Intervals / game / Weight Loss / Rolling / Cadence / Random / Constant Watts / THR zone / % THR / Custom 1 /...
Page 42
6) WEIgHT LOSS PLUS: Promotes weight loss by increasing and decreasing the resistance, while keeping you in your fat burning zone. Time based program with 15 levels to choose from and greater intensity than the weight loss program. User sets time and level using (up/down arrows) and ENTER.Please drink enough water while and after doing exercise to enhance the weight loss results.
Page 43
7) ROLLINg: Maintains weight by gradually raising and lowering the resistance level to gradually raise and lower your heart rate. ROLLINg Warm Up Program segments Cool down Seconds Segment Level 1 Level 2 Level 3 Level 4 Level 5 Level 6 Level 7 Level 8 Level 9 Level 10 Level 11 Level 12 Level 13 (Comfort 3) Level 14...
Page 44
(L), medium speed (M), or high speed (H) to help you reach your fitness goal. CAdENCE Warm up Cool down Seconds Segment Level 1 Level 2 Level 3 Level 4 Level 5 Level 6 Level 7 Level 8 Level 9 Level 10 Level 11 Level 12 Level 13 (Comfort 3) Level 14...
Page 46
9) RANdOM: Special designed chart based program that will simulate resistance being changed randomly. RANdOM Warm Up Program segments Cool down Seconds Segment Level 1 Level 2 Level 3 Level 4 Level 5 Level 6 Level 7 Level 8 Level 9 (Comfort 3) Level 10...
Page 47
RANdOM Warm Up Program segments Cool down Seconds Segment Level 1 Level 2 Level 3 Level 4 Level 5 Level 6 Level 7 Level 8 Level 9 Level 10 Level 11 Level 12 Level 13 (Comfort 5i, 7i, 8i, Ri) Level 14 10) CONSTANT WATTS: This workout automatically adjusts the resistance to keep you within a set Watts range and maintains your desired level of exercise intensity.
Page 48
11) INTERVAL WATT PROgRAM: Allows you to choose a high WATTs value and a low WATTs value. The interval program will switch between High and Low WATTs values, making for a very intense and effective workout. 1) Select Constant Watts program using and press enter. 2) Set time using and press enter .
Page 49
12) THR zONE: Simulate the intensity of your favorite sport as the program resistance automatically adjusts to maintain a set Target Heart Rate range. (Suggest to use chest belt with this program. you may purchase chest belt separately from your dealer) 1) Select THR zone program using and press ENTER.
Page 50
14) STRENgTH BUILdER: Help you gradually increase your muscle strength with a preset workout program. Time based program with 20 levels to choose from. User sets time and level using (up/down arrows) and ENTER. STRENgTH BUILdER Warm Up Program Segments - Repeat Cool down Seconds Segment...
15) CUSTOM 1 & 2: Customized workout, time defaults to 15 minutes. (Comfort 3 does not have Custom 2) 1) first enter the program setting and profile display will guide you trough all the workout column. 2) Use upper and lower arrow to change the resistance and press enter to confirm.
2) Use your media player buttons to adjust song settings. 3) Remove the AUdIO AdAPTOR CABLE when not in use. SyNCINg BIKE WITH PASSPORT (COMfORT 3 IS NOT INCLUdEd) 1) Using the arrow key on the passport remote control to scroll to the setup icon and press the Select.
ENgINEERINg MOdE: To enter the engineering menu, press and hold the for 3-5 seconds. SWITCHINg BETWEEN BRITISH ANd METRIC MOdE Use the arrow keys to navigate to Eng2 and press Enter. Use the Enter key to navigate to P0. Use the arrow keys to switch between STANdARd (BRITISH) and METRIC.
Page 67
COMfORT Ri PARTS LIST dESCRIPTION SPECIfICATIONS dESCRIPTION SPECIfICATIONS MAIN fRAME INdUCTION fLy WHEEL NCZ26540B-1(8.5KG) BEARINg 6003zz CKS HEX SCREW M6XP1.0X15, 8.8 dRIVE PULLEy Ø240X19T,6 WASHER Ø15XØ7X2.0T MAgNET Ø15X7T,1400gS SPRINg WASHER M6X1.5T TRANSMISSION SHAfT NBz18065A ( 180MM) LEfT CRANK NBz124170L,L170MM- 9/16" C-CLIP fOR Ø...
Page 68
dESCRIPTION SPECIfICATIONS dESCRIPTION SPECIfICATIONS CLIP-SHORT PCA7258A (Ø8X28.5) HANd gRIP HR SENSOR CABLE fOR fBg6703P THE HANdLEBAR REAR SUPPORT TUBE TOP COVER PCz141111 TRUSS ENd CAP for Ø31.8,1.5t BASE TUBE LEfT COVER PAz450103L CORd CAP PAR139115 BASE TUBE RIgHT COVER PAz450103R fOAM gRIP fOR Ø31.8, 2.5T LONg :490MM WITH...
Page 70
Ende der Nutzungsdauer einer sachgerechten Entsorgung zu (örtliche Sammelstelle). gB: Waste disposal Vision fitness / Horizon fitness / TEMPO fitness / TREO fitness products are recyclable. At the end if its useful life please dispose of this article correctly and safely (local refuse sites).
