DeLonghi PACT 90ECO Instructions Manual

GB-5751012500 14-04-2004
I m p o r t a n t s a f e g u a rd s
• This appliance is designed for home air conditioning and must not be used for other purposes.
• It is dangerous to modify or alter the characteristics of the appliance in any way.
• The appliance must be installed in conformity with legislation in force in the country concerned.
• If the appliance requires repair, contact a Service Centre authorised by the manufacturer only.
Repairs carried out by unauthorised personnel may be dangerous.
• If the power cable is damaged, it must be replaced by a qualified professional authorised by the
manufacturer only.
• This air conditioning unit must be used by adults only. Never allow children to play with the applian-
ce.
• The appliance must be connected to an efficient earth system. Have your electrical circuit checked
by a qualified electrician.
• Do not use extension cables.
• Before cleaning or maintenance operations, always unplug the appliance from the mains socket.
• Do not move the appliance by pulling the power cable.
• Do not install the appliance in rooms containing gas, oil or sulphur. Do not install near sources of heat.
.
• Do not rest heavy or hot objects on top of the appliance.
• Clean the anti-microbial filters at least once a week.
• Avoid using heating appliances near the air conditioning unit.
• Always transport the appliance upright or resting on one side.
Before moving the appliance, empty the internal circuit completely of water. Press the MODE (B)
and FAN (T) buttons simultaneously for a number of seconds without removing the tank (8) and then
empty the tank (8).
After moving the appliance, wait at least 1 hour before starting it
• Use the appliance as described in this instruction manual only. As with any electrical appliance,
while the instructions aim to cover as many eventualities as possible caution and common sense
should be used when operating and installing this air conditioning unit.
• At the end of its working life, take the appliance to a special collection centre.
• The materials used for packaging can be recycled. You are therefore recommended to dispose of
them in special differentiated waste collection containers.
• When putting the appliance away, do not cover with plastic bags.
• The refrigerant gases R290 and R407c conform to EC regulations on the environment. Avoid perfo-
rating the refrigerant circuit of the appliance.
• Keep the appliance at least 50 cm away from flammable substances (alcohol etc) or pressurised
containers (eg aerosol cans).
For environmentally-friendly models only (T90ECO, T100ECO)
• If the appliance is used in rooms without adequate ventilation, take the necessary precautions to
avoid possible leaks of refrigerant gas stagnating in the atmosphere, creating a fire risk.
• This appliance must be used and kept in rooms with a volume of more than 21m
• If an appliance containing flammable refrigerant is used in an unventilated room, make sure the
room is suitable and that there is no danger of gas leaks reaching a concentration which could
cause fire or explosion in the presence of other heat sources (electrical heating appliances, heaters
or similar).
DESCRIPTION
1
air outlet grille (motorised in model T100
ECO only)
2 control panel
3 castors
4 handles
5 air exhaust hose housing
6 condenser air intake grille
7 evaporator air intake grille
8 condensate tank
9 continuous condensate drain connection
10 power cable
15:59 Pagina 17
11 flange cap
12 air exhaust hose
13 window outlet
14 suckers
15 castor locks
16 continuous drain hose with coupling
17 remote control unit (model T100 ECO only)
18 3M air purifying filter accessory (model
T100 ECO only)
3 .
17
