  • Page 1 Built-In Electric Oven EOC65340...
  • Page 2 We were thinking of you when we made this product...
  • Page 3 electrolux 3 Welcome to the world of Electrolux Thank you for choosing a first class product from Electrolux, which hopefully will provide you with lots of pleasure in the future. The Electrolux ambition is to offer a wide variety of quality products that make your life more comfortable.

  • Page 4: Table Of Contents

    4 electrolux contents Contents Safety instructions Description of the Appliance Before Using for the first time Using the Oven Uses, Tables and Tips Cleaning and Care What to do if … Installation Instructions Disposal Guarantee/Customer Service Service The following symbols are used in this user manual: Important information concerning your personal safety and information on how to avoid damaging the appliance.

  • Page 5: Safety Instructions

    safety instructions electrolux 5 Safety whilst Using • People (including children) who, be- cause of their physical, sensory or mental capabilities or their inexperi- ence or ignorance are not able to use Safety instructions the device safely, should not use this device without supervision or in- struction by a responsible person.
  • Page 6 6 electrolux safety instructions How to avoid damage to the appliance • Do not line the oven with aluminium foil and do not place baking trays, pots, etc. on the oven floor, as the heat that builds up will damage the oven enamel.

  • Page 7: Description Of The Appliance

    description of the appliance electrolux 7 Description of the Appliance General Overview Control panel Light bar Door Full glass door handle...

  • Page 8: Control Panel

    8 electrolux description of the appliance Control Panel Oven Power Indicator Oven Power Indicator Temperature / Time Display Temperature / Time Selection Oven Functions Clock function buttons...

  • Page 9: Oven Features

    description of the appliance electrolux 9 Oven Features Top heat and heating elements Oven lighting Shelf positions Fat Filter Fan heating element Bottom Heat Oven shelf runners, removable Inside of door On the inside of the oven door you will find the numbers of the different oven shelves.

  • Page 10: Oven Accessories

    10 electrolux description of the appliance Oven accessories Oven shelf For cookware, cake tins, roasts and grilled foods. Baking tray For cakes and biscuits. Roasting Pan For baking and roasting or as a pan for collecting fat.

  • Page 11: Before Using For The First Time

    before using for the first time electrolux 11 Before Using for the first time Setting and changing the time The oven only operates when the time has been set. When the appliance has been connect- ed to the electrical supply or when there has been a power cut, the function indi- cator Time flashes automatically.

  • Page 12: Initial Cleaning

    12 electrolux before using for the first time Initial Cleaning Before using the oven for the first time you should clean it thoroughly. Caution: Do not use any caustic or abrasive cleaners. The surface could be damaged. To clean metal fronts use commer- cially available cleaning agents.

  • Page 13: Using The Oven

    using the oven electrolux 13 Using the Oven Switching the Oven On and Off Oven Power Indicator Temperature / Time Display Oven Power Indicator Heat indicator Pyrolyse time Selection button Oven Functions Change display Temperature / Time Selection...
  • Page 14 14 electrolux using the oven Switching the oven on Turn the oven functions selector to the desired function. The power indicator light lights up. The temperature display shows the suggested temperature for the oven function selected. The oven starts to heat up. When the temperature set is reached, an audible signal sounds.
  • Page 15 using the oven electrolux 15 Cooling fan The fan switches on automatically in order to keep the appliance’s sur- faces cool. When the oven is switched off, the fan continues to run to cool the appliance down, then switches itself off automatically. Heat indicator Warming up indicator When the oven function has been...

  • Page 16: Oven Functions

    16 electrolux using the oven Oven Functions The oven has the following functions: Oven function Application Light Using this function you can light up the oven interior, e.g. for cleaning. Convection with For roasting and baking on up to three levels at the same ring heating time.
  • Page 17 using the oven electrolux 17 Inserting the Combination Shelf, Baking Tray and Roasting Pan Inserting the baking tray or roasting Insert baking tray or or roasting pan on the telescopic runners of the selected oven level so that the two holes engage on the front retaining pins on the tele- scopic runners.
  • Page 18 18 electrolux using the oven Inserting/Removing the Fat Filter Only use the fat filter when roasting to protect the rear heating elements from fat splashes. Inserting the fat filter Hold the fat filter by the grip and insert the two mounts downwards into the opening on the rear wall of the oven (fan opening).

  • Page 19: Clock Functions

    using the oven electrolux 19 Clock Functions Temperature / Time Display Clock function indicators Pyrolyse time Selector Button Change display Cook time To set how long the oven is to be in use. End time To set when the oven is to switch off again.
  • Page 20 20 electrolux using the oven How to use the clock functions • After a clock function has been se- lected, the corresponding function indicator flashes for about 5 seconds. During this period, the desired times can be set or mod- ified using the dial.
  • Page 21 using the oven electrolux 21 Countdown 1. Press the Selection button re- peatedly until the function indicator Countdown flashes. 2. Using the control knob set the desired countdown (max. 99.00minutes). The function indicator Countdown lights up. When 90% of the time set has elapsed, an audible signal sounds.
  • Page 22 22 electrolux using the oven Cook time 1. Select the oven function and tem- perature. 2. Press the Selection button re- peatedly until the function indicator Cook time flashes. 3. Using the control knob set the desired cooking time. The function indicator Cook time lights up and the oven comes on immediately.
  • Page 23 using the oven electrolux 23 End time 1. Select the oven function and tem- perature. 2. Press the Selection button re- peatedly until the End time func- tion indicator flashes. 3. Using the control knob set the desired switch-off time. The function indicator End time lights up and the oven comes on immediately.
  • Page 24 24 electrolux using the oven Cook time and End time com- bined Cook time and End time be used simultaneously, if the oven is to be switched on and off auto- matically at a later time. 1. Select the oven function and tem- perature.

  • Page 25: Other Functions

    using the oven electrolux 25 Other Functions Switching off the display You can save energy by switching off the clock display. Switching off the clock display 1. Turn the control knob to the right and hold it. 2. In addition press the Selection button until the display goes out.
  • Page 26 26 electrolux using the oven Ovenís child safety device The oven is fitted with a child safety de- vice. As soon as the child safety device is activated, the oven cannot be switched on. • The child safety device works only for the oven, not for the cooking rings.
  • Page 27 using the oven electrolux 27 Oven automatic cut-out If not switched off after a certain time, or if the temperature is not modified, the oven switches off au- tomatically. The last temperature set flashes in the temperature display. The oven switches off when the oven temperature is: 30 - 120°C after...

  • Page 28: Mechanical Door Lock

    28 electrolux using the oven Mechanical door lock When the appliance is delivered the door lock is deactivated. Activating door lock 1. Take hold of the door trim(B) on the upper edge of the door at both sides and press inwards to release the clip seal.
  • Page 29 using the oven electrolux 29 On the open side of the door trim (B) there is a guide bar (C). This must be pushed between the outer door panel and the guide corner (D). The clip seal (E) must be snapped in. To open the oven door.
  • Page 30 30 electrolux using the oven Removing door lock 1. Take hold of the door trim(B) on the upper edge of the door at both sides and press inwards to release the clip seal. Then remove the door trim by pulling it upwards. 2.
  • Page 31 using the oven electrolux 31 4. Take hold of the door trim(B) at each side, position it on the inside edge of the door and push the door trim (B) onto the upper edge of the door On the open side of the door trim(B) there is a guide bar(C).

  • Page 32: Uses, Tables And Tips

    32 electrolux uses, tables and tips Uses, Tables and Tips Baking Oven function: Convection with ring heating element Conventional Baking tins Oven levels • For Conventional dark metal and • Baking with Conventional is pos- non-stick tins are suitable. sible on one oven level. •...
  • Page 33 uses, tables and tips electrolux 33 General Instructions • Moist recipes (for example, pizzas, fruit flans, etc.) are baked on one • Insert the tray with the bevel at the level. front. • Cakes and pastries at different • With Conventional or Convection heights may brown at an uneven rate with ring heating element...

  • Page 34: Baking Table

    34 electrolux uses, tables and tips Baking table Baking on one oven level Type of Oven Temperature Time Oven function baking level °C Hr: Mins. Baking in tins Ring cake or brioche Convection with 150-160 0:50-1:10 ring heating element Madeira cake/fruit cakes Convection with 140-160 1:10-1:30...
  • Page 35 uses, tables and tips electrolux 35 Type of Oven Temperature Time Oven function baking level °C Hr: Mins. Cake with crumble topping Convection with 150-160 0:20-0:40 (dry) ring heating element Buttered almond cake/sugar Conventional 190-210 0:15-0:30 cakes Fruit flans Convection with 0:35-0:50 (made with yeast dough/ ring heating...
  • Page 36 36 electrolux uses, tables and tips Type of Oven Temperature Time Oven function baking level °C Hr: Mins. Pastries made with egg Convection with 80-100 2:00-2:30 white, meringues ring heating element Macaroons Convection with 100-120 0:30-0:60 ring heating element Biscuits made with yeast Convection with 150-160 0:20-0:40...
  • Page 37 uses, tables and tips electrolux 37 Baking on more than one oven level Convection Convection with ring with ring heating heating Time Tempera- element element Type of baking Hours: ture in °C Mins. Shelf positions from bottom 2 levels 3 levels Cakes/pastries/breads on baking trays Cream puffs/Eclairs 1 / 4...

  • Page 38: Tips On Baking

    38 electrolux uses, tables and tips Tips on Baking Baking results Possible cause Remedy The cake is not browned Wrong oven level Place cake lower enough underneath The cake sinks (becomes Oven temperature too high Use a slightly lower setting soggy, lumpy, streaky) Baking time too short Set a longer baking time...
  • Page 39 uses, tables and tips electrolux 39 Pizza setting table Temperature Time Type of baking Shelf position °C Hr: Mins. Pizza (thin crust) 180 - 200 20 - 30 Pizza (with a lot of topping) 180 - 200 20 - 30 Tarts 180 - 200 45 - 60...
  • Page 40 40 electrolux uses, tables and tips Table for Bakes and Gratins Tempera- Shelf Time Dish Oven function ture position Hr: Mins. °C Pasta bake Conventional 180-200 0:45-1:00 Lasagne Conventional 180-200 0:25-0:40 Convection with Vegetables au gratin ring heating 160-170 0:15-0:30 element Convection with Baguettes topped with...

  • Page 41: Frozen Ready Meals Table

    uses, tables and tips electrolux 41 Frozen Ready Meals Table Food to be Shelf Temperature Oven function Time cooked position °C as per manufac- as per manufac- Frozen pizza Conventional turer’s instruc- turer’s instruc- tions tions Convection with as per manufac- Chips ring heating 200-220...
  • Page 42 42 electrolux uses, tables and tips Roasting Oven function: Conventional Convection grilling Roasting dishes • Any heat-resistant ovenware is suita- ble to use for roasting (please read the manufacturer's instructions). • Large roasting joints can be roasted directly in the roasting tray or on the oven shelf with the roasting tray placed below it.

  • Page 43: Roasting Table

    uses, tables and tips electrolux 43 Roasting table Tem- Time Shelf pera- Type of meat Quantity Ovenfunction Hours position ture mins. °C Beef Pot roast 1-1.5 kg Conventional 200-250 2:00-2:30 per cm. of Roast beef or fillet thickness per cm. Convection 190- - rare...
  • Page 44 44 electrolux uses, tables and tips Tem- Time Shelf pera- Type of meat Quantity Ovenfunction Hours position ture mins. °C Game Saddle of hare, leg 220- up to 1 kg Conventional 0:25-0:40 of hare Saddle of venison 1.5-2 kg Conventional 210-220 1:15-1:45 Haunch of venison...

  • Page 45: Grill Sizes

    uses, tables and tips electrolux 45 Grill sizes Oven function: Grill or Dual grill with maximum temperature setting Important: Always grill with the oven door closed. The empty oven should always be pre-heated with the grill functions for 5 minutes. •...
  • Page 46 46 electrolux uses, tables and tips Drying Oven function: Convection with ring heating element • Use oven shelves covered with greaseproof paper or baking parch- ment. • You get a better result if you switch the oven off halfway through the dry- ing time, open the door and leave the oven to cool down overnight.

  • Page 47: Making Preserves

    uses, tables and tips electrolux 47 Making preserves Oven function: Bottom heat • The jars should all be filled to the same level and clamped shut. • For preserving, use only commercial- ly available preserve jars of the same • Place the jars on the baking tray in size.

  • Page 48: Cleaning And Care

    48 electrolux cleaning and care Cleaning and Care Clean the appliance after each use. In this way, residue is easier to clean off and does not have the chance to Warning: First switch off the appli- burn on. Residue that is not re- ance and let it cool down before moved may cause changes to the carrying out any cleaning.

  • Page 49: Pyrolytic Cleaning

    cleaning and care electrolux 49 Pyrolytic cleaning The Light does not work. When a pre-set temperature is Warning: The oven gets very hot reached, the door is locked. during this process. Keep small The bars of the heat indicator light children away.

  • Page 50: Oven Shelf Runner

    50 electrolux cleaning and care Oven shelf runner The shelf support rails on the left and right hand sides of the oven can be re- moved for cleaning the side walls. Removing the shelf support rails First pull the front of the rail away from the oven wall and then unhitch at the back.
  • Page 51 cleaning and care electrolux 51 Cleaning the oven shelf runner Clean oven shelf runners with hot water and washing up liquid. Important: The oven shelf runners cannot be cleaned in the dishwash- Important: On no account grease telescopic runners. Information regarding use in appli- ances with pyrolytic cleaning: The oven shelf runners must be re- moved before pyrolytic cleaning is...

  • Page 52: Oven Lighting

    52 electrolux cleaning and care Oven lighting Warning: There is a danger of elec- tric shock! Prior to changing the oven light bulb: – Switch off the oven! – Remove the fuses in the fuse box or switch off the circuit breaker. Place a cloth on the oven floor to protect the oven light and glass cov- Replacing the oven light bulb/clean-...

  • Page 53: Oven Door

    cleaning and care electrolux 53 Oven door For easier cleaning of the oven interior the oven door of your appliance can be taken off its hinges. Removing the oven door from its hinges 1. Open the oven door as far as it will 2.
  • Page 54 54 electrolux cleaning and care Hanging the oven door back on its hinges 1. From the handle side take hold of the oven door with a hand on each side and hold at an angle of approx. 45°. Position the recesses on the bottom of the oven door on the hinges on the oven.

  • Page 55: Oven Door Glass

    cleaning and care electrolux 55 Oven door glass The oven door is fitted with four panels of glass mounted one behind the other. The inner panels can be removed for cleaning. Important Rough handling, espe- cially around the edges of the front panel, can cause the glass to break.
  • Page 56 56 electrolux cleaning and care 4. Take hold of the door trim (B) on the upper edge of the door at both sides and press inwards to release the clip seal. Then remove the door trim by pulling it upwards. 5.
  • Page 57 cleaning and care electrolux 57 Putting the door glass panels back. 1. From above insert the door glass panels one after the other into the door profile at the bottom edge of the door at an angle and lower them. The two smaller panels first, then the larger panel.
  • Page 58 58 electrolux cleaning and care 3. Open the oven door as far as it will 4. Fold up the clamping levers (A) on both door hinges back into their orig- inal positions. 5. Close the oven door.

  • Page 59: What To Do If

    what to do if … electrolux 59 What to do if … Problem Possible cause Remedy The oven does not heat up The oven has not been Switch on the oven switched on The clock has not been set to Set the clock to the current the current time time...
  • Page 60 60 electrolux what to do if … If you are unable to remedy the problem by following the above suggestions, please contact your local Service Force Centre. Warning! Repairs to the appliance are only to be carried out by quali- fied service engineers.

  • Page 61: Installation Instructions

    installation instructions electrolux 61 Installation Instructions Attention: The new appliance may only be installed and connected by a registered expert. Please comply with this. If you do not, any damage resulting is not covered by the warranty. Safety information for the installer •...
  • Page 62 62 electrolux installation instructions...
  • Page 63 installation instructions electrolux 63...
  • Page 64 64 electrolux installation instructions...
  • Page 65 installation instructions electrolux 65...

  • Page 66: Disposal

    66 electrolux disposal Disposal Warning: So that the old appliance can no longer cause any danger, make it unusable before disposing Packaging material of it. To do this, disconnect the appliance The packaging materials are envi- from the mains supply and remove ronmentally friendly and can be re- the mains cable from the appliance.

  • Page 67: Guarantee/Customer Service

    guarantee/customer service electrolux 67 Guarantee/Customer Service European Guarantee This appliance is guaranteed by Electrolux in each of the countries listed at the back of this user manual, for the period specified in the appli- ance guarantee or otherwise by law. If you move from one of these countries to another of the countries listed below the appliance guarantee will move with you subject to the following qual-...
  • Page 68 68 electrolux guarantee/customer service www.electrolux.com Albania +35 5 4 261 450 Rr. Pjeter Bogdani Nr. 7 Tirane Belgique/België/ +32 2 363 04 44 Bergensesteenweg 719, 1502 Lembeek Belgien Èeská republika +420 2 61 12 61 12 Budìjovická 3, Praha 4, 140 21 Danmark +45 70 11 74 00 Sjællandsgade 2, 7000 Fredericia...
  • Page 69 guarantee/customer service electrolux 69 Electrolux Service, S:t Göransgatan 143, Sverige +46 (0)771 76 76 76 S-105 45 Stockholm Tarlabaþý caddesi no : 35 Taksim Türkiye +90 21 22 93 10 25 Istanbul 129090 Ìîñêâà, Îëèìïèéñêèé ïðîñïåêò, 16, Ðîññèÿ +7 495 937 7837 ÁÖ...

  • Page 70: Service

    70 electrolux service Service In the event of technical faults, please first check whether you can remedy the problem yourself with the help of the op- erating instructions (section “What to do if…”). If you were not able to remedy the prob- lem yourself, please contact the Cus- tomer Care Department or one of our service partners.
  • Page 72 www.electrolux.com 822 720 378-N-010208-01...
