  • Page 1 Owner’s manual Mode d’emploi Manual de instrucciones Istruzioni per l’uso CMD5 WATERTIGHT MARINE AM/FM/CD/MP3/WMA MULTIMEDIA CONTROLLER COMBINÉ NAUTIQUE ÉTANCHE RADIO AM/FM- LECTEUR CD MULTIMEDIA CONTROLADOR MULTIMEDIA MARINO DE AM/FM/DISCOS CD IMPERMEABLE UNITÀ DI CONTROLLO MULTIMEDIALE PER USO MARITTIMO AM/FM/CD IMPERMEABILE...
  • Page 2 APPARATET BØR KUN ÅBNES AF FAGFOLK MED SÆRLIGT KENDSKAB TIL APPARATER MED LASERSTRÅLER! Indvendigt i apparatet er anbragt den her gengivne advarselsmækning, som advarer imod at foretage sådanne indgreb i apparatet, at man kan komme til at udsaætte sig for laserstråling. CMD5...

  • Page 3: Table Of Contents

    We have made product registration simple with our easy to use website. The registration form is short and easy to complete. Once you’re registered, we can keep you informed of important product information. Register at www.clarion.com - it’s easy to keep your Clarion product up to date. Contents 1. FEATURES ........................3 2.

  • Page 4: Precautions

    INFORMATION FOR USERS: technician for help. CHANGES OR MODIFICATIONS TO THIS PRODUCT NOT APPROVED BY THE MANUFACTURER WILL VOID THE WARRANTY AND WILL VIOLATE FCC APPROVAL. Bottom View of Source Unit CMD5...

  • Page 5: Handling Compact Discs

    3. Do not use the front panel as a tray to place OPEN detection switch. objects on when it is open. 4. When closing the front panel, do not press the [OPEN] button. CMD5...

  • Page 6: Controls

    [ ENT ] [ POWER ] [ DIRECT ] [ SCAN ] [ FADE ] [ REPEAT ] [ TREBLE ] [ RANDOM ] [ BASS ] IR-Receiver DISC With the front panel opened [ CD SLOT ] [ RESET ] CMD5...

  • Page 7: Names Of The Buttons And Their Functions

    MP3/WMA files. [OPEN] button [SCAN] button • Open the panel by pressing the “Clarion • Play 10 seconds of each track while in the CD/ Marine” oval latch button. Audio will mute with MP3 mode.

  • Page 8: Major Button Operations When External Equipment Is Connected To This Unit

    • Select a track when listening to a disc. longer to switch to fast-forward/fast-rewind. • Press and hold the button for 1 second or • Use to proceed to the next menu in the iPod longer to switch to fast-forward/fast-rewind. MENU mode. CMD5...

  • Page 9: Display Items

    : Preset channel indication (1 to 6) : Disc number indication (1 to 6) Display Screen In extreme cold, the screen movement may slow down and the screen may darken, but this is normal. The screen will recover when it returns to normal temperature. CMD5...

  • Page 10: Optional Wired Remote Control Unit Operations

    Titles, frequency, clock, etc. are displayed. * Status display may be different from the display of the control panel. : Stereo indication : Satellite indication : Mute indication Preset channel indication (1 to 6) Disc number indication (1 to 6) [ BAND/DISC ] CMD5...
  • Page 11 Each time the [BAND] button is pressed, the band switches in the following order: SR1 ➜ SR2 ➜ SR3 ➜ SR1..Changing the band (in TV mode) Each time the [BAND] button is pressed, the band switches in the following order: TV1 ➜ TV2 ➜ TV1..CMD5...

  • Page 12: Wireless Remote Control Unit Operations

    • Do not subject battery to heat, or dispose of in fire or water. Do not attempt to disassemble the battery. • Dispose of used batteries properly. WARNING Alkaline(CR) button batteries contain Perchlorate. --Don’t put in Trash-- Dispose as Hazardous Waste. CMD5...
  • Page 13 * Some of the corresponding buttons on the main unit and remote control unit have different functions. *1: For satellite mode, performs category scan. When pressed and held for 2 seconds or longer: preset scan. CMD5...

  • Page 14: Operations

    The system check starts automatically within the unit. Selecting a mode Press the [DISC], [SAT], [AM/FM] or [AUX] button to change the operation mode. * External equipment not connected with CeNET is not displayed. CMD5...

  • Page 15: Radio Operations

    FM1 ➜ FM2 ➜ FM3 ➜ AM ➜ FM1... ● Step tuning 3. Press the [E] or [e] button to tune in the Press the [E] or [e] button to manually tune in a desired station. station. CMD5...
  • Page 16 2. When a desired station is tuned in, press the [ENT] button again to continue receiving that station. Note: • Be careful not to press and hold the [ENT] button for 2 seconds or longer, otherwise the auto store function is engaged and the unit starts storing stations. CMD5...

  • Page 17: Cd/Mp3/Wma Operations

    Check box for COPY PROTECT MUSIC. be played in the order displayed on the PC). Then, reconstruct files. • Some noise may occur depending on the type Personally constructed WMA files are used at of encoder software used while recording. your own responsibility. CMD5...
  • Page 18 To resume CD play, press and hold the [ CD SLOT button again. Insert a CD into the center of the CD SLOT with the label side facing up. While loading, “FILE READ” appears on the display; then the CD plays automatically. CMD5...
  • Page 19 1. Press and hold the [SCAN] button for 1 second or longer. * Folder scan play starts from the next track after the track currently being played back. 2. To cancel folder scan play, press the [SCAN] button again. CMD5...
  • Page 20 This function allows you to play all tracks of all the folders recorded on an MP3/WMA disc in a random order. 1. Press and hold the [RANDOM] button for 1 second or longer. 2. To cancel folder random play, press the [RANDOM] button again. CMD5...

  • Page 21: Common Operations

    3. Turn the [VOLUME] knob to select “ON” or rings. “OFF”. * This function is not compatible with all cellular 4. Press the [MENU] button to return to the telephones. Contact your local authorized Clarion previous mode. dealer for information on proper installation and compatibility. Setting the clock 1.
  • Page 22 3. Turn the [VOLUME] knob to select the reception area. 4. Press the [MENU] button to return to the previous mode. 4. Press the [MENU] button to return to the previous mode. The above operations are required when a TV tuner other than TTX7501z is connected. CMD5...
  • Page 23 You can listen to telephone calls from the 4. Press the [MENU] button to return to the CeNET input. previous mode. (with Bluetooth BB (BLT433) connected) 4. Press the [MENU] button to return to the previous mode. CMD5...
  • Page 24 2. Press the [E] or [e] button to select “SYSTEM CHECK”. 3. Press and hold the [ENT] button for 1 second or longer. CeNET connection configuration is automatically checked. When the system check is complete, the display returns to the previous mode. CMD5...

  • Page 25: Accessories

    : when the antenna is (1-888-539-SIRIUS (7474), online at disconnected. siriusradio.com) and inform us of your SIRIUS ID • SUB UPDT : when the subscription of a and a few other details. channel covered by your contract is being updated. CMD5...
  • Page 26 You can also perform available that channel is received. Otherwise, seeking by using the [E] or [e] button. seeking continues until an available channel is found. 3. Press the [CAT] button again to cancel. CMD5...
  • Page 27 1. Press the [ENT] button to start a category scan. 2. Press the [CAT] button, a [DIRECT] button, the [E] or [e] button to cancel a category scan. Note: • Category scanning is not available when no category is defined for the current channel. CMD5...

  • Page 28: Ipod Operations

    Press the [DISP] button to select the desired longer during playback. display. ● Fast-rewind Each time you press the [DISP] button, the display switches in the following order: Press and hold the [e] button for 1 second or longer during playback. CMD5...
  • Page 29 In the iPod mode, you can select tracks by the album title or artist name by the similar operations on the iPod as well as the iPod Music menu. Note: • In the iPod MENU mode, you cannot specify the fast-forward, fast-backward, repeat and random playback. CMD5...

  • Page 30: Cd Changer Operations

    2. To cancel disc repeat play, press the beginning of the previous track. [REPEAT] button again. Fast-forward/fast-rewind ● Fast-forward Press and hold the [E] button for 1 second or longer. ● Fast-rewind Press and hold the [e] button for 1 second or longer. CMD5...
  • Page 31 This function continues automatically until it is canceled. 1. Press and hold the [RANDOM] button for 1 second or longer. 2. To cancel disc random play, press the [RANDOM] button again. CMD5...

  • Page 32: Tv Operations

    Setting TV/VTR and TV diver Press and hold the [E] or [e] button for 1 second or longer to tune in a station. To switch TV to VTR, to select the TV area, and to set the TV diver, see “Common Operations”. CMD5...

  • Page 33: Troubleshooting

    File system is not correct. Use ISO9660 level 1, 2 or JOLIET or Romeo file system. Sound skips or is Disc is dirty. Clean the disc with a soft cloth. noisy. Disc is heavily scratched Replace with a disc with no scratches. or warped. CMD5...
  • Page 34 The microprocessor has Perform a system check. See “Common does not recognize not stored the proper Operations”, performing a system check section. CeNET source CeNET information. connection. The CeNET cable is not Ensure the CeNET cables are properly connected properly. connected. CMD5...

  • Page 35: Error Displays

    If an error display other than the ones described above appears, press the reset button. If the problem persists, turn off the power and consult your store of purchase. CMD5...

  • Page 36: Specifications

    U.S.A: 87.9 MHz to 107.9 MHz Europe: 87.5 MHz to 108.0 MHz Australia: 87.0 MHz to 108.0 MHz Note: Usable Sensitivity: 9 dBf • Specifications and design are subject to change 50 dB Quieting Sensitivity: 15 dBf without notice for further improvement. CMD5...
