TECHNICAL INFORMATION

Gross Freezer Capacity lt.
Net Freezer Capacity lt.
Dimensions (width*height*depth, cm)
Tension (V/Hz)
Energy Consumption (kWh/24h)
Energy Class
Freezing Capacity (kg/24h)
Temperature increase time h
Noise (dB/A)
Climatic Class
The technical infomation are situated in the rating plate on the internal left side of the appliance .

INSTALLATION

Location
The appliance should be installed well away from
sources of heat such as radiators, boilers, direct
sunlight etc. For safety reasons, minimum ventilation
must be as shown in Fig.
Appliance positioned under overhanging kitchen wall
units (see Fig. A).
Appliance positioned without overhanging kitchen
wall units (see Fig. B).
Attention: keep ventilation openings clear of
obstruction.
Two adjustable feet at the cabinet base allow
accurate levelling of the appliance.
EUC 2323
220
195
160x60x62,5
220-240/50
0,721
A
20
35
38
SN-T
A
B
NP00
43
