Changing the opening direction of
the door
Before carrying out any operations, remove the plug
from the power socket.
To change the opening direction of the door,
proceed as follows:
1. Remove the ventilation grill (D).
2. Unscrew the bottom hinge (E).
3. Remove the door by releasing it from the top
hinge pin (G).
4. Remove the pin then mount these on the
opposite side.
5. Remove the two plugs, to reveal the holes for the
hinge pivots, and remount them on the other
side.
6. Replace the freezer door.
7. using a 10 mm spanner, unscrew the hinge pin
(E) and reassemble it on the opposite side of the
hinge;
8. Screw down the bottom hinge (E) on the opposite
side by using the screws previously removed.
9. Remove the plug (F) from the ventilation grill (D)
and replace it on the opposite side.
10.Re-assemble the ventilation grill (D).
11. Unscrew the handle. Refit it on the opposite side.
Warning:
After having reversed the opening direction of the
doors check that all the screws are properly
tightened and that the magnetic seal adheres to the
cabinet. If the ambient temperature is cold (i.e. in
Winter), the gasket may not fit perfectly to the
cabinet. In that case, wait for the natural fitting of the
gasket or accelerate this process by heating up the
part involved with a normal hairdrier.
