Summary of Contents for Chauvet Circus 2.0 IRC
- Page 1 User Manual...
-
Page 2: Table Of Contents
ABLE OF ONTENTS 1. Before You Begin ......................3 What Is Included ..........................3 Unpacking Instructions ........................3 Claims ............................... 3 Text Conventions ..........................3 Symbols ............................3 Disclaimer ............................3 Product at a Glance .......................... 4 Safety Notes ............................. 4 2. -
Page 3: Before You Begin
Failure to report damage to the carrier immediately may invalidate your claim. In addition, keep the box and contents for inspection. For other issues, such as missing components or parts, damage not related to shipping, or concealed damage, file a claim with CHAUVET® within 7 days of delivery. Text Convention Meaning 1–512... -
Page 4: Product At A Glance
Product at a Use on Dimmer Auto Programs Outdoor Use Auto-ranging Power Supply Glance Sound-Activated Replaceable Fuse User-Serviceable Master/Slave Duty Cycle Safety Notes These notes include important information about the mounting, usage, and maintenance of this product; read before using the product. ·... -
Page 5: Introduction
2. I NTRODUCTION Overview Display Control Buttons Safety Loop DMX In Microphone DMX Out Back Panel View Power In Microphone Sensitivity Adjustment Knob Fuse Holder Power Out LED Pods IRC Remote Receiver SMD Strobe LEDs Front View (white) Circus™ 2.0 IRC User Manual (Rev. 1) Page 5 of 17... -
Page 6: Dimensions
Dimensions 14.7 in/373 mm 7.8 in/200 mm Page 6 of 17 Circus™ 2.0 IRC User Manual (Rev. 1) -
Page 7: Setup
3. S ETUP AC Power The Circus™ 2.0 IRC has an auto-ranging power supply and it can work with an input voltage range of 100~240 VAC, 50/60 Hz. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart. -
Page 8: Power Linking
The power linking diagram shown above corresponds to the North American version of the product ONLY! If using the product in other markets, you must consult with the local CHAUVET® distributor as power linking connectors and requirements may differ in your country or region. -
Page 9: Mounting
Mounting Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes. Orientation The Circus™ 2.0 IRC may be mounted in any position; however, make sure adequate ventilation is provided around the product. · Rigging Before deciding on a location, always make sure there is easy access to the product for maintenance and programming. -
Page 10: Operation
4. O PERATION Control Panel To access the control panel functions, use the four buttons located underneath the display. Operation Button Function Selects an operation mode or to backs out of the current menu <MENU> option <UP> Scrolls up the list of options or selects a higher value <DOWN>... -
Page 11: Dmx Channel Modes, Assignments, And Values
DMX Channel Modes, Assignments, and Values Channel Function Value Setting 4-Channel 000 ó 015 No function 016 ó 021 Automatic 1 022 ó 027 Automatic 2 028 ó 033 Automatic 3 034 ó 039 Automatic 4 040 ó 045 Automatic 5 046 ó... -
Page 12: Configuration (Standalone)
Configuration Set the product in one of the standalone modes to control without a DMX controller. Connect the product to a suitable power outlet. (Standalone) Turn the product on. Never connect a product that is operating in any standalone mode (either Static, Automatic, or Sound) to a DMX string connected to a DMX controller. -
Page 13: Master/Slave Mode
Do not connect more than 31 slave units to the master unit. The Circus™ 2.0 IRC is fully compatible with the Infrared Remote Control (IRC) from Infrared Remote CHAUVET®. To enable usage with the IRC, do the following: Control (IRC) Press <MENU> repeatedly until SEr shows on the display. -
Page 14: Irc Operation
IRC Operation Note: Make sure to point the IRC directly at the receiver on the product. Automatic Mode Automatic mode will enable you to run the automatic programs on the product. To turn on Automatic mode: Press <AUTO> on the IRC. Press <+>... -
Page 15: Technical Information
5. T ECHNICAL NFORMATION Product Dust build-up reduces light output performance and can cause overheating. This can lead to reduction of the light source’s life. To maintain optimum performance and Maintenance minimize wear, clean the product at least twice a month. However, usage and environmental conditions contribute to increased cleaning frequency. -
Page 16: Technical Specifications
6. T ECHNICAL PECIFICATIONS Dimensions and Length Width Height Weight Weight 14.7 in (373 mm) 7.8 in (200 mm) 13 in (330 mm) 8.5 lbs (3.8 kg) Note: Dimensions in inches rounded to the nearest decimal digit. Power Supply Type Range Voltage Selection Power... -
Page 17: Returns
You must send the merchandise prepaid, in its original box, and with its original packing and accessories. CHAUVET® will not issue call tags. Clearly label the package with the RMA number. CHAUVET® will refuse any product returned without an RMA number.
