Operating Manual AV-MTD G 30 TTT
Page 2

Rear Panel and Specification

DSUB9F
XLR4M
1
off
1
DC In
on/off
Data Out:
Power In:
1: RS485 TRA 1: GND
2: RS485 TRB 4: DC In
3: LTC_1 12-18V DC
max. 500mA
4: LTC_2
5: GND
Video In:
DCF77 antenna:
DCF77/GPS serial data:
GPI:
Housing:
Weight:
Operating temperature:
Permissible humidity:
With the special option "receiving real-time from an LTC" there is neither a DCF77 antenna
connection nor a DCF77/GPS data connection, instead, a second XLR socket is installed as
LTC input.
XLR3M XLR3F
4 2
1
2
2 3
3
LTC Out
LTC In (optional)
LTC Out:
LTC In:
1: GND
1: GND
2: LTC_1
2: LTC_1
3: LTC_2
3: LTC_2
balanced, 1Vpp
balanced
50mV - 5V
20-30 frames/sec
1 Vp-p, CVBS or black burst. For V8 colour framing there has to
be the white flag in line 7.
Meinberg type
RS232, 2400/7/E/2
relay contacts between COM1 and NC1 (normally closed). At
trigger for approx. one second contact closure between COM1
and NO1 (normally open).
Max. breaking capacity:
Max. turn-on voltage:
Max. switching current:
Max. main current:
½ 19", 1 U, 214 (W) x 43 (H) x 262 (D) mm
2.0 kg (approx.)
5 °C to 40 °C
35 % up to 85 %
DSUB9M
DSUB9F
1
1
1
3
GPI DCF77/GPS
Data In:
(Option):
1: NC1 2: RxD
2: NO1 5: GND
3: COM1
5 W
175 V
0.25 A
1 A
BNC
BNC insul./SMA
75Ohm
BNC BNC
Antenna
In
off on
Loop
Option
DCF77/GPS
Video In
Antenna
Loop Out
Option VITC:
Video+VITC Out
