Description of the Menu Lines

Pressing the menu key switches the menu lines on or off. After power-on the last selected
menu line is displayed (the menu LED lights up). A menu line serves to indicate actual settings
or executable functions. Pressing the select key all menu lines may be displayed cyclically,
pressing the enter key the indicated settings may be altered or functions may be executed.
Menu line
LOCK OFF (ON)
U Store
U Load
U reset
GPI A0
Operating Manual AV-MTD G 30 TTT
Description
Key-lock off (on).
Key-lock "on" means that all keys except the menu and enter key are
without function. This way the generator cannot be switched
inadvertently.
Switch between ON and OFF by pressing the enter key.
Pressing the enter key all current settings (including settings made via
an external MTD operational unit) may now be stored in a "user"
storage area; see also chapter "Stored data and factory settings".
During the backup Store is displayed, afterwards U Store is displayed
again. This process will not disturb any current operation of the
generator.
Pressing the enter key calls the settings of the "user" storage area, see
also chapter "Stored data and factory settings".
Attention: This action will restart the G 30 TTT just like a power-on!
Pressing the enter key resets the "user" storage area to the standard
values (factory settings), see also chapter "Stored data and factory
settings". During the backup Store is being displayed, afterwards U
reset is displayed again. This process will not disturb any current
operation of the generator.
Display and alteration of settings of the relay trigger:
A0 = trigger at time A, inactive.
A1 = trigger at time A, active.
B0 = trigger at time B, inactive.
B1 = trigger at time B, active.
Pressing the enter key calls the alteration set mode, the select LED
lights up ( only with built-in option "GPI"). Then, the display will
additionally display the actual trigger time.
The hours key alters the hours of the trigger time,
The minutes key alters the minutes of the trigger time,
The seconds key alters the second of the trigger time,
The frames key switches between A0
The set key terminates the programming and stores the new setting.
If the GPI is inactive or not triggered, the contacts COM1 and NC1 are
closed. If the time (A or B) assigned to the GPI matches the selected
(trigger) time and GPI is set active, then COM1 closes to NO1 for
approx. one second.
A1 B0 B1.
