Stored Data and Factory Settings

Settings which have been made via G 30 TTT or via a MTD user console will be stored. In
detail these settings are as follows:
Settings via G 30 TTT
• Start value (hours, minutes, seconds, frames)
• Operating mode = real-time, ltc, E or start key
• colour framing on/off, cf key
• key-lock LOCK on/off
• GPI active/inactive and at time A/B, trigger time
Settings via MTD user console
display format (1-8)
hyphen (colon, dec. point, off)
leading zeros on (1)/off (0)
leading zeros at zero on (1)/off (0)
flashing with negative on (1)/off (0)
function selection (UP/DOWN/DIFF...)
Offset
down stop (0) or down overflow (1)
For more details see operating instructions of the MTD system.
These data may be written altogether into in different storage areas. The storage areas are
organised as follows:
Area "F": factory settings of G 30 TTT. These non-erasable data are stored in the PROM.
Area "S": backup memory saving any alteration made during current operation. The data
are stored in an EEPROM (i.e. that they will be available when switching on
again).
Area "U": user area, permits to store separately a complete system setting. These data
are stored in an EEPROM as well.
Area "W": working area for current operation. RAM area which changes with new
settings.
PROM
READ ONLY
"F"
FACTORY
SETTING
POWER ON: "S"
RESET: "F"
The diagram above shows the storage areas and processes:
Operating Manual AV-MTD G 30 TTT
A B C
1 1 1
: : :
0 0 0
0 0 0
0 0 0
UP UP UP
0 0 0
1 1 1
EEPROM
STORE + READ
"S" "U"
SAVE USER
AREA AREA
"W"
"S" "W"
Factory settings
00:00:00:00
real-time
off
off
00:00:00 A0
D E F
1 1 1
: :
0 0 1
0 0 0
0 0 0
UP UP OFFSET
TC
0 0 0
1 1 1
RAM
RANDOM
"W"
WORKING
AREA
USER STORE: "W"
USER LOAD: "U"
USER RESET: "F"
Page 9
H I LTC
7 1 1
. .
0 0 1
"U"
"W"
"U"
