- Page 1 OPERATING INSTRUCTIONS OAKTON WD-35606-00, -05 CON 5 and TDS 5 Acorn Series Meters CON 5 Acorn series DISTRIBUTED BY: Conductivity/ C Meter HOLD ENTER MODE 00702-39 Printed in the U.S.A. 8/98...
-
Page 2: Table Of Contents
Table of Contents 1. Introduction...................4 2. Display and Keypad Functions...............5 3. Preparation..................6-7 3.1 Inserting the batteries ........................6 3.2 Connecting the electrode and temperature probe ..............6 3.3 Switching the Meter on .......................7 3.4 Setting the Conductivity-to-TDS conversion factor (Acorn TDS5 only) ......7 4. -
Page 3: Introduction
1. Introduction 2. Display and Keypad Functions Thank you for purchasing an OAKTON ® Acorn Meter. These meters are economical, The Acorn has a large custom LCD with the following indicators: microprocessor-based meters that deliver ±2% full scale accuracy. indicates... -
Page 4: Preparation
Switching the meter on 3. Preparation Press the ON/OFF key to power up your meter. All the LCD segments display for a few seconds as the meter goes through a self-diagnostic test. The LCD then Inserting the batteries switches into Conductivity/TDS measurement mode. Wet the probe for 10 minutes before calibrating or taking readings in order to saturate the probe surface and The battery compartment is found at the minimize drift. -
Page 5: Calibration
Calibrating for Conductivity or TDS 4. Calibration Pour approximately 3 cm of the chosen Conductivity / TDS standard into two separate containers. Conductivity/TDS calibration Gently stir the probe in one of the containers of your standard. This standard acts as a rinse solution, removing contami- This instrument is capable of up to three-point calibration to ensure accuracy across nants that offset the calibration. -
Page 6: Temperature Calibration
Temperature calibration 5. Measurement The built-in temperature sensor included in the probe is factory calibrated. Over time, the temperature calibration may drift and require recalibration. If you replace Taking Measurements the probe you should calibrate temperature prior to Conductivity/TDS calibration. Connect your probe to the meter. -
Page 7: Probe Care And Maintenance
7. Error Messages 6. Probe care and maintenance Keep your conductivity probe clean. Error Message in LCD display Indicates Solution For best accuracy, soak a dry probe at least 5 to 10 minutes before use. Rinse the Recalibrate instrument probe before use, and gently swirl it while you take readings. Microproccesor Turn meter off and then on Wash the probe with deionized or tap water before storing it. -
Page 8: Troubleshooting
7. Troubleshooting 8. Specifications Problem Cause Solution Conductivity / TDS / Mode Temperature CON 5 TDS 5 LO annunciator Low battery Replace batteries 0.0 to 199.9 µS 0.0 to 99.9 ppm on LCD with fresh set 200 to 1999 µS 100 to 999 ppm 0.0 to Range... -
Page 9: Accessories
TDS values: 8759 ppm KCl, 8532 ppm NaCl, 13,455 ppm 442. from drops and dings. Also features meter stand for convenient benchtop use. To order OAKTON accessories, contact your OAKTON distributor. OAKTON calibration solutions (1 pint bottles) Conductivity solutions have ±1% accuracy at 25°C. Shpg wt 1.1 lb/510 g per bottle. -
Page 10: Warranty
15. Warranty OAKTON warrants this meter to be free from significant deviations in material and workmanship for a period of one year from date of purchase. OAKTON warrants this probe to be free from significant deviations in material and workmanship for a period of six months from date of purchase.
