PARTS AND OPERATION MANUAL
OPERATION AND PARTS MANUAL
TM
WHISPERWATT
SERIES
MODEL DCA-56SPX
60 Hz GENERATOR
(PARTS LIST NO. B4871301604 S/N 3796699~)
Revision #1 (04/14/10)
THIS MANUAL MUST ACCOMPANY
THE EQUIPMENT AT ALL TIMES.
