Any attempt to crank or start the engine before
it has been properly serviced with the
recommended oil may result in an engine
failure.
•
Place generator on a level surface.
•
Clean area around oil fill and remove oil fill cap and dipstick.
•
Wipe dipstick clean.
•
Slowly fill engine with oil through the oil fill opening until it reaches
the full mark. Stop filling occasionally to check oil level. Be
careful not to over fill.
•
Install oil fill cap and finger tighten securely.
•
Check engine oil level before starting each time thereafter.
2.7.2 ADDING GASOLINE
Never fill fuel tank indoors. Avoid spilling
gasoline on hot engine. Allow engine/unit to
cool entirely before adding fuel. Never fill fuel
tank when engine is running or hot. DO NOT
light a cigarette or smoke when filling the fuel
tank. Gasoline is highly flammable and its
vapors are explosive.
Do not overfill the fuel tank. Always leave room
for fuel expansion. If the fuel tank is over-filled,
fuel can over flow onto hot engine and cause an
explosion.
•
Use regular UNLEADED gasoline with the generator engine. Do
not use any gasoline with more than 10% added ethanol. Do not
use E85 gasoline. Do not mix oil with gasoline.
•
Clean area around fuel fill cap, remove cap.
•
Slowly add unleaded regular gasoline to fuel tank. Fill to bottom of
screen filter. Be careful not to overfill (Figure 9).
•
Install fuel cap and wipe up any spilled gasoline.
Figure 9 - Fuel Tank
Fuel Tank
Fuel
8
Section 2 – Operation
Portable Generator System
DANGER
DO NOT Fill Above Lip
IMPORTANT: It is important to prevent gum deposits from forming
in fuel system parts such as the carburetor, fuel hose or tank during
storage. Alcohol-blended fuels (called gasohol, ethanol or methanol)
can attract moisture, which leads to separation and formation of acids
during storage. Acidic gas can damage the fuel system of an engine
while in storage. To avoid engine problems, the fuel system should
be emptied before storage of 30 days or longer. See the "Storage"
section. Never use engine or carburetor cleaner products in the fuel
tank as permanent damage may occur.
2.8 TO START THE ENGINE
Never start or stop engine with electrical
devices plugged into the receptacles AND
devices turned on.
•
Unplug all electrical loads from the unit's receptacles before
starting the engine.
•
Make sure the unit is in a level position.
•
OPEN
the Fuel Shut-off Valve (Figures 10 and 11).
Figure 10 - Fuel Shut-off Valve
Figure 11 - Fuel Shut-off Decal
