- Page 1 User Manual...
-
Page 2: Table Of Contents
Automatic Mode ..........................10 Sound-Active Mode ......................... 10 Master/Slave Mode ......................... 11 5. Maintenance .........................11 Product Maintenance ....................... 11 6. Technical Specifications ....................12 Returns ............................ 13 Contact Us ..........................13 Page 2 of 13 Cubix™ 2.0 User Manual (Rev. 5) -
Page 3: Before You Begin
CHAUVET® assumes no responsibility or liability for any errors or omissions that may appear in this manual. CHAUVET® reserves the right to update the existing document or to create a new document to correct any errors or omissions. -
Page 4: Product At A Glance
Please contact the nearest authorized technical assistance center. • Keep this User Manual for future use. If you sell the product to someone else, be sure that they also receive this document. Page 4 of 13 Cubix™ 2.0 User Manual (Rev. 5) -
Page 5: Introduction
2. I NTRODUCTION Product Overview LED Display Fuse Holder Safety Loop DMX In/Out Power In/Out Perimeter (Side) Lenses (20) Middle Lens Cubix™ 2.0 User Manual (Rev. 5) Page 5 of 13... -
Page 6: Product Dimensions
Product Dimensions Page 6 of 13 Cubix™ 2.0 User Manual (Rev. 5) -
Page 7: Setup
Product Product Other products You can power link up to 19 Cubix™ 2.0 units on 120 VAC or up to 32 Cubix™ 2.0 units on 230 VAC. The power linking diagram corresponds to the North American version of the product ONLY! If using the product in other markets, you must consult with the local CHAUVET®... -
Page 8: Mounting
Mounting Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes. Orientation The Cubix™ 2.0 may be mounted in any position; however, make sure adequate ventilation is provided around the product. Rigging • Before deciding on a location for the product, always make sure there is easy access to the product for maintenance and programming purposes. -
Page 9: Operation
DMX mode uses. If you choose a starting address that is too high, you could restrict the access to some of the product’s channels. The Cubix™ 2.0 uses up to 7 DMX channels in its 7-channel DMX mode, which defines the highest configurable address to 506. -
Page 10: Dmx Channel Assignments And Values
Press <MENU repeatedly until SNd shows on the display. Press <ENTER>. Turn the music on and adjust the sound sensitivity knob until the product starts responding to the beat of the music. Page 10 of 13 Cubix™ 2.0 User Manual (Rev. 5) -
Page 11: Master/Slave Mode
Master/Slave The Master/Slave mode allows a single Cubix™ 2.0 unit (the “master”) to control the actions of one or more Cubix™ 2.0 units (the “slaves”) without the need of a DMX Mode controller. The master unit will be set to operate in either Automatic or Sound Active mode, while the slave units will be set to operate in Slave Mode. -
Page 12: Technical Specifications
Coverage angle 111º Thermal Maximum External Temp. Cooling System 104° F (40° C) Convection I/O Connectors Channel Range 3-pin XLR Ordering Product Name Item Code UPC Number Cubix™ 2.0 03050528 781462208769 Page 12 of 13 Cubix™ 2.0 User Manual (Rev. 5) -
Page 13: Returns
Be sure to pack the product properly. Any shipping damage resulting from inadequate packaging will be your responsibility. FedEx packing or double-boxing are recommended. CHAUVET® reserves the right to use its own discretion to repair or replace returned product(s). Contact Us World Headquarters United Kingdom &...
