Dimplex Electric Fireplace Operation

Hide thumbs Also See for Electric Fireplace:

REMOTE CONTROL USAGE

The fireplace is supplied with a radio frequency remote control. This remote control has a range of

approximately 50 feet. (15.25m), it does not have to be pointed at the fireplace and can pass through

most obstacles (including walls). It is supplied with one of 2178 independent frequencies to prevent

interference with other units. The frequency designation is indicated on the back of the transmitter.

The remote control operates the fireplace levels sequentially. The level is increased every time the ON

button on the transmitter is pressed. The fireplace can be turned off at any point by pressing the OFF

button on the remote control transmitter.

Stage 1 – Flame Effect only

Stage 2 – Flame Effect and low heat

Stage 3 – Flame Effect and high heat

1. To replace the battery, slide battery cover open on the hand held transmitter.

2. Correctly install one (1) 12 Volt (A23) battery in the battery holder.

3. Close the battery cover.

LIGHT

OFF BUTTON

THREE POSITION

SWITCH

BATTERY

BATTERY COVER
