Strong SRT 4930 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Enlarged version
1. Introduction ........................................................................................................... 2
2. Safety/Precautions ............................................................................................... 3
3. Points to Check before Use ................................................................................. 5
4. Controls/Functions .............................................................................................. 6
4.4 Front Display
5. How to Connect .................................................................................................. 11
6. Operation ............................................................................................................. 12
7. Troubleshooting ................................................................................................. 55
8. Specifications ..................................................................................................... 56
1
Contents

Advertisement

Table of Contents
loading

Related Manuals for Strong SRT 4930

Summary of Contents for Strong SRT 4930

  • Page 1: Table Of Contents

    Contents 1. Introduction ......................2 1.1 Overview 1.2 Main Features 2. Safety/Precautions ....................3 2.1 Safety 2.2 Precautions 3. Points to Check before Use ................. 5 3.1 Accessories 4. Controls/Functions ....................6 4.1 Front Panel 4.2 Rear Panel 4.3 Remote controller 4.4 Front Display 5.

  • Page 2: Introduction

    Introduction Safety/Precautions 1.1 Overview 2.1 Safety This satellite receiver is designed for the reception of free-to-air and encrypted channels. Depending on your location, enjoy the rich choice of up to 10,000 different channels broadcasting a large range of programs: culture, sports, cinema, news, Be sure to read this user's manual before Do not touch the power cord with wet events, etc.

  • Page 3: Precautions

    2.2 Precautions Points to Check before Use When installing the unit 3.1 Accessories Install the unit horizontally. An uneven Do not put heavy items such as a TV installation may cause the unit to be set on the unit. That may damage The accessories below are included with this receiver: damaged.

  • Page 4: Controls/Functions

    4.2 Rear Panel Controls/Functions 4.1 Front Panel No. Name Connector Function LNB INPUT IEC 169-24 FEMALE IF input from LNB to digital tuner LOOP OUT IEC 169-24 FEMALE IF loop-through output from digital tuner VIDEO RCA cinch Composite video output Power : Switches the receiver between ‘Standby’...

  • Page 5: Remote Controller

    4.3 Remote controller 4.3 Remote controller POWER : To turn the receiver On/Off. Vol Up & Down : To change the volume level in non-menu mode. STAND BY : Just turn the receiver off. OK : To show the Channel List in non- TEXT : To show the teletext contents if menu mode and select an item or teletext is transmitted.

  • Page 6: How To Connect

    How to Connect Operation When Connecting the Receiver to a TV 6.1 Getting Started Connect the TV antenna to TV ANT IN After your receiver is powered on, proceed with installation as follows : Connect the Video and Audio of the TV to Video and Audio: connect the red 1) Menu Language Setting and white connectors to Audio R and Audio L, and the yellow connector to Video...
  • Page 7 6.1 Getting Started 6.1 Getting Started ( When the DiSEqC Motor parameter is set as 1.2 <Figure 6.1.4> ) 2) Antenna Setup - Satellite : Select any satellite by pressing buttons. Press the MENU button to display the main menu. - Frequency : Displays the current TP value of the selected satellite.
  • Page 8 6.1 Getting Started 6.1 Getting Started ( When the DiSEqC Motor parameter is set as USALS <Figure 6.1.6> ) 3) Satellite Scan - Sat Degree : Satellite location. Through this function, the receiver searches for all the available channels and saves - Antenna Position : Press them in memory.
  • Page 9 6.1 Getting Started 6.1 Getting Started Blind Scan <Figure 6.1.10> Package Identifier (PID) Scan <Figure 6.1.12> Select the satellites you want to search by pressing the button on the remote. Select a transponder. Press to set the “Polarization” and “Scan Mode” options. To change a transponder’s information (Frequency, Symbol Rate), use the NUMERIC buttons.
  • Page 10 6.1 Getting Started 6.1 Getting Started 4) Channel Selection 5) Other Functions of the Remote Control Volume Control You can use to navigate between channels until you find the channel you While watching a program, press to control the volume. want.
  • Page 11 6.1 Getting Started 6.1 Getting Started Multi Picture Display <Figure 6.1.14> SUBTITLE <Figure 6.1.17> You can press to display multiple pictures; you can choose the number of pictures You can press to select the subtitle language of current channel. such as 1X2, 2X2, 2X3 or 3X3. SLEEP <Figure 6.1.18>...

  • Page 12: System Setting

    6.2 System Setting 6.2 System Setting 1) Time Settings 2) A/V Output Settings This submenu allows you to set your local time, wake up time, wake up channel and This submenu allows you to specify the audio/video output. <Figure 6.2.2> sleep time.
  • Page 13 6.2 System Setting 6.2 System Setting 3) OSD Settings 4) Security Settings This submenu allows you to set the menu language, OSD transparency and Information This submenu allows you to set password options and to lock or unlock access to menus and Volume timeouts.
  • Page 14 6.2 System Setting 6.2 System Setting 5) Database Reset 6) IP Setting This submenu allows you to restore the factory set values (useful when encountering If the Network supports DHCP , IP settings can be allocated automatically. If the Network problems after changing settings).

  • Page 15: Channels

    6.2 System Setting 6.3 Channels 7) Data Transfer 1) Set Favorites This submenu allows you to set up favorite groups of channels. You can select TV or This submenu allows you to transfer the software from a receiver to another receiver. You Radio channels in an alternative way by pressing the TV/RADIO button.
  • Page 16 6.3 Channels 6.3 Channels 4) Lock Channels This submenu allows you to lock channels to control access to them. Once a channel is locked, you will be asked to enter a password whenever you try to watch it. You can select TV or Radio channels in an alternative way by pressing the TV/RADIO button.
  • Page 17 6.3 Channels 6.3 Channels 5) Skip Channels 6) Delete Channels This submenu allows you to skip channels. Once a channel is set to be skipped, it will be This submenu allows you to delete channels. You can select TV or Radio channels in an whenever you navigate channels using in non-menu mode.

  • Page 18: Electronic Program Guide

    6.3 Channels 6.4 Electronic Program Guide 7) Add Channels 1) EPG This submenu allows you to add channels. This submenu allows you to access the electronic program guide when available. Press on ‘Add Channels’. The following menu will be displayed. <Figure 6.3.8> Press the GUIDE button to display the guide menu.

  • Page 19: Games

    6.4 Electronic Program Guide 6.5 Games 1) Tetris Press on ‘Tetris’. The following menu will be displayed. <Figure 6.5.1> You can choose a skill level using Press to start the game <Figure 6.5.2>, or press the EXIT button to return to the previous menu.
  • Page 20 6.5 Games 6.5 Games 2) Sokoban 3) Snake How to play Sokoban: you have to push the balls to their correct positions. The balls can Press on ‘Snake’. The following menu will be displayed. <Figure 6.5.5> only be pushed, never pulled, so you have to be careful not to push them into a corner You can choose a skill level using where you can’t get them out from.

  • Page 21: Storage

    6.6 Storage 6.6 Storage This submenu allows you to play various MP3 files, view JPG files or download a new 2) JPG menu software by connecting your USB flash drive. Press to select a picture. <Figure 6.6.3> Press to show the picture you want to display. 1) MP3 menu - RED : Sets the time interval between slides.
  • Page 22 6.6 Storage 6.6 Storage 4) Disk Manager 5) Timer Manager Use the cursor keys to activate the desired functions from this menu. Press the after selecting the timer number <Figure 6.6.6> - Default Disk : Set the DVR disk. Press to select timer parameters - Disk Information : Choose the Hard disk volume or usb device with USB hub.

  • Page 23: System Information

    6.7 System Information 6.8 Conditional Access System You can check the current information about your receiver such as receiver model name, 1) Card Initializing S/W (software) version, H/W (hardware) version, manufacturing date, etc. To Enjoy CONAX CAS7 scrambled channels, you will need a Smart Card from the service <Figure 6.7.1>...

  • Page 24: Dvr

    6.8 Conditional Access System 6.9 DVR 2) The Status of the Smart Card 1) File List You can access detailed information about the Smart Card using the File Playback keys in the Main Menu to select ‘CA’ and pressing . <Figure 6.8.2> Press to show the file list.
  • Page 25 6.9 DVR 6.9 DVR Edit Menu 2) Trick Mode You can operate the trick mode while you are playing the recorded files. These functions You will be asked to enter a password whenever you try to enter it. Press . The pop- are available in playback mode or time-shift mode powerfully.
  • Page 26 6.9 DVR 6.9 DVR RWD(Rewind) Bookmark When playing the file, you can press to adjusting the playing speed. <Figure To mark a specific place in a file for later retrieval. <Figure 6.9.8> 6.9.6> - RED : Press this button and red small triangle cursor will be placed at that position. If The speed will change to x2, x4, x8, x16 and x32.
  • Page 27 6.9 DVR 6.9 DVR 3) Instant Recording 4) Timer Recording You can record a current channel by using . If you then press , a time-banner This function is availabe when usb device is connected. You can choose a channel to will be displayed.<Figure 6.9.9>...

  • Page 28: Media

    6.10 MEDIA Troubleshooting Playing Media Files On Your SRT4930: - The SRT4930 is compatible with most PC type media files. There may be various reasons for the abnormal operation of the unit. Therefore, if the unit - These files can be played back on your receiver via the USB ports or SD Card Reader. does not work properly, check it according to the procedures shown in the table below: - To Playback media files, firstly connect the storage device where files are stored.

  • Page 29: Specifications

    Specifications Smart Card Reader 2 Slot Conditional Access Fully DVB compliant System capabilities Interface satellite Connector IEC 169-24, female Power consumption max 30W Power supply Frequency range 950MHz ~ 2150MHz LNB/Tuner input Supply voltage AC 90V ~ 250V Signal level -65dBm ~ -25dBm Supply frequency 50Hz ~ 60Hz...
