Page 1 2012- CAMRY / CAMRY HV TVIP V5 RS3200 PLUS OWNER’S GUIDE RS3200 PLUS SECURITY SYSTEM DESIGNED FOR USE WITH YOUR VEHICLE’S REMOTE KEYLESS ENTRY SYSTEM Owner's Guide 04-16-12 090002-3413A700...
Page 2: Table Of Contents
Page 1 TOYOTA — RS3200 PLUS Security System TABLE OF CONTENTS To better understand the features and functions of this security system, please read this Owner’s Guide completely prior to use. DESCRIPTION PAGE INTRODUCTION BRIEF DESCRIPTION–RS3200 PLUS FEATURES 3, 4...
Page 3: Introduction
Page 2 INTRODUCTION Congratulations on your choice of the RS3200 PLUS add-on security system to protect your vehicle! To get the most from the system, we strongly recommend that you read this Owner’s Guide completely to learn all of its features and functions.
Page 4: Brief Description-Rs3200 Plus Features
TRIGGERING an ALARM. Once the open trunk is closed, the system ARMS again. When you lock the vehicle with the central lock switch (while a door is open), the RS3200 PLUS will ARM 30 seconds after MANUAL ARMING you close all the doors and the trunk (if open).
Page 5: Brief Description–Rs3200 Plus Features
During an ALARM, the RS3200 PLUS activates the vehicle’s HORN horn. ACTIVATION If power to the RS3200 PLUS is disrupted while it is ARMED, an POWER LOSS ALARM is TRIGGERED once power is restored. MEMORY This panel houses the GLASS BREAKAGE SENSOR micro-...
Page 6: Operation
TOYOTA — RS3200 PLUS Security System Page 5 OPERATION ARMING THE RS3200 PLUS The system may be ARMED in several ways. Do one of the following: Lock the doors with your key: Remove the key from the ignition switch. Exit the vehicle, and close all the doors.* Close the trunk or hatch, if necessary.* Insert...
Page 7: Disarming The Rs3200 Plus
TOYOTA — RS3200 PLUS Security System Page 6 OPERATION DISARMING THE RS3200 PLUS The system may be DISARMED in several ways. Do one of the following: Unlock the doors with your key: Insert the key into the door key switch and turn it toward the rear of the vehicle: The STATUS MONITOR’S LED stops flashing.*...
Page 8: Automatic Rearming
When you unlock the doors using the remote control, the RS3200 PLUS is DISARMED at the same time. However, if you do not open a door or the trunk within 30 seconds, the keyless entry system will relock the doors and the RS3200 PLUS will REARM 30 seconds later.
Page 9: Alarm Information
ALARM will be TRIGGERED. STOP “Hot wiring” the vehicle The RS3200 PLUS can detect the absence of the ignition key if the ignition circuit is shorted in attempt to start the vehicle. Tapping on or breaking the glass The noise from tapping on, or breaking of glass TRIGGERS a WARN AWAY ALARM first, then a regular ALARM.
Page 10: Alarm Descriptions
Page 9 TOYOTA — RS3200 PLUS Security System ALARM INFORMATION ALARM DESCRIPTIONS Regular ALARM When an ALARM is triggered in any way other than initial detection by the GLASS BREAKAGE SENSOR, the following occur: The horn sounds repeatedly for 60 seconds.
Page 11: Glass Breakage Sensor Information
“false alarms” from occurring. GLASS BREAKAGE SENSOR CHECK PROCEDURE When the RS3200 PLUS was installed in your vehicle, care was taken to adjust the sensitivity level of the GLASS BREAKAGE SENSOR. You may observe how it works following the procedure listed below.
Page 12: Warning And Caution Information
Page 11 TOYOTA — RS3200 PLUS Security System Warning • This product is applicable only to vehicles with 12V DC, negative grounding specifications. Do not use in vehicles with 24V specifications. Otherwise, damage to the unit or a fire may result.
