- Page 1 Vehicle Security System VSS3 - Vehicle original remote Setting Guide - English...
- Page 2 PIN Code, with a maximum 1.5 second delay between one press and the next. If the LED is already on when the button is pressed, it will go out. Wait for the LED to fl ash indicating that the next digit can be entered. Repeat the process for all four digits. VSS3...
- Page 3 The blinker will fl ash 1x every 12 sec, and the LED will remain ON as confi rmation that you have entered the programming mode. Note: – If the LED does not light ON, withdraw the key from the ignition and repeat the procedure. VSS3...
- Page 4 Turn the key to IG OFF and IG ON again Note: – The Blinkers will fl ash 1x every 10 sec, and the LED will fl ash 1x every 3 sec to confi rm you have reached the Mode 1. VSS3...
- Page 5 • LED fl ashing 1x slow every 3 sec: function is enabled. If you want to change the setting, press and hold the LED push button once. Note: press 6x the LED push button to go to Mode 3.1. VSS3...
- Page 6 If you want to change the setting, press and hold the LED push button 1x. 6 Exit from programming mode Close the bonnet. The blinker will fl ash 5x to confi rm. Note: – You can exit the programming mode at any time by closing the bonnet. VSS3...
- Page 7 7 Programming setting guide diagram VSS3...
- Page 8 1 beep sound if seconds, press the buzzer enabled lock button once again. Summary: Press the remote twice within 30 seconds. Note: – The interior sensor is deactivated once only. Next time the interior sensor will be activated again. VSS3...
- Page 9 30 sec., press the buzzer enabled. lock button again twice. Summary: press the remote 3 times within 30 sec. Note: – The sensor is deactivated for 1 use only. Next time you arm the alarm, the sensor will be activated again. VSS3...
- Page 10 The hazards and LED will give 1 long fl ash and a long beep beep will sound for confi rmation. To exit: 1. Turn IG ON. 2. Long push on the remote unlock button, or on the LED push button. Note: During garage mode, the LED will fl ash at each ignition ON. VSS3...
- Page 11 PZ???-?????-EU Publication no. ASM 000 028-0...
