TP-Link TL-SF1005D Installation Manual

10/100 mbps desktop switch

Hide thumbs Also See for TL-SF1005D:

Download this manual See also: User Manual

Installation Guide

10/100Mbps Desktop Switch

TL-SF1005D/TL-SF1008D

For simplicity, we will take TL-SF1005D for example throughout this Guide.

Connection

Ethernet Ports (1-5)

Router

WAN Port

LAN Port

LED Explanation

Power

Link/Act

On: Power on

Off: Power oﬀ

On: Link present but no activity

Flashing: Transmitting/receiving data

Off: No link

Power Cord

Need help?

Do you have a question about the TL-SF1005D and is the answer not in the manual?

Page 1 Installation Guide Link/Act 10/100Mbps Desktop Switch TL-SF1005D/TL-SF1008D On: Link present but no activity Flashing: Transmitting/receiving data Off: No link For simplicity, we will take TL-SF1005D for example throughout this Guide. Connection Ethernet Ports (1-5) Power Cord Router WAN Port LAN Port...
Page 2: Specifications
No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as 1) This device may not cause harmful interference. translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2016 2) This device must accept any interference received, including interference that may cause undesired TP-LINK TECHNOLOGIES CO., LTD.
