Installation Guide
10/100 Mbps Desktop Switch
For simplicity, we will take TL-SF1005D for example throughout this Guide.
Connection
Ethernet Ports (1-5)
Router
WAN Port
LAN Port
LED Explanation
Power
On:
Power on
Off:
Power off
Link/Act
On:
Link present but no activity
Flashing:
Transmitting/receiving data
Off:
No link
PC
PC
Power Adapter
