TP-Link TL-SF1005D Installation Manual
10/100 mbps desktop switch
Hide thumbs
Also See for TL-SF1005D:
- Installation manual (56 pages) ,
- User manual (4 pages) ,
- Specifications (2 pages)
Advertisement
Quick Links
Installation Guide
10/100Mbps Desktop Switch
TL-SF1005D/TL-SF1008D
TL-SF1016D/TL-SF1024M
Package Contents: Switch, Power Adapter and Installation Guide.
Connection
For simplicity, we will take TL-SF1005D for example throughout this Guide.
Ethernet Ports (1-5)
WAN Port
All manuals and user guides at all-guidesbox.com
Router
LAN Port
LED Explanation
Power
On:
Power on
Off:
Power off
Link/Act
On:
Link present but no activity
Flashing:
Transmitting/receiving data
Off:
No link
PC
PC
Power Cord
