SILENT AIR COMPRESSOR
MODEL NO: SHHHAIR 100/24, 100/50, 150/100
PART NO: 2320880, 2320885, 2320890,
OPERATION & MAINTENANCE
INSTRUCTIONS
LS0416

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SHHHAIR 100/50 and is the answer not in the manual?

Questions and answers

Summary of Contents for Clarke SHHHAIR 100/50

  • Page 1 SILENT AIR COMPRESSOR MODEL NO: SHHHAIR 100/24, 100/50, 150/100 PART NO: 2320880, 2320885, 2320890, OPERATION & MAINTENANCE INSTRUCTIONS LS0416...
  • Page 3: Environmental Recycling Policy

    INTRODUCTION Thank you for purchasing this CLARKE Silent Air Compressor. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
  • Page 4: Safety Precautions

    2. DO NOT operate your compressor with any guards removed. 3. Electrical or mechanical repairs should only be carried out by a qualified engineer. If problems occur, contact your Clarke dealer. 4. Before carrying out any maintenance, ensure the pressure is expelled from the air receiver, and the machine is disconnected from the mains supply.
  • Page 5: Electrical Connections

    ELECTRICAL CONNECTIONS Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply through an approved 13 amp BS 1363 plug, or a suitably fused isolator switch. WARNING: THIS APPLIANCE MUST BE EARTHED IMPORTANT: The wires in the mains lead are coloured in accordance with the following code: Green &...
  • Page 6: Preparing For Use

    1. Make sure that the oil level is half way up the oil sight glass. 2. If not, remove the oil cap and top up the reservoir. • Only use Clarke synthetic compressor oil, available from your Clarke dealer (Part No. 3050795).
  • Page 7: Switching The Air Compressor On

    SWITCHING THE AIR COMPRESSOR ON 1. To start the compressor, turn the ON/OFF switch to the ‘I’ (ON) position - the motor should start immediately. NOTE: If the motor fails to start immediately, the air receiver may already be full of air. Check the tank pressure gauge (shown on the right).
  • Page 8: Shutting Down The Compressor

    NOTE: If the machine pumps continuously without cutting out then the compressor is too small for the application/tool being used, and damage may result. Consult your Clarke dealer. NOTE: DO NOT exceed the duty cycle for the machine (see Specifications).
  • Page 9: Draining The Tank

    DRAINING THE TANK 1. Pressurise the reservoir slightly and then turn the compressor off. 2. If supplied, attach the small hose to the vent valve. • On the SHHH AIR 100/50 and SHHH AIR 150/100 the vent valve is located on the bottom of the reservoir tank. •...
  • Page 10: Troubleshooting

    TROUBLESHOOTING PROBLEM PROBABLE CAUSE REMEDY The compressor will not start, or Bad connections Check the electrical stops and will not start again connections Blown fuse Replace fuse Overload cutout switch has Wait 25-20 mins before tripped attempting to restart Compressor does not start Air receiver charged Open drain valve to expel air.
  • Page 11: Maintenance

    MAINTENANCE Once Once Daily a Year Month Check the oil level, See “Adding Oil” on page 6. Drain the water collected in the air outlet filter. See “Draining the Tank” on page 9. Remove the condensate that has collected in the air tank.
  • Page 12: Replacing The Air Outlet Filter

    CHECK THE NON RETURN VALVES If the tank pressure decreases for no apparent reason, it is possible that the non-return valve is leaking. To check, ensure the tank is under pressure and the machine switched OFF, 1. Take off the flexible hose and check if air leaks out from the valve. 2.
  • Page 13: Specifications

    1500mL Synthetic Oil Part No. 3050795 3050795 3050795 Please note that the details and specifications contained herein, are correct at the time of going to print. CLARKE International reserve the right to change specifications at any time without prior notice.
  • Page 14 EXPLODED DIAGRAM & PARTS LIST...
  • Page 15 EXPLODED DIAGRAM & PARTS LIST...
  • Page 16 EXPLODED DIAGRAM & PARTS LIST...
  • Page 17 EXPLODED DIAGRAM & PARTS LIST...
  • Page 18: Exploded Diagram And Parts List

    EXPLODED DIAGRAM & PARTS LIST DESCRIPTION DESCRIPTION C0037 Screw TCEI 6X20 C0247 Air Hose C0106 Spacer T21 C0292 Air Pipe MM 260 1/8FX1/8F Rotable C0109 Capacitor Bracket C0295 Air Pipe MM 300 1/8FX1/8F Rotable C0111 Overload Protector T2134A (230V) C0294 Air Hose C0112 Start Relay T21 ( 230V )
  • Page 19: Declaration Of Conformity

    DECLARATION OF CONFORMITY...
