Summary of Contents for Clarke 2242119
- Page 1 100L AIR COMPRESSOR MODEL NO: RAIDER 15/1050 PART NO: 2242119 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS LS0520 - ISS 1...
-
Page 2: Environmental Recycling Policy
INTRODUCTION Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: Safety Precautions
2. DO NOT operate your compressor with the guard removed. 3. Repairs must only be carried out by a qualified engineer. If problems occur, contact your local CLARKE dealer. 4. Before carrying out any maintenance, make sure that the pressure is released from the air tank and that the compressor is disconnected from the electrical supply. -
Page 4: Safety Symbols
SAFETY SYMBOLS Read this instruction booklet carefully before positioning, operating or adjusting the compressor. This compressor contains surfaces which may reach a high temperature during operation. Never operate with the motor housing removed. Wear safety goggles when using this compressor Wear ear protectors when using this compressor This compressor produces a high sound level during operation. -
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply through an approved 13 amp BS 1363 plug, or a suitably fused isolator switch. If the plug has to be changed because it is not suitable for your socket, or because of damage, it must be removed and a replacement fitted, following the wiring instructions shown below. -
Page 6: Attach The Wheels
ASSEMBLY ATTACH THE WHEELS 1. Use a suitable spanner and screwdriver to attach the wheels to the compressor. • Use the washers and spring washer in the positions shown. ATTACH THE FEET 1. Insert the feet into the position shown. 2. -
Page 7: Install The Oil Breather Cap
INSTALL THE OIL BREATHER CAP 1. Remove the travel plug. 2. Insert the oil breather cap. MOVING THE AIR COMPRESSOR CAUTION: THE COMPRESSOR IS HEAVY AND REQUIRES TWO PEOPLE TO LIFT SAFELY. • Stop the compressor and disconnect it from the power supply before you move it. -
Page 8: Before Use
2. If not, remove the oil cap and add oil to the crankcase. • Only use SAE30 compressor oil, available from your CLARKE dealer. • Only fill to the half way point on the sight glass, overfilling may result in damage. -
Page 9: Operation
OPERATION If the compressor has not been used for more than 24 hours, open the drain valve (on the bottom of the tank) and drain any condensate which has collected. See page 12. ATTACHING AIR TOOLS WARNING: BEFORE CONNECTING AIR TOOLS, MAKE SURE THAT YOU READ THE INSTRUCTIONS SUPPLIED WITH THE TOOL, ALSO ENSURE THAT THE TOOL IS SUITABLE FOR USE WITH THE COMPRESSOR AND HOSE SPECIFICATIONS. -
Page 10: Check The Safety Valve
CHECK THE SAFETY VALVE To make sure that the safety valve works correctly: 1. Pull on the ring attached. • Air will be released when you pull on the ring and stop when you release the ring. 2. If the valve does not operate, do not use the compressor. -
Page 11: Remove Tools From The Air Hose
REMOVE TOOLS FROM THE AIR HOSE WARNING: ALWAYS SET THE PRESSURE REGULATOR TO ZERO BEFORE YOU REMOVE OR REPLACE A TOOL. 1. Push down on the On/Off button to stop the compressor. 2. Turn the outlet valve handle to the closed position. -
Page 12: Draining The Tank
DRAINING THE TANK CAUTION: YOU MUST DRAIN THE MOISTURE FROM THE TANK AFTER EACH DAYS USE AND BEFORE YOU PUT YOUR COMPRESSOR INTO STORAGE. 1. Turn the compressor off and disconnect from the power supply. 2. Slowly open one of the outlet valves to depressurise the tank. -
Page 13: Maintenance
MAINTENANCE CHECKING THE OIL LEVEL (DAILY) 1. Make sure that the oil level is half way up the oil sight glass. 2. If not, remove the oil breather cap and add oil to the reservoir. • Only use SAE30 compressor oil, available from your dealer. -
Page 14: Check The Non-Return Valve (Every 6 Months)
CHECK THE NON-RETURN VALVE (EVERY 6 MONTHS) If the tank pressure decreases for no apparent reason, it is possible that the non-return valve is leaking. To check, 1. Make sure that the tank is not under pressure and the compressor is switched OFF. 2. -
Page 15: Troubleshooting
TROUBLESHOOTING CAUTION: DO NOT TRY TO REPAIR OR ADJUSTMENT IF YOU ARE UNCERTAIN. IF YOU HAVE ANY QUERIES, CONTACT YOUR DEALER. PROBLEM PROBABLE CAUSE REMEDY The compressor Bad electrical connections. 1. Check electrical connections. has stopped and 2. Clean and tighten if necessary. does not start. -
Page 16: Exploded Diagram
EXPLODED DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 17: Parts List
PARTS LIST CAPACITOR CRANKCASE BOLT BOLT FLAT WASHER CRANKSHAFT SHROUD FLAT WASHER CIRCLIP BOLT OUTSIDE BACK COVER FLAT WASHER BOLT BEARING SEAT OIL SEAL GASKET BEARING FRONT COVER CENTRIFUGAL SWITCH OIL SIGHTGLASS SEAL CENTRIFUGAL FILM OIL SIGHTGLASS OUTSIDE FRONT COVER BOLT STATOR OIL BREATHER... -
Page 18: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 19 DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
