Polycom SoundStation IP 7000 Setup Manual page 10

Setup Guide for the Polycom SoundStation IP 7000 Phone
Note
1 - 4
Connecting Your Phone Using a Power over Ethernet Source
Power over Ethernet is the default connection for your phone.
AC power adapters are not included in the PoE package. If you require one, see
your system administrator.
The following figure shows how to connect your phone to the network using
a PoE source.
1
To connect your phone using a PoE source:
1. Connect the 25-foot Network Cable to the LAN jack on your phone.
2. Connect the other end of the 25-foot Network Cable to an available
LAN port on the wall or hub/switch device port.
Connecting Your Phone Using AC Power (One Phone)
If a PoE source is not available, connect your phone to an AC power source. To
connect your phone to an AC power source, make sure you have the optional
AC Power Kit (containing a Power Adapter, Regional Power Cord, and a
Power Insertion Cable).
2
25-foot Network Cable
