In-ceiling Housing
Installation Manual
SHD-3000F

Advertisement

Table of Contents
loading

  Also See for Samsung SHD-3000F

  Related Manuals for Samsung SHD-3000F

  Summary of Contents for Samsung SHD-3000F

  • Page 1 In-ceiling Housing Installation Manual SHD-3000F...
  • Page 2: Table Of Contents

    Table Of COnTenTS Overview What’s Included Installation Instructions Installation (indoor type) Installation (outdoor type) Product Specifications _ SHD-3000F...
  • Page 3: Overview

    This In-CEILING HOUSING is a mounting ADAPTOR that is designed to mount the smart dome camera in built-in style on a double-layer ceiling. whaT’S InCluded HOUSING SAFETY BRACKET (1EA) SAFETY WIRE (1SET) outdoor type (3EA) Lower bracket (exclusively for TEMPLATE (1EA) indoor dome cameras) (1EA) indoor type (2EA) In-ceiling Housing Installation Manual SHD-3000F INSTALLATION MANUAL SHD-3000F _3...
  • Page 4: Installation Instructions

    Remove the round filling (“C”) from the TEMPLATE. ❶ Place TeMPlaTe A onto the CeIlInG bOard to which you will attach the ceiling mount ADAPTOR and drill a hole of Ø198mm in diameter. See the figure below for the hole shape. CEILING BOARD TEMPLATE _ SHD-3000F...
  • Page 5 Refer to the installation manual of the camera that you want to install, and prepare necessary cables for camera connection. HOUSING CEILING HOUSING Hole 그 External Cable SHD-3000F _...
  • Page 6 Ensure that the HOUSING is firmly secured to the CEILING BOARD. BRACKET BRACKET HOUSING BRACKET BRACKET <A> <B> SCREW Turn clockwise Combine the dome camera and the bracket using two screws. ※ Lower bracket is exclusively for indoor use. _ SHD-3000F...
  • Page 7 Insert the bracket where the camera is mounted into the housing and fix it by turning it in the lOCK direction. When the installation is completed, remove both PROTECTIVE TAPE and PRETOECTIVE COVER from the lens. CEILING 그 HOUSING Attach the COver to the hOuSInG. HOUSING Cover SHD-3000F _...
  • Page 8: Installation (Outdoor Type)

    Hook and fix the other end of SafeTY wIre onto the hOuSInG as shown below: Nut (N1) ANCHOR BOLT Safety BRACKET Nut (N2,N3) SAFETY WIRE ANCHOR BOLT CEILING CEILING HOUSING  The ANCHOR BOLTs and nuts are optional and not included in the product package. _ SHD-3000F...
  • Page 9 SCREWs (x2) clockwise to fix the HOUSING on the CEILING. (The braCKeT will be positioned from <A> to <B> as shown.) Ensure that the HOUSING is firmly secured to the CEILING BOARD. BRACKET BRACKET HOUSING BRACKET BRACKET <A> <B> SCREW Turn clockwise SHD-3000F _...
  • Page 10 If waterproofing in the connected cable jacket is poor, it may cause leaks. Make sure you tape it tight and thoroughly. The butyl rubber tape for waterproofing can extend at least twice as long as the original length. 함 10_ SHD-3000F...
  • Page 11 ※ When attaching the camera to the mount, check the arrow directions in the figure below before proceeding. Remove the dome cover from the camera, and install the cover onto the HOUSING. CEILING HOUSING 그 HOUSING 그  Assemble the network cable through the Cover hole on the bottom part of the housing. SHD-3000F _11...
  • Page 12: Product Specifications

    PrOduCT SPeCIfICaTIOnS Item Specifications D224 X H106.9 Dimension (mm) 490g Weight -10℃ ~ 50℃ Temperature Material Color Ivory 1_ SHD-3000F...
  • Page 13 MEMO SHD-3000F _13...
  • Page 14 SAMSUNG TECHWIN EUROPE LTD. • • 100 Challenger Rd. Suite 700 Ridgefield Park, NJ 07660 Samsung House, 1000 Hillswood Drive, Hillswood Business Toll Free : +1-877-213-1222 Direct : +1-201-325-6920 Park Chertsey, Surrey, UNITED KINGDOM KT16 OPS Fax : +1-201-373-0124 TEL : +44-1932-45-5300 FAX : +44-1932-45-5325 www.samsungcctvusa.com...
