Mirroring; Tie-Off Options - Pfaff expression line Owner's Manual

Mirroring

To mirror stitches or sequences side to side, press
the mirror side to side button.
For 4.0: To mirror end to end, press the mirror end
to end button.

Tie-off options

The tie-off options let you program tie-offs both at
the beginning (A) and the end (B) of the stitch.
1. Press the F2 button (F1 for 2.0) to open the tie-
off options view.
2. Use the wheel to step between the options and
press OK to select which functions you want
to use.
3. When you have made your selections, close the
view by pressing the F2 button (F1 button for
2.0) again. Tie-off mini icons (D) will be shown
on the graphic display, indicating which tie-
off functions are selected. The selections will
remain until you deselect them.
Note: For immediate tie-off, use the tie-off button, found
on the front of the machine.
Sewing with tie-off options selected
1. The tie-off beginning (A) will be performed as
soon as you start to sew.
2. Press the reverse button to activate tie-off end
(B). The programmed tie-off indicator will be
lit. The machine will nish the stitch and do a
tie-off.
For 4.0: When a thread snip (C) is
programmed, the machine will automatically
cut the threads after performing the tie-off
end. The needle and presser foot will raise.
Note: Stop sewing and press the reverse button
twice to activate reverse sewing. The reverse
indicator will be lit. No tie-off will be performed.
Press the reverse button when sewing in reverse to
activate tie-off end. Both the reverse indicator and
the programmed tie-off indicator will be lit.
To go back to sewing forward, stop sewing in
reverse and press the reverse button. No indicators
will be lit and no tie-off will be performed.
3. To deactivate the tie-off options, use the wheel
to step between the options and press OK for
each one to deselect.
D
A B C
3:3
