ADJ FREQ MATRIX User Manual page 8

FREQ Matrix
for Master setting.
1. Press the MENU button until
ENTER.
2.
Press the UP or DOWN buttons until you find your desired show,
press ENTER, then press and hold the MENU button to confirm.
Please see page 9 for more info about Show Mode.
3. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout. See page 15 for UC3
controls and functions.
Manual Mode:
This mode allows a single unit to run a manual set up.
1. Press the MENU button until
ENTER.
2. Either "DIMM" or "STRO" will now be displayed. Press the UP or
DOWN buttons to switch between either setting.
3. When you have decided on what setting you would like to adjust
first, press the ENTER button. Use the UP and DOWN buttons to
make adjustments. Once you have made your desired adjust-
ments press ENTER.
4. Once you have finished with your adjustments DO NOT leave this
submenu. If you press the MENU button, all adjustments will be-
lost and you will have to start over.
5. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout. See page 15 for UC3
controls and functions.
ADJ Products, LLC - www.adj.com - FREQ Matrix Instruction Manual Page 14
Operation
"SHND" is displayed, and press
"MANU" is displayed, and press
FREQ Matrix
Master-Slave Operation:
units together and operate without a controller. In Master-Slave opera-
tion one unit will act as the controlling unit and the others will react to
the controlling units programs. Any unit can act as a Master or as a
Slave.
1. Using appropriate XLR cables, daisy chain your units together via
the XLR connector on the rear of the units. Remember the Male
XLR connector is the input and the Female XLR connector is the
output. The first unit in the chain (master) will use the female XLR
con nector only - The last unit in the chain will use the male XLR
con nector only. For longer cable runs we suggest a terminator at
the last fixture.
2. Set the Master unit to your desired operational mode. After you
have set your desired operational mode, press the MENU button
until "SLND" is displayed, and Press ENTER. Use the UP or
DOWN buttons to find the "MAST" setting and press ENTER.
3. On the slave units
tap the MENU button until "SLND" is display-
ed, and Press ENTER. Use the UP or DOWN buttons to switch
between either "SL 1" or "SL 2". Once you have made your
choice, press ENTER. For more info see page 8.
4. The slave units will now follow the Master unit.
5. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout. See UC3 Control below.
FREQ Matrix
Blackout Blackout the unit
1. Synchronous Strobe by auto.
Function
2. Synchronous Strobe by sound.
Strobe(LED OFF)
Mode
ADJ Products, LLC - www.adj.com - FREQ Matrix Instruction Manual Page 15
Master-Slave Set Up
This function will allow you to link up to 16
UC3 Control
Select Show (Show 1-12).
Show(LED ON)
