• Reorient or relocate the receiving antenna (that is, the antenna for radio or
television that is "receiving" the interference).
• Reorient or relocate and increase the separation between the
telecommunications equipment and receiving antenna.
• Connect the telecommunications equipment into an outlet on a circuit
different from that to which the receiving antenna is connected.
If these measures do not eliminate the interference, please consult your dealer
or an experienced radio/television technician for additional suggestions. Also,
the Federal Communications Commission has prepared a helpful booklet, "How
To Identify and Resolve Radio/TV Interference Problems." This booklet is available
from the U.S. Government Printing Office, Washington, D.C. 20402. Please specify
Call Waiting Caller ID Phone
stock number 004-000-00345-4 when ordering copies.
Notice: The changes or modifications not expressly approved by the party
with 10 Number Memory
responsible for compliance could void the user's authority to operate the
Licensed under US Patent 6,427,009.
This telephone system meets FCC standards for Hearing Aid Compatibility.
CAUTION: When using telephone equipment, there are basic safety
instructions that should always be followed. Refer to the IMPORTANT
SAFETY INSTRUCTIONS provided with this product and save them for
Your Caller ID phone stores and displays specific information, provided by your
local telephone company, to subscribers of Caller ID or similar caller identification
Your Caller ID phone enables you to:
• Identify callers before you answer the phone.
Please read this manual
• View the time and date of each incoming call.
before operating this
• Record up to 75 Caller ID messages sequentially.
product for the first time.
IMPORTANT: In order to use all of the features of this telephone, you must
subscribe to two separate services available from your local telephone
company: the standard Name/Number Caller ID Service to know who is
calling when the phone rings and Caller ID with Call Waiting Service to know
who is calling while you are on the phone.
Your telephone equipment is approved for connection to the Public Switched
Telephone Network and is in compliance with parts 15 and 68, FCC Rules and
Regulations and the Technical Requirements for Telephone Terminal Equipment
Hook switch. The part of the phone that pops up to activate the phone line
published by ACTA.
1 Notification to the Local Telephone Company
On the bottom of this equipment is a label indicating, among other Information,
the US number and Ringer Equivalence Number (REN) for the equipment. You
must, upon request, provide this information to your telephone company.
The REN is useful in determining the number of devices you may connect to
your telephone line and still have all of these devices ring when your telephone
number is called. In most (but not all) areas, the sum of the RENs of all devices
Make sure your package includes the following items:
connected to one line should not exceed 5. To be certain of the number of
devices you may connect to your line as determined by the REN, you should
contact your local telephone company.
A plug and jack used to connect this equipment to the premises wiring and
telephone network must comply with the applicable FCC Part 68 rules and
requirements adopted by the ACTA. A compliant telephone cord and modular
plug is provided with this product. It is designed to be connected to a
compatible modular jack that is also compliant. See installation instructions for
• This equipment may not be used on coin service provided by the telephone
To use this phone, you need an RJ11C type modular telephone
• Party lines are subject to state tariffs, and therefore, you may not be able
jack, which might look like the one pictured here, installed in
to use your own telephone equipment if you are on a party line. Check with
your home. If you don't have a modular jack, call your local
your local telephone company.
phone company to find out how to get one installed.
• Notice must be given to the telephone company upon permanent
disconnection of your telephone from your line.
• If your home has specially wired alarm equipment connected to the
CAUTION: Disconnect the phone cord from the wall outlet before
telephone line, ensure the installation of this product does not disable
installing or replacing the batteries.
your alarm equipment. If you have questions about what will disable alarm
• Never install telephone wiring during a lightning storm.
equipment, consult your telephone company or a qualified installer.
• Never touch uninsulated telephone wires or terminals, unless the telephone line
US NUMBER IS LOCATED ON THE CABINET BOTTOM
has been disconnected at the network interface.
REN NUMBER IS LOCATED ON THE CABINET BOTTOM
• Use caution when installing or modifying telephone lines.
2 Rights of the Telephone Company
• Never install telephone jacks in wet locations unless the jack is specifically
Should your equipment cause trouble on your line which may harm the
designed for wet locations.
telephone network, the telephone company shall, where practicable, notify you
that temporary discontinuance of service may be required. Where prior notice
• Temporarily disconnect any equipment connected to the phone, such as faxes,
is not practicable and the circumstances warrant such action, the telephone
other phones, or modems.
company may temporarily discontinue service immediately. In case of such
temporary discontinuance, the telephone company must: (1) promptly notify
you of such temporary discontinuance; (2) afford you the opportunity to correct
the situation; and (3) inform you of your right to bring a complaint to the
Your Caller ID phone uses 3 AA-size alkaline batteries for receiving and storing
Commission pursuant to procedures set forth in Subpart E of Part 68, FCC Rules
Caller ID records and for storing the numbers you use for memory dialing, pulse
dialing, and redial.
The telephone company may make changes in its communications facilities,
equipment, operations or procedures where such action is required in the
IMPORTANT: You will have approximately 90 seconds to replace the
operation of its business and not inconsistent with FCC Rules and Regulations. If
batteries before the memories stored are lost. Please read the instructions
these changes are expected to affect the use or performance of your telephone
before replacing the batteries and have the batteries ready to be inserted
equipment, the telephone company must give you adequate notice, in writing,
to allow you to maintain uninterrupted service.
IMPORTANT: If you are not going to use the telephone for more than 30
days, remove the batteries because they may leak and damage the unit.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
1. If the telephone line cord is connected,
disconnect it from the base unit.
following two conditions: (1) This device may not cause harmful interference; and
(2) This device must accept any interference received, including interference that
2. Release latch on battery compartment and
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class
3. Insert 3 AA-size alkaline batteries as shown on
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
the diagram in the battery compartments.
to provide reasonable protection against harmful interference in a residential
4. Snap the battery compartment door back into
This equipment generates, uses, and can radiate radio frequency energy and, if
5. If the line cord was previously connected, re-attach it to the unit and check
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
your memory locations.
interference will not occur in a particular installation.
NOTE: If the low battery icon (
If this equipment does cause harmful interference to radio or television reception,
replace the batteries. It is important that you replace the batteries as soon as
which can be determined by turning the equipment off and on, the user is
possible in order to maintain Caller ID operation.
encouraged to try to correct the interference by one or more of the following
Your phone should be placed on a level desktop surface.
1. Connect one end of the coiled handset cord to the jack on the handset.
2. Plug the other end of the coiled handset cord to the jack on the base.
3. Place the handset in the cradle.
101 West 103rd Street
Indianapolis, IN 46290-1102
00005381 (Rev. 3 E/S)
© 2007 Thomson Inc.
Trademark(s) ® Registered
Printed in China
1. Connect one end of the straight telephone line cord to the jack on the
back of the base.
2. Connect the other end to a wall phone jack.
3. Set the RINGER volume switch located at the back of the base to the desired
OFF - Telephone will not ring.
LO - Sound will be lowest.
HI - Sound will be loudest.
NOTE: The unit is properly installed if you pick up the handset and hear the
dial tone. Otherwise, recheck all installation steps.
sed in tHis
You should not plug the telephone into the modular jack while setting up the
Caller ID menu.
1. Press the MENU button to enter the menu feature configuration mode.
when the handset is lifted from the base.
# 1. >ENG FRA ESP (CID language default English)
A term used to describe the phone in active mode when
# 2. CONTRAST (default level is 3).
the handset is off of the base cradle.
# 3. LOCAL AREA CODE
A term used to describe the phone in an inactive mode.
2. Press the MENU button to scroll through the 3 menu screens.
3. Use the 7 or 8 buttons to select the desired setting.
NOTE: You have 10 seconds following an entry before the phone returns to
the Summary Screen.
This adjustment allows you to display the Caller ID prompts in English, French, or
1. Press the MENU button until ENG FRA ESP shows in the display.
2. Use the 7 or 8 buttons to select ENG, FRA or ESP.
3. Press the MENU button again to save.
This adjustment allows you to adjust the contrast of the display.
1. Press the MENU button until CONTRAST shows in the display.
2. Use the 7 or 8 buttons to select level 1, 2, 3, 4, or 5.
3. Press the MENU button again to save.
The telephone uses the programmed area codes to determine the number format
to display when a valid Caller ID signal is received. Numbers that match the local
area code are displayed as seven digits and are used for dialing back previous
numbers. Entering your local area code will also help you immediately know if the
call is local or long distance when viewing the CID records in the display.
NOTE: If you make a mistake and want to start over again, press the DELETE
button to erase all of the digits.
1. Press the MENU button until LOCAL AREA CODE shows in the display.
2. Use the handset number pad to enter your 3-digit area code.
3. Press the MENU button to save.
NOTE: The phone will exit Set Up after 20 seconds if no buttons are pressed.
REMINDER: The time and date are programmed automatically when the first
Caller ID record is successfully received after set up.
id (cid) f
The Summary Screen shows the current time, date, and number of new calls to
review. It is displayed until any button is pressed.
NOTE: The number of new calls is displayed until all new calls have been
The new call indicator flashes to indicate you have new calls.
This unit receives and displays information transmitted by your local phone company.
This information can include the phone number, date, and time; or the name, phone
number, date, and time. The unit can store up to 75 calls for later review. When the
memory is full, a new call automatically replaces the oldest call in memory. NEW
appears in the display for calls received that have not been reviewed.
• Press the 7 or 8 buttons to view the call records.
• Press the 7 button to scroll through the call records from the most recent to
) appears in the display, you need to
• Press the 8 button to scroll through the call records from the oldest to the
• When all of the records have been viewed, START/END appears in the display.
• To delete the record shown in the display, press the DELETE button once.
• To delete all records while reviewing, press and hold the DELETE button for
about three seconds. DELETE ALL? appears in the display. Press DELETE again to
When reviewing Caller ID records, you can dialback the numbers on the display by
pressing the DIAL button.
NOTE: If PICKUP PHONE shows in the display, no other changes to the number
can be made. The information sent from the telephone company is known to
be a valid number for dialing back (used only in very limited areas). Once you
pickup the phone, the number is automatically dialed.
1. Use the 7 or 8 buttons to display the number you want to dial.
2. Press the DIAL button.
• If you see a number with seven digits (i.e. 555-1234), then the call is from within
your area code. However, this does not guarantee the call is a local call.
• If you see a number with 11 digits (i.e. 1-234-555-1234), then the call is not
from within your area code.
NOTE: A timer (10 seconds on-hook and 3 seconds off-hook) located in the
upper right side of the display will start, letting you know how much time is
left until the unit returns to the Summary Screen.
3. If the phone is on-hook and PICKUP OR ADJ displays, you can adjust the
phone number format by pressing the DIAL button. If the phone is off-hook
and ADJUST shows in the display, you can adjust the phone number format
by pressing the DIAL button. For example, sometimes a 7-digit local number
cannot be dialed because it requires a 10-digit or 11-digit format. Press the
DIAL button repeatedly to scroll through the 7, 10, and 11-digit numbers.
7-digits: 7-digit telephone number (i.e. 555-5555)
10-digits: 3-digit area code + 7-digit telephone number (i.e. 425-555-5555)
11-digits: long distance code 1 + 3-digit area code + 7-digit telephone number
4. To dial the displayed number, and the phone is on-hook, pick up the handset
before the timer reaches 0. If the phone is off-hook, wait until the time reaches
0. NOW DIALING shows in the display and the number is dialed.
1. Use the 7 or 8 buttons to display the number you want to dial. You will only
see 10-digit numbers (i.e. 234- 555-1234).
2. See steps 2 through 4 in the previous section to complete the dialback
(Caller ID button)
The following special messages indicate the status of a message or the unit:
The caller of the incoming call is registered as "Private
Number" and their Caller ID information is withheld.
Indicates a call is waiting on the line.
Battery power level is low.
The caller memory is empty.
You are at the beginning or the end of the Caller ID
The incoming call does not have Caller ID service or their
service area is not linked to yours. If UNKNOWN
CALLER appears along with a calling number, the name
information for that number was not available.
You may adjust the handset volume with the 3 level VOLUME switch located on
the back of the unit.
You may redial the last number you called by pressing the REDIAL button after you
hear a dial tone.
NOTE: The redial feature holds the last number (up to 32 digits) that you
dialed in memory. If you pressed any other numbers after dialing the phone
number (for example, when accessing a voice-menu system) then those
numbers are also dialed.
Press FLASH to activate special features of your telephone network, such as call
transfer, or special services from your local telephone company, such as call
If you have pulse (rotary) service and want to access customer calling services
(such as telebanking and long distance services) that require tone dialing, you can
use this feature to temporarily change from pulse to tone service.
After dialing the telephone number and connecting to the customer calling
1. Press and release the TONE (*) button.
2. W hen you hang up, the telephone automatically returns to pulse dialing mode.
TIP: Temporary Tone can also be used while storing numbers in memory by
pressing TONE (*) at the necessary point in the storage sequence.
You may store information in any of the following memory locations: 0 to 9. See
"Storing a Pause in Memory" and "Temporary Tone Dialing" for more information.
1. Press the STORE button. LOCATION? shows in the display.
2. Press the desired memory location (0-9).
NOTE: You may select memory locations by pressing
the memory locations or press the 0 - 9.
3. Press the STORE button again to confirm the memory location.
NOTE: If necessary, to erase existing memories, or if you make a mistake, use
the DELETE button.
4. Use the number keys to enter the telephone number (up to 32 digits) and press
the STORE button to save. (The unit will not dial a phone number in this mode.)
The cursor automatically moves to the text line for name entry.
5. Use the number keys to enter the name of the person associated with the
telephone number you just entered. More than one letter is stored in each of
the number keys.
For example, to enter the name BILL SMITH, press the 2 key twice for the letter
B. Press the 4 key 3 times for the letter I. Press the 5 key 3 times for the letter L.
NOTE: The flashing cursor automatically moves to the next position or you
may press the
buttons to move the cursor to the next position.
Press the 5 key 3 times for the second letter L. Press the 1 key once to insert a
space, and press the 7 key 4 times for the letter S. Press the 6 key once for the
letter M. Press the 4 key 3 times for the letter I. Press the 8 key for the letter T.
Press the 4 key twice for the letter H.
6. Press the STORE button to save the name.
7. To enter another name and number in a different memory location,
return to step 1 and repeat the process.
Repeat the storage sequence under Storing A Name and Number in Memory, and
use the DELETE button to delete the old number before entering the new number.
1. Press the STORE button.
2. Press the memory location (0-9) to be erased.
3. Press the DELETE button.
1. P ress the 7 or 8 buttons to view the caller number and name you want to
2. P ress the STORE button.
3. P ress the memory location (0-9). The number flashes if there is a number
already stored in the memory location.
4. P ress the STORE button to enter the edit mode, and then press the STORE
button again to edit the name.
NOTE: You may select a different memory location by pressing
scroll through the memories or press a number key (0-9).
5. P ress the STORE button to confirm and save, and wait for three seconds to exit.
NOTE: If the name you want to enter is longer than 12 characters, only the
first 12 characters will be copied into memory.
1. P ress the REDIAL button while the phone is on-hook. The display shows PICKUP
2. P ress the STORE button.
3. P ress any number key (0-9) for the memory location.
4. P ress the STORE button twice to edit the name.
5. Press the STORE button again to save the edit. The phone will confirm and exit
the memory menu.
When phone is on-hook:
1. Press the MEM button
2. T o select a memory, press any number key (0-9) or use the 7 or 8 buttons
until the desired phone number is on the display.
3. Pick up the handset and the phone will automatically dial the number.
When phone is off-hook:
1. Lift the handset.
2. P ress the MEM button.
3. T o select a memory, press any number key (0-9) and the phone will
automatically dial the number.
use the 7 or 8 buttons until the desired phone number is on the display. Press
the DIAL button and the phone will automatically dial the number.
This process allows you to dial a succession of stored numbers from separate
memory locations. This is useful when you must dial several sequences of numbers,
such as with frequent calls via a telephone company long distance provider.
Local access number of long distance company
Authorization code (ID)
Long distance phone number
1. Pick up the handset.
2. Press MEM button, then press number "6" for the memory location.
3. Press MEM button, then press number "7" for the memory location.
4. Press MEM button, then press number "8" for the memory location.
5. The number dials automatically.
The REDIAL button has dual functionality and becomes a pause button when the
STORE button is pressed first. It is valid only when storing a number into memory
locations. Use the PAUSE (REDIAL) button to insert a pause when a delay is needed
in an automatic dialing sequence. For example, when you must dial a 9 to get an
outside line or when you enter codes to access your long distance company.
1. W ith the handset on the cradle, enter the telephone number you wish to call.
The telephone number shows in the display.
2. L ift the handset and the number automatically dials.
NOTE: Use the DELETE button to delete an incorrectly entered number.
No Dial Tone
• Check all cabling to make sure that all connections are secure and not damaged.
• Check hook switch: Does it fully extend when handset is lifted from cradle?
• Replace the batteries.
• Check for proper battery installation.
No Information is Shown After the Phone Rings
• Are you subscribed to Caller ID service from your local telephone company?
• Be sure to wait until the second ring before answering.
to scroll through
Phone Does Not Ring
• Make sure ringer switch is ON.
• You may have too many extension phones on your line. Try unplugging some
• Check for dial tone. See Troubleshooting Tips for No Dial Tone.
Incoming Voice Volume Low
• Are other phones off hook at same time? If so, this is normal condition as
volume drops when additional phones are used at once.
• Check the receiver volume located at the back of unit.
• Make sure you entered the numbers correctly into memory.
To keep your phone working and looking good, follow these guidelines:
• Avoid putting it near heating appliances and devices that generate electrical
noise (for example, motors or fluorescent lamps).
• DO NOT expose to direct sunlight or moisture.
• Avoid dropping and other rough treatment to the unit.
• Clean with a soft cloth.
• Never use a strong cleaning agent or abrasive powder because this will damage
• Retain the original packaging in case you need to ship it at a later date.
If trouble is experienced with this equipment, for repair or warranty information,
please contact customer service at 1-800-511-3180. If the equipment is causing
harm to the telephone network, the telephone company may request that you
disconnect the equipment until the problem is resolved.
This product may be serviced only by the manufacturer or its authorized service
agents. Changes or modifications not expressly approved by Thomson Inc. could
void the user's authority to operate this product. For instructions on how to obtain
service, refer to the warranty included in this guide or call customer service at
Or refer inquiries to:
Manager, Consumer Relations
P O Box 1976
Indianapolis, IN 46206
Attach your sales receipt to the booklet for future reference or jot down the date
this product was purchased or received as a gift. This information will be valuable
if service should be required during the warranty period.
Purchase date ________________________________________________
Name of store ________________________________________________
What your warranty covers:
Defects in materials or workmanship.
For how long after your purchase:
One year, from date of purchase.
(The warranty period for rental units begins with the first rental or 45 days from date of shipment
to the rental firm, whichever comes first.)
What we will do:
Provide you with a new or, at our option, a refurbished unit. The exchange unit is under warranty
for the remainder of the original product's warranty period.
How you get service:
Properly pack your unit. Include any cables, etc., which were originally provided with the
product. We recommend using the original carton and packing materials.
"Proof of purchase in the form of a bill of sale or receipted invoice which is evidence that the
product is within the warranty period, must be presented to obtain warranty service." For rental
firms, proof of first rental is also required. Also print your name and address and a description of
the defect. Send via standard UPS or its equivalent to:
11721 B Alameda Ave.
Socorro, Texas 79927
Pay any charges billed to you by the Exchange Center for service not covered by the warranty.
Insure your shipment for loss or damage. Thomson Inc. accepts no liability in case of damage or
A new or refurbished unit will be shipped to you freight prepaid.
What your warranty does not cover:
Customer instruction. (Your Owner's Manual provides information regarding operating
instructions and user controls. Any additional information, should be obtained from your dealer.)
Installation and setup service adjustments.
Damage from misuse or neglect.
Products which have been modified or incorporated into other products.
Products purchased or serviced outside the USA.
Acts of nature, such as but not limited to lightning damage.
Please complete and mail the Product Registration Card packed with your unit. It will make
it easier to contact you should it ever be necessary. The return of the card is not required for
Limitation of Warranty:
ThE WARRAnTY STATED ABOvE IS ThE OnlY WARRAnTY APPlICABlE TO ThIS PRODUCT.
All OThER WARRAnTIES, ExPRESS OR IMPlIED (InClUDIng All IMPlIED WARRAnTIES OF
MERChAnTABIlITY OR FITnESS FOR A PARTICUlAR PURPOSE) ARE hEREBY DISClAIMED. nO
vERBAl OR WRITTEn InFORMATIOn gIvEn BY ThOMSOn InC., ITS AgEnTS, OR EMPlOYEES
ShAll CREATE A gUARAnTY OR In AnY WAY InCREASE ThE SCOPE OF ThIS WARRAnTY.
REPAIR OR REPlACEMEnT AS PROvIDED UnDER ThIS WARRAnTY IS ThE ExClUSIvE
REMEDY OF ThE COnSUMER. ThOMSOn InC. ShAll nOT BE lIABlE FOR InCIDEnTAl OR
COnSEqUEnTIAl DAMAgES RESUlTIng FROM ThE USE OF ThIS PRODUCT OR ARISIng
OUT OF AnY BREACh OF AnY ExPRESS OR IMPlIED WARRAnTY On ThIS PRODUCT. ThIS
DISClAIMER OF WARRAnTIES AnD lIMITED WARRAnTY ARE gOvERnED BY ThE lAWS OF
ThE STATE OF InDIAnA. ExCEPT TO ThE ExTEnT PROhIBITED BY APPlICABlE lAW, AnY
IMPlIED WARRAnTY OF MERChAnTABIlITY OR FITnESS FOR A PARTICUlAR PURPOSE On
ThIS PRODUCT IS lIMITED TO ThE APPlICABlE WARRAnTY PERIOD SET FORTh ABOvE.
How state law relates to this warranty:
Some states do not allow the exclusion nor limitation of incidental or consequential damages, or
limitations on how long an implied warranty lasts so the above limitations or exclusions may not
apply to you.
This warranty gives you specific legal rights, and you also may have other rights that vary from
state to state.
If you purchased your product outside the USA:
This warranty does not apply. Contact your dealer for warranty information.
Visit the RCA web site at www.rca.com
Please do not send any products to the Indianapolis address listed in this manual
or on the carton. This will only add delays in service for your product.
