- Page 1 Montageanweisungen Instructions for use and installation instructions Instructions d’ utilisation et avis de montage Gebruiksaanwijzing en montagehandleiding Istruzioni di uso e di montaggio Instrucciones de uso y de montaje Instruções de uso e de montagem KD 934.1 / 634.1...
-
Page 2: Table Of Contents
Installation preconditions Mounting a steel rear panel (optional) Attaching wall hooks and chimney support Fitting the hood Ducting and chimney attachment Fitting the grease filters Guideline for extraction paths..18 KD 934.1 / KD634.1... -
Page 3: Safety Instructions
The room Moisture — If the cooker hood is only used in recirculation mode - with activated air is cle- Heat — charcoal filters - there are no restrictions on operation aned of Odours KD 934.1 / KD 634.1... -
Page 4: Your Appliance At A Glance
The lighting can be used independently of the ventilation. The left hand switch turns the – lighting on. Press again to switch the lighting – off. Switching on the ventilation Press button 0-1 in order to – switch the hood on. KD 934.1 / KD634.1... -
Page 5: Cleaning, Care And Maintenance
They will then click into place. Remove the halogen bulb from its socket. – Hold the new bulb (20 watt) with a cloth and push into the socket. – Close the light cover. – KD 934.1 / KD 634.1... -
Page 6: What To Do If Trouble Occurs
20 mm thick. For solid concrete walls you must use special concrete dowels from a specialist store. For solid wooden walls you must use wood screws of sufficient thick- ness and length. KD 934.1 / KD634.1... -
Page 7: Mounting A Steel Rear Panel (Optional)
The rear panel must rest on the worktop. Screw in the chimney support tightly. – Remove the metal-mesh grease filter from the hood. – Guide the power cable through the opening in the rear panel and screw – on the panel. KD 934.1 / KD 634.1... -
Page 8: Fitting The Hood
Arrange the chimney sections inside one another. For recirculation mode, – the venting slots must be located at the top in the upper section, for ex- traction mode, they are concealed at the bottom. Recirculation mode Extraction mode KD 934.1 / KD634.1... -
Page 9: Guideline For Extraction Paths
The exhaust air must only be introduced into an existing exhaust shaft if this is insulated against damp and is not already used for fuel purposes. Have the chimney sweep responsible approve the use of the shaft. KD 934.1 / KD 634.1...
