- Page 1 Bedienungsanleitung Instructions Booklet Mode d’emploi Libretto Istruzioni Gebruiksaanwijzing Manual de instrucciones Manual de instruções KD 9550 KD 9550 KD 9550 KD 9550 KD 9550...
- Page 2 Dear Customer, If you follow the recommendations contained in this Instruction Manual, your appliance will give you constant high performance and will remain efficient for many years to come. CONTENTS RECOMMENDATIONS AND SUGGESTIONS CHARACTERISTICS INSTALLATION MAINTENANCE...
-
Page 3: Recommendations And Suggestions
RECOMMENDATIONS AND SUGGESTIONS INSTALLATION • The manufacturer will not be held liable for any damages resulting from incorrect or improper installation. • Check that the mains voltage corresponds to that indicated on the rating plate fixed to the inside of the hood. •... - Page 4 CHARACTERISTICS Dimensions Components Ref. Q.ty Product Components Hood Body, complete with: Controls, Light, Blower, Filters Directional Air Outlet grille Filter cover Ref. Q.ty Installation Components Wall Plugs Wall Plugs SB 12/10 Screws 4,2 x 44,4 Screws 2,9 x 6,5 Screws 2,9 x 9,5 Q.ty Documentation Instruction Manual...
-
Page 5: Installation
INSTALLATION Wall drilling and bracket fixing On the wall, draw • a Vertical line up to the ceiling or upper limit, at the centre of the area in which the Hood is to be fitted; • a Horizontal line at a minimum of 960 mm above the Cooker Top. •... -
Page 6: Mounting The Hood Body
Mounting the hood body • Open the ducting panels. • Disconnect the panel from the hood canopy by sliding the fixing pin lever.(A) • Remove the metal grease filters by turning the handles provided. • Adjust the two screws Vr, on brackets 11a, to a minimum.(B) •... -
Page 7: Control Panel
Control Panel The hood can be switched on pushing directly onto the requested speed without firstly having to select 0/1 button. FUNCTIONS 0/1 Light Turns lighting on and off. 0/1 Motor First speed. When pressed for about 1 seconds the motor is switched off. -
Page 8: Maintenance
REMOTE CONTROL (OPTIONAL) The appliance can be controlled using a remote control powered by a 1.5 V carbon-zinc alkaline batteries of the standard LR03-AAA type. • Do not place the remote control near to heat sources. • Used batteries must be disposed of in the proper manner. -
Page 9: Activated Charcoal Filter (Recirculation Version)
Activated charcoal filter (Recirculation version) REPLACING THE ACTIVATED CHARCOAL FILTER • The filter is not washable and cannot be regenerated. It must be replaced when led S1 flashes or at least every 4 months. The alarm signal will only light up when the extractor motor is switched on.
