OPERATION AND PARTS MANUAL
MODEL GA6HZR
PORTABLE GENERATOR
(HONDA GX340 GASOLINE ENGINE)
Revision #3 (03/30/11)
To find the latest revision of this
publication, visit our website at:
www.multiquip.com
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GA6HZR and is the answer not in the manual?

Questions and answers

Related Manuals for MULTIQUIP GA6HZR

Summary of Contents for MULTIQUIP GA6HZR

  • Page 1 OPERATION AND PARTS MANUAL MODEL GA6HZR PORTABLE GENERATOR (HONDA GX340 GASOLINE ENGINE) Revision #3 (03/30/11) To find the latest revision of this publication, visit our website at: www.multiquip.com THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

  • Page 2: Proposition 65 Warning

    PROPOSITION 65 WARNING PAGE 2 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 3 NOTE PAGE GA-6HZR A.C. GENERATOR — OPERATION AND PARTS MANUAL — REV. #3 (03/30/11) — PAGE 3...
  • Page 4 TABLE OF CONTENTS Honda GX340K1EDN2 GA6HZR Portable 60 Hz Engine Generator Cylinder Head Assembly ........36-37 Here's How To Get Help ..........2 Recoil Starter Assembly........38-39 Table Of Contents ............. 3 Fan Cover Assembly ..........40-41 Parts Ordering Procedures ........4 Camshaft/Valves Assembly ........42-43 Rules For Safe Operation .........

  • Page 5: Parts Ordering Procedures

    , 2006 Order via Internet (Dealers Only) Best Deal! If you have an MQ Account, to obtain a Username Order parts on-line using Multiquip’s SmartEquip website! and Password, E-mail us at: parts@multiquip. ■ View Parts Diagrams com. ■ Order Parts To obtain an MQ Account, contact your ■...

  • Page 6: Rules For Safe Operation

    RULES FOR SAFE OPERATION CAUTION: ■ Provide adequate ventilation when operating the generator. DO NOT operate the generator in any enclosed or narrow Failure to follow instructions in this manual space. The generator's gasoline engine gives off DEADLY may lead to serious injury or even death! This carbon monoxide gas.

  • Page 7: Operation And Safety Decals

    OPERATION AND SAFETY DECALS Machine Safety Decals The GA-6HZR portable generator is equipped with a number of safety decals. These decals are provided for operator safety and maintenance information. The illustration below shows these decals as they appear on the machine. Should any of these decals become unreadable, replacements can be obtained from your dealer.
  • Page 9  Slow Down (diode 3) Generator The AC voltage will pass through the excitation diode that The Multiquip Model GA-6HZR generator has been designed converts the voltage to DC power. as a portable lightweight power source for 60 Hz (single-...
  • Page 10 GA-6HZR — CONTROLS AND INDICATORS PARTS NAME CIRCUIT BREAKER AC VOLTMETER IDLE CONTROL SWITCH OPERATION SWITCH 6000 FULL POWER SWITCH RECEPTACLE (250V) RECEPTACLE (120V) GA-6HZR FULL POWER SWITCH POWERED by HONDA GFCI RECEPTACLE (120V) 10 DIPSTICK 11 OIL DRAIN PLUG AC CIRCUIT BREAKER STARTER GRIP AC VOLTMETER...
  • Page 11 GA-6HZR — INSTALLATION Outdoor Installation Indoor Installation Exhaust gases from gasoline engines are extremely Install the generator in a location where it will not be exposed to rain or sunshine. Make sure that the generator is on secure level poisonous. Whenever an engine is installed indoors the ground so that it cannot slide or shift around.
  • Page 12 GA-6HZR — PRE-SETUP General Inspection Prior to Operation Circuit Breaker This generator has been thoroughly inspected and accepted To protect the generator from an overload, a 2-pole 13.5 amp prior to shipment from the factory. However, be sure to check circuit breaker is provided on the control box.
  • Page 13 GA-6HZR — PRE-SETUP Fuel Lubrication Oil Close the fuel cock before filling the tank. Fill the fuel tank Fill the engine crankcase with lubricating oil through the filler with clean and fresh unleaded gasoline. Do not fill the tank hole, but do not overfill. Make sure the generator is level. beyond capacity.
  • Page 14 (low/high RPM's). To prevent phase load. damage to the generator or power tools turn the generator OFF and consult your authorized Multiquip service dealer. PAGE 14 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 15 GA-6HZR — LOAD APPLICATION Single Phase Load CAUTION: Motors and motor-driven equipment draw Always be sure to check the nameplate on the generator much greater current for starting than and equipment to insure the wattage, amperage and during operation. frequency requirements are satisfactorily supplied by the generator for operating the equipment.
  • Page 16 GA-6HZR — OPERATING INSTRUCTIONS Before Starting Warm up 1. Be sure to disconnect the electrical load and switch the 1. When the engine starts, open the choke slowly. main circuit breaker to the “OFF” position prior to starting 2. Run the engine at low speed for 3 minutes without load the engine.
  • Page 17 GA-6HZR — MAINTENANCE General Inspection Service Daily At least daily or prior to each use, the generating set should If engine is operating in very dusty and dry grass conditions. be cleaned and inspected for deficiencies. Check for loose, A clogged air cleaner will result in high fuel consumption, missing or damaged nuts, bolts or other fasteners.
  • Page 18 GA-6HZR — PREPARATION FOR LONG -TERM STORAGE Generator Storage For storage of the generating set for over 30 days, the following is required:  Drain the fuel tank completely.  Run the engine until the gasoline in the carburetor is completely consumed.
  • Page 19 GA-6HZR — WIRING DIAGRAM GA-6HZR A.C. GENERATOR — OPERATION AND PARTS MANUAL — REV. #3 (03/30/11) — PAGE 19...
  • Page 20 GA-6HZR — TROUBLESHOOTING (ENGINE) diagnosis based on the Engine Troubleshooting (Table 5) Practically all breakdowns can be prevented by proper information shown below and on the proceeding page. If the handling and maintenance inspections, but in the event of a problem cannot be remedied, please leave the unit just as it breakdown, please take a remedial action following the is and consult our company's business office or service...
  • Page 21 GA-6HZR — TROUBLESHOOTING (ENGINE) f l a i t c i l o i l o i c i f " i s s a " r i A a t - l i f r e t r i a a t - t l i f .
  • Page 22 GA-6HZR — TROUBLESHOOTING (GENERATOR) diagnosis based on the Generator Troubleshooting (Table 6) Practically all generator breakdowns can be prevented by information shown below and on the preceding page. If the proper handling and maintenance inspections, but in the event problem cannot be remedied, please leave the unit just as it of a breakdown, please take a remedial action following the is and consult our company's business office or service plant.
  • Page 23 GA-6HZR — TROUBLESHOOTING (GENERATOR) i t c r o t t o r . r o i t c . d i V " . " i t c l o r c i v l o r c i v i t c l o r c i v...
  • Page 24 A blank entry generally indicates that the item is not sold assembly/kit that can be purchased, or is not available separately or is not sold by Multiquip. Other entries will for sale through Multiquip. be clarified in the “Remarks” Column.
  • Page 25 GA-6HZR — SUGGESTED SPARE PARTS GA-6HZR1 TO 5 UNITS WITH HONDA GX340K1EDN2 ENGINE 1 to 5 Units Qty. Description 5 .... 9807955846 ..SPARK PLUG 1 .... 15510ZE2W01 ..OIL LEVEL SWITCH 1 .... 15600735700 ..DIPSTICK 1 .... 28400ZEZW01ZB RECOIL STARTER 5 ....
  • Page 26 GA-6HZR — GENERATOR ASSY. GENERATOR ASSY. PAGE 26 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 27 GA-6HZR — GENERATOR ASSY. GENERATOR ASSY. PART NO PART NAME QTY. REMARKS 7901002403 ROTOR ASS’Y 7871080003 FIELD COIL 0601823207 RECTIFIER 0601822638 SURGE ABSORBER 0071706304 BEARING 7901017004 SET BOLT, ROTOR 0801086104 SET WASHER, BEARING 0040010000 SPRING WASHER 7901348603 ARMATURE ASS’Y 79013A15502 END BRACKET 7871315022 END BRACKET...
  • Page 28 GA-6HZR — CONTROL BOX ASSY. CONTROL BOX ASSY. PAGE 28 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 29 GA-6HZR — CONTROL BOX ASSY. CONTROL BOX ASSY. PART NO PART NAME QTY. REMARKS 7911811403 CONTROL BOX 0601850102 GROMMET 0601823853 SLOW DOWN UNIT 0027104010 MACHINE SCREW 0207004000 HEX. NUT 7911821413 CONTROL PANEL 7900501212 NAME PLATE ......... 1 ....S/N 2975451 AND BELOW 7900501222 NAME PLATE .........
  • Page 30 GA-6HZR — PIPE FRAME ASSY. PIPE FRAME ASSY. PAGE 30 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 31 GA-6HZR — PIPE FRAME ASSY. PIPE FRAME ASSY. PART NO PART NAME QTY. REMARKS 7905413002 PIPE FRAME 7905416004 BRACKET 0017106016 HEX. HEAD BOLT 7905443003 BASE 3015419604 RUBBER SUSPENSION 0207008000 HEX. NUT 1725419214 RUBBER SUSPENSION 0207008000 HEX. NUT 0017108030 HEX. HEAD BOLT 0017108040 HEX.
  • Page 32 GA-6HZR — MUFFLER ASSY. MUFFLER ASSY. PAGE 32 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 33 GA-6HZR — MUFFLER ASSY. MUFFLER ASSY. PART NO PART NAME QTY. REMARKS 7912310003 MUFFLER 18320ZC2000 PROTECTOR, MUFFLER ....1 ... REPLACES P/N 0602302001 18325ZB4000 PROTECTOR, MUFFLER ....1 ... REPLACES P/N 0602302002 18329ZB4000 SEAL ..........2 ... REPLACES P/N 0602302003 18355ZB4630 ARRESTER, SPARK .......
  • Page 34 GA-6HZR— NAMEPLATE ASSY. NAMEPLATE ASSY. PAGE 34 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 35 GA-6HZR— NAMEPLATE ASSY. NAMEPLATE ASSY. PART NO PART NAME QTY. REMARKS 0800628504 DECAL : GROUND .......... 1 ..S-1123 1980680004 DECAL : FUEL COCK ........1 ..S-3704 7900638004 DECAL : OPERATING INSTRUCTIONS ..1 ..S-4605 7900501222 DECAL : MQ GA-6HZR 7900681202 DECAL : MQ 6000 ...........
  • Page 36 HONDA GX340K1EDN2 ENGINE — CYLINDER HEAD HONDA GX240K1 ENGINE — CYLINDER HEAD CYLINDER HEAD ASSY. PAGE 36 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 37 HONDA GX340K1EDN2 ENGINE — CYLINDER HEAD CYLINDER HEAD ASSY. PART NO PART NAME QTY. REMARKS 122AOZF6W00 HEAD COMP., CYLNDER ... 1 ..INCLUDES ITEM W/ 12204ZE2325 GUIDE, IN. VALVE (OVER SIZE) 1 12205ZE2315 GUIDE, EX. VALVE (OVER SIZE) 1 12216ZE2300 CLIP, VALVE GUIDE 12251ZE3W00 GASKET, CYLINDER HEAD...
  • Page 38 HONDA GX340K1EDN2 ENGINE — RECOIL STARTER RECOIL STARTER ASSY. PAGE 38 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 39 HONDA GX340K1EDN2 ENGINE — RECOIL STARTER RECOIL STARTER ASSY. PART NO PART NAME QTY. REMARKS 28400ZE3W01ZB STARTER ASSY, RECOIL ....1 ..INCLUDES ITEMS W/ 28410ZE3W01ZB CASE COMP., RECOIL STARTER 28421ZE3W01 PULLEY, RECOIL STARTER 28422ZE2W01 RATCHET, STARTER 28441ZE2W01 SPRING, FRICTION 28442ZE2W01 SPRING, STARTER RETURN 28443ZE2W01...
  • Page 40 HONDA GX340K1EDN2 ENGINE — FAN COVER FAN COVER ASSY. PAGE 40 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 41 HONDA GX340K1EDN2 ENGINE — FAN COVER FAN COVER ASSY. PART NO PART NAME QTY. REMARKS 19610ZE3700ZB COVER COMP., FAN 19631ZE3W00 SHROUD 81329567020 GROMMET, DRAIN HOLE 90013883000 BOLT, FLANGE, 6X12 90654SA4003 CLIP GA-6HZR A.C. GENERATOR — OPERATION AND PARTS MANUAL — REV. #3 (03/30/11) — PAGE 41...
  • Page 42 HONDA GX340K1EDN2 ENGINE — CAMSHAFT/VALVES CAMSHAFT/VALVES ASSY. PAGE 42 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 43 HONDA GX340K1EDN2 ENGINE — CAMSHAFT/VALVES CAMSHAFT/VALVES ASSY. PART NO PART NAME QTY. REMARKS 14100ZE3010 CAMSHAFT ASSY....... 1 ..INCLUDES ITEMS/W 14410ZE3013 ROD, PUSH 14431ZE2000 ARM, VALVE ROCKER 14441ZE2000 LIFTER, VALVE 14451ZE1003 PIVOT, ROCKER ARM 14568ZE1000 SPRING, WEIGHT RETURN 14711ZE3000 VALVE, IN 14721ZE3000 VALVE, EX.
  • Page 44 HONDA GX340K1EDN2 ENGINE — PISTON/RINGS PISTON/RINGS ASSY. PAGE 44 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 45 HONDA GX340K1EDN2 ENGINE — PISTON/RINGS PISTON/RINGS ASSY. PART NO PART NAME QTY. REMARKS 13010ZE3003 RING SET, PISTON (STD) 13011ZE3003 RING SET, PISTON (0.25) 13012ZE3003 RING SET, PISTON (0.50) 13013ZE3003 RING SET, PISTON (0.75) 13101ZE3W00 PISTON (STD) 13102ZE3W00 PISTON (0.25) 13103ZE3W00 PISTON (0.50) 13104ZE3W00 PISTON (0.75)
  • Page 46 HONDA GX340K1EDN2 ENGINE — AIR CLEANER AIR CLEANER ASSY. PAGE 46 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 47 HONDA GX340K1EDN2 ENGINE — AIR CLEANER AIR CLEANER ASSY. PART NO PART NAME QTY. REMARKS 15721ZB4000 TUBE BREATHER 17211899000 ELEMENT, AIR CLEANER 17212ZB4003 SEPARATOR, AIR CLEANER 17220ZB4003 CASE COMP., AIR CLEANER 17222ZC2000 STAY, AIR CLEANER 17231899000 COVER COMP., AIR CLEANER 17235899000 CLIP A, AIR CLEANER WIRE 17236899000...
  • Page 48 HONDA GX340K1EDN2 ENGINE — CYLINDER BARREL CYLINDER BARREL ASSY. (RECOIL STARTER) PAGE 48 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 49 HONDA GX340K1EDN2 ENGINE — CYLINDER BARREL CYLINDER BARREL ASSY. (RECOIL STARTER) PART NO PART NAME QTY. REMARKS 12000ZE3816 BARREL ASSY., CYLINDER 15510ZE2043 SWITCH ASSY., OIL LEVEL 16541ZE3000 SHAFT, GOVERNOR ARM 90131883000 BOLT, DRAIN PLUG 90446KE1000 WASHER, 8.2X17X0.8 9410912000 WASHER, DRAIN PLUG 91201ZE3004 OIL SEAL 91203952771...
  • Page 50 HONDA GX340K1EDN2 ENGINE — CYLINDER BARREL CYLINDER BARREL ASSY. (ELECTRIC START) PAGE 50 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 51 HONDA GX340K1EDN2 ENGINE — CYLINDER BARREL CYLINDER BARREL ASSY. (ELECTRIC START) PART NO PART NAME QTY. REMARKS 12000ZE3826 BARREL ASSY., CYLINDER 15510ZE2043 SWITCH ASSY., OIL LEVEL 16541ZE3000 SHAFT, GOVERNOR ARM 90131883000 BOLT, DRAIN PLUG 90446KE1000 WASHER, 8.2X17X0.8 9410912000 WASHER, DRAIN PLUG 91201ZE300 OIL SEAL 91203952771...
  • Page 52 HONDA GX340K1EDN2 ENGINE — CRANKCASE COVER/GOVERNOR CRANKCASE COVER/GOVERNOR ASSY. PAGE 52 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 53 HONDA GX340K1EDN2 ENGINE — CRANKCASE COVER/GOVERNOR CRANKCASE COVER/GOVERNOR ASSY. PART NO PART NAME QTY. REMARKS 06165ZE3000 GOVERNOR KIT ........1 ..INCLUDES ITEM W/* 11300ZE3020 COVER ASSY., CRANKCASE ....1 ..INCLUDES ITEM W/+ 11381ZE3800 PACKING, CASE COVER 15600735700 CAP ASSY., OIL FILLER ......1 ..INCLUDES ITEM W/# 15621896010 PACKING, OIL FILLER CAP 15625ZE1000...
  • Page 54 HONDA GX340K1EDN2 ENGINE — FLYWHEEL/FAN ASSY. FLYWHEEL/FAN ASSY. PAGE 54 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 55 HONDA GX340K1EDN2 ENGINE — FLYWHEEL/FAN ASSY. FLYWHEEL/FAN ASSY. PART NO PART NAME QTY. REMARKS 19511ZE3000 FAN, COOLING 28451ZE3W01 PULLEY, STARTER 31100ZE3721 FLYWHEEL COMP. 90201ZE3790 NUT, SPECIAL, 16 MM 90741ZE2000 KEY, SPECIAL WOODRUFF GA-6HZR A.C. GENERATOR — OPERATION AND PARTS MANUAL — REV. #3 (03/30/11) — PAGE 55...
  • Page 56 HONDA GX340K1EDN2 ENGINE — COIL ASSY. COIL ASSY. PAGE 56 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 57 HONDA GX340K1EDN2 ENGINE — COIL ASSY. COIL ASSY. PART NO PART NAME QTY. REMARKS 30500ZE2013 COIL ASSY., IGNITION 30700ZE1013 CAP ASSY., NOISE SUPPRESSO 31510ZE1811 COIL ASSY., LAMP 12V/25W 31511ZE3000 CLAMP, WIRE 31512ZE2000 GROMMET, CORD 36101ZE3800 CORD, STOP SWITCH 36103ZE1000 HOLDER, STOP SWITCH CORD 90012888000 BOLT, FLANGE, 6X40 90013883000...
  • Page 58 HONDA GX340K1EDN2 ENGINE — CRANKSHAFT ASSY. CRANKSHAFT ASSY. PAGE 58 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 59 HONDA GX340K1EDN2 ENGINE — CRANKSHAFT ASSY. CRANKSHAFT ASSY. PART NO PART NAME QTY. REMARKS 13310ZE3701 CRANKSHAFT COMP...... 1 ..INCLUDES ITEMS W/ 13351ZE3010 WEIGHT, BALANCER 13352ZE3310 GEAR, BALANCER DRIVE 14311ZE3310 GEAR, TIMING 961006207000 BEARING, RADIAL BALL, 6207 GA-6HZR A.C. GENERATOR — OPERATION AND PARTS MANUAL — REV. #3 (03/30/11) — PAGE 59...
  • Page 60 HONDA GX340K1EDN2 ENGINE — GOVERNOR CONTROLS ASSY. GOVERNOR CONTROLS ASSY. PAGE 60 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 61 HONDA GX340K1EDN2 ENGINE — GOVERNOR CONTROLS ASSY. GOVERNOR CONTROLS ASSY. PART NO PART NAME QTY. REMARKS 16550ZE3700 ARM, GOVERNOR 16555ZE3000 ROD, GOVERNOR 16561ZE3000 SPRING, GOVERNOR 16562ZE3700 SPRING, THROTTLE RETURN 16570ZE3700 CONTROL ASSY......1 ..INCLUDES ITEMS W/ 16584883300 SPRING, CONTROL ADJUSTING 1 90013883000 BOLT, FLANGE, 6X12 90015ZE5010...
  • Page 62 HONDA GX340K1EDN2 ENGINE — CARBURETOR ASSY. CARBURETOR ASSY. PAGE 62 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 63 HONDA GX340K1EDN2 ENGINE — CARBURETOR ASSY. CARBURETOR ASSY. PART NO PART NAME QTY. REMARKS 16010ZE3701 GASKET SET 16011ZA0931 VALVE SET, FLOAT 16013ZA0931 FLOAT SET 16015ZA0931 CHAMBER SET, FLOAT 16016ZH7W01 SCREW SET 16024124761 SCREW SET, DRAIN 16028ZA0931 SCREW SET 16100ZE3F10 CARBURETOR ASSY...... 1 ... INCLUDES ITEMS W/ 16124ZE0005 SCREW, THROTTLE STOP 16148141881...
  • Page 64 HONDA GX340K1EDN2 ENGINE — SOLENOID ASSY. SOLENOID ASSY. PAGE 64 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 65 HONDA GX340K1EDN2 ENGINE — SOLENOID ASSY. SOLENOID ASSY. PART NO PART NAME QTY. REMARKS 16268893000 SPRING, CHOKE RETURN 17850ZD1E30 LEVER COMP., THROTTLE 36160ZB4003 SOLENOID ASSY. 93500050080A SCREW, PAN 90013883000 BOLT, FLANGE, 6X2 GA-6HZR A.C. GENERATOR — OPERATION AND PARTS MANUAL — REV. #3 (03/30/11) — PAGE 65...
  • Page 66 HONDA GX340K1EDN2 ENGINE — FUEL COCK ASSY. FUEL COCK ASSY. PAGE 66 — GA-6HZR A.C. GENERATOR— OPERATION AND MANUAL — REV. #3 (03/30/11)
  • Page 67 HONDA GX340K1EDN2 ENGINE — FUEL COCK ASSY. FUEL COCK ASSY. PART NO PART NAME QTY. REMARKS 16173001004 PACKING, FUEL STRAINER CUP 16950ZB4015 COCK ASSY., FUEL ......1 ..INCLUDES ITEMS W/ 16952ZB4005 SCREEN, FUEL STRAINER 16958397771 O-RING 16959471831 FILTER CUP 16967GA6671 CUP, FUEL STRAINER 90854ZB2000...
  • Page 68 Multiquip be $5.00. meeting this requirement. liable for loss of profit or good will or for any Special order items.
  • Page 69 NOTE PAGE GA-6HZR A.C. GENERATOR — OPERATION AND PARTS MANUAL — REV. #3 (03/30/11) — PAGE 69...
  • Page 70 © COPYRIGHT 2011, MULTIQUIP INC. Multiquip Inc and the MQ logo are registered trademarks of Multiquip Inc. and may not be used, reproduced, or altered without written permission. All other trademarks are the property of their respective owners and used with permission.
