Model No. NTEL21412.0
USER’'S MANUAL
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
QUESTIONS?
If you have questions, or if parts
are damaged or missing, DO NOT
CONTACT THE STORE; please
contact Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
CALL TOLL-FREE:
1-800-TO-BE-FIT
(1-800-862-3348)
Mon.––Fri. 6 a.m.––6 p.m. MT
Sat. 8 a.m.––4 p.m. MT
ON THE WEB:
www.nordictrackservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Advertisement
Table of Contents
Related Manuals for NordicTrack Elite 14.7 Elliptical
Summary of Contents for NordicTrack Elite 14.7 Elliptical
- Page 1 Model No. NTEL21412.0 USER’’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CONTACT THE STORE; please contact Customer Care.
-
Page 2: Table Of Contents
Apply the decal in the location shown. Note: The decal(s) may not be shown at actual size. NORDICTRACK is a registered trademark of ICON IP, Inc. -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your elliptical before using your elliptical. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product. -
Page 4: Before You Begin
NORDICTRACK ® ELITE 14.7 elliptical. The ELITE 14.7 manual. To help us assist you, note the product model elliptical provides an impressive selection of features number and serial number before contacting us. The... -
Page 5: Part Identification Chart
PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly. -
Page 6: Assembly
ASSEMBLY •• Assembly requires two persons. •• In addition to the included tool(s), assembly requires the following tools: •• Place all parts in a cleared area and remove the one Phillips screwdriver packing materials. Do not dispose of the packing materials until you complete all assembly steps. - Page 7 3. Remove the screws (not shown) and the ship- ping bracket (not shown) from the rear of the Frame (1). Discard the screws. With the help of a second person, place the ship- ping bracket (not shown) under the rear of the Frame (1).
- Page 8 6. Locate the wire tie in the Upright (4). Tie the lower end of the wire tie to the Main Wire (110). Wire Then, pull the upper end of the wire tie until the Main Wire is routed through the Upright. Tip: To prevent the Main Wire (110) from fall- ing into the Upright (4), secure the Main Wire with the wire tie.
- Page 9 8. Identify the Left and Right Inner Covers (55, 68) and orient them as shown. Slide the Left Inner Cover (55) onto the left side of the Upright (4). Then, slide the Right Inner Cover (68) onto the right side of the Upright. 9.
- Page 10 10. Tighten an M8 x 16mm Screw (120) and an M8 x 25mm Washer (98) into each end of the Pivot Axle (35) at the same time. 11. Identify the Right Pedal (49) and the Right Pedal Arm (58), and orient them as shown. Attach the Right Pedal (49) to the Right Pedal Bracket (139) on the Right Pedal Arm (58) with five M6 x 12mm Screws (121).
- Page 11 12. Orient the Left Pedal Arm (44) as shown. Apply grease to the axle on the Left Pedal Arm (44). Attach the Left Pedal Arm (44) to the Left Roller Arm (12) with an M8 x 16mm Screw (120), a Roller Arm Cover (81), and an M8 x 25mm Grease Washer (98).
- Page 12 14. Slide the Right Upper Body Leg (36) onto the Right Upper Body Arm (61). Attach the Right Upper Body Leg (36) with two M8 x 35mm Bolts (96) and two M8 Locknuts (102). Make sure that the Locknuts are in the hexagonal holes.
- Page 13 16. Untie and discard the wire tie on the Main Wire (110). While a second person holds the Console (7) near the Upright (4), connect the wires on the Console to the Main Wire (110), to the Right and Left Grip Wires (41, 48), to the sensor wire (A), and to the Ground Wire (143).
- Page 14 18. Attach the Rear Upright Cover (80) to the Upright (4) with four #8 x 3/4" Screws (123). 19. Press the Front Upright Cover (91) onto the Rear Upright Cover (80). Attach the Front Upright Cover (91) to the Upright (4) with a #8 x 3/4" Screw (123). 20.
-
Page 15: The Chest Heart Rate Monitor
THE CHEST HEART RATE MONITOR HOW TO PUT ON THE HEART RATE MONITOR •• Do not expose the heart rate monitor to direct sun- light for extended periods of time; do not expose it to The heart rate temperatures above 122° F (50° C) or below 14° F monitor consists of (-10°... -
Page 16: How To Use The Elliptical
HOW TO USE THE ELLIPTICAL HOW TO PLUG IN THE POWER CORD A temporary adapter may 2-pole Receptacle This product must be grounded. If it should malfunc- be used to tion or break down, grounding provides a path of least connect the Adapter resistance for electric current to reduce the risk of... - Page 17 HOW TO MOVE THE ELLIPTICAL HOW TO EXERCISE ON THE ELLIPTICAL Due to the size and weight of the elliptical, moving To mount the elliptical, hold the upper body arms or it requires two persons. Stand in front of the elliptical, the handlebars and step onto the pedal that is in the hold the upright, and place one foot against one of the lower position.
- Page 18 CONSOLE DIAGRAM FEATURES OF THE CONSOLE When you use the manual mode of the console, you can change the resistance of the pedals and the incline The advanced console offers an array of features of the ramp with the touch of a button. designed to make your workouts more effective and enjoyable.
- Page 19 HOW TO TURN ON THE POWER HOW TO USE THE TOUCH SCREEN IMPORTANT: If the elliptical has been exposed to The console features a tablet with a full-color touch cold temperatures, allow it to warm to room tem- screen. The following information will help you become perature before turning on the power.
- Page 20 HOW TO SET UP THE CONSOLE The Internet browser will open to the iFit.com home page. Touch the Register button in the upper right Before using the elliptical for the first time, set up the corner of the screen. console. The browser will open to the iFit.com registration 1.
- Page 21 HOW TO USE THE MANUAL MODE on the console, press the Power Ramp increase and decrease buttons on the console, or press the 1. Touch the screen or press any button on the Ramp increase and decrease buttons on the left console to turn on the console.
- Page 22 5. Measure your heart rate if desired. Be careful not to move your hands excessively or to squeeze the contacts tightly. For optimal perfor- To use the chest heart rate monitor, see page mance, clean the contacts using a soft cloth; never 15.
- Page 23 HOW TO USE AN ONBOARD WORKOUT If the resistance level and/or incline level for the current segment is too high or too low, you can 1. Begin pedaling or press any button on the manually override the setting by pressing the console to turn on the console.
- Page 24 HOW TO USE A SET-A-GOAL WORKOUT IMPORTANT: The target rpm is intended only to provide motivation. Your actual pedaling speed 1. Begin pedaling or press any button on the may be slower than the target rpm. Make sure console to turn on the console. to pedal at a speed that is comfortable for you.
- Page 25 HOW TO USE AN IFIT WORKOUT For more information about the iFit workouts, please see www.iFit.com. Note: To use an iFit workout, you must have access to a wireless network (see HOW TO USE THE When you select an iFit workout, the screen will WIRELESS NETWORK MODE on page 28.
- Page 26 HOW TO USE THE EQUIPMENT SETTINGS MODE passcode of your choice. Touch Save to use this passcode. Touch Cancel to return to the equipment 1. Select the settings main menu. settings mode and not use a passcode. To disable the passcode, touch the Disable checkbox. Turn on the console and select the main menu (see steps 1 and 2 on page 21).
- Page 27 HOW TO USE THE MAINTENANCE MODE incline level, lower to the minimum incline level, and then return to the starting position. This will 1. Select the settings main menu. calibrate the incline. Press the Cancel button to return to the maintenance mode. When the incline See step 1 on page 26.
- Page 28 HOW TO USE THE WIRELESS NETWORK MODE name (SSID). If your network has a password, you will also need to know the password. The console features a wireless network mode that allows you to set up a wireless network connection. An information box will ask if you want to connect to the wireless network.
- Page 29 HOW TO USE THE SOUND SYSTEM HOW TO USE THE INTERNET BROWSER To play music or audio books through the console Note: To use the Internet browser, you must have sound system, you must connect your MP3 player, CD access to a wireless network including a wireless player, or other personal audio player to the console.
-
Page 30: Fcc Information
FCC INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15C of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 31: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the elliptical regularly. To adjust the drive Replace any worn parts immediately. belt, first use a flat screwdriver to remove To clean the elliptical, use a damp cloth and a small the Lower Upright amount of mild soap. - Page 32 Loosen the M6 x HOW TO ADJUST THE REED SWITCH 12mm Hex Screw (85) and the M10 x 58mm If the console does not display correct feedback, the Hex Bolt (86). Then, reed switch should be adjusted. remove the right Crank Arm (20).
-
Page 33: Exercise Guidelines
EXERCISE GUIDELINES Burning Fat——To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy. -
Page 34: Part List
PART LIST Model No. NTEL21412.0 R1012A Key No. Qty. Description Key No. Qty. Description Frame Roller Rear Stabilizer Cover Fan Grill Ramp Axle Cover Upright Left Outer Cover Rear Stabilizer Left Inner Cover Front Stabilizer Lower Upright Cover Console Roller Arm Bushing Front Stabilizer Cover Right Pedal Arm Bottom Ramp Cover... - Page 35 Key No. Qty. Description Key No. Qty. Description Idler Screw M4 x 16mm Machine Screw M8 Locknut M8 x 23mm Washer Pedal Pin Heart Rate Monitor M4 x 16mm Screw Chest Strap M8 x 16mm Hex Screw 1" Grommet M4 x 13mm Screw Crank Arm Bushing Standoff Ramp Shield...
-
Page 36: Exploded Drawing
EXPLODED DRAWING A Model No. NTEL21412.0 R1012A... - Page 37 EXPLODED DRAWING B Model No. NTEL21412.0 R1012A...
- Page 38 EXPLODED DRAWING C Model No. NTEL21412.0 R1012A...
- Page 39 EXPLODED DRAWING D Model No. NTEL21412.0 R1012A...
-
Page 40: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: •• the model number and serial number of the product (see the front cover of this manual) ••...
