Model No. IMSW20701
IMSG20701
IMSB20701
Serial No.
The serial number can be found in the
location shown below. Write the serial
number in the space above.
Serial Number Decal
(on the frame behind the access cover)
QUESTIONS?
PLEASE CALL DIRECT TO OUR
TOLL-FREE CUSTOMER HOT
LINE. The trained technicians
on our customer hot line will
provide immediate assistance,
free of charge to you.
CUSTOMER HOT LINE:
1-877-897-7493
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before
using this equipment. Save this
manual for future reference.
USER'S MANUAL
Visit our website at
www.workoutwarehouse.com
new products, prizes,
fitness tips, and much more!
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IMSG20701, IMSW20701, IMSB20701 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Image IMSG20701, IMSW20701, IMSB20701

Summary of Contents for Image IMSG20701, IMSW20701, IMSB20701

  • Page 1 Model No. IMSW20701 IMSG20701 IMSB20701 Serial No. The serial number can be found in the location shown below. Write the serial number in the space above. Serial Number Decal (on the frame behind the access cover) QUESTIONS? PLEASE CALL DIRECT TO OUR TOLL-FREE CUSTOMER HOT LINE.

  • Page 2: Table Of Contents

    LIMITED HYDROTHERAPY SPA WARRANTY .........Back Cover IMAGE ®...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS WARNING: TO REDUCE THE RISK OF DROWNING, ELECTRIC SHOCK, OR SERIOUS INJURY, READ THE FOLLOWING IMPORTANT PRECAUTIONS BEFORE USING THE RENEW 207. READ AND FOLLOW ALL INSTRUCTIONS 1. It is the responsibility of the owner to ensure that all users of the RENEW 207 are adequately informed of all precautions.
  • Page 4 20. Do not use an extension cord with the RENEW 207; this could damage the motor and will void the warranty. 21. DANGER—If you will be using the RENEW 207 outside, do not bury the power cord. Keep the power cord away from lawn mow- ers, hedge trimmers, and other similar equip- ment.

  • Page 5: Save These Instructions

    39. The included warning sign must be posted where all users of the IMAGE 207 can see and read it (see POSTING THE WARNING SIGN on page 10).

  • Page 6: Before You Begin

    BEFORE YOU BEGIN Congratulations for selecting the new IMAGE RENEW 207 massage spa. The RENEW 207 offers the features and quality of a traditional hot tub at an affordable price, providing the benefits of hydrotherapy in the comfort and privacy of your home.

  • Page 7: Choosing A Location For The Renew 207

    CHOOSING A LOCATION FOR THE RENEW 207 There are many factors to consider when choosing a location to set up the RENEW 207. These factors vary depending on whether you plan to use the spa inside or outside. We have listed several factors you may wish to consider as you decide where you want to set up the spa.

  • Page 8: Setup And Assembly

    SETUP AND ASSEMBLY Before beginning assembly, carefully read the following information and instructions: • Place all parts of the spa in a cleared area and remove the packing materials from the spa shell; do not dispose of the packing materials until assembly is completed.
  • Page 9 4. Attach the nozzle of the included air pump to the valve on the Insulating Liner (4). Fill the Insulating Liner with air. Be careful not to overfill the Insulating Liner. Lay the Spa Cover (11) on the floor as shown. Set the Insulating Liner (4) inside the Spa Cover.

  • Page 10: Posting The Warning Sign

    POSTING THE WARNING SIGN The included warning sign, shown below, must be posted on a wall or fence where it will be visible to all users of the RENEW 207. If the spa is moved, the sign must also be moved and reposted near the spa. If the sign becomes lost or illegible, call our toll-free Customer Hot Line at 1-877-897-7493 to obtain a free replacement sign.
  • Page 11 TESTING AND TREATING THE WATER For water maintenance, the hydrotherapy spa comes with a starter chemical pack for maintaining the water in the spa. Additional chemicals can be purchased at a pool and spa supply store. Always keep the chem- icals away from children and pets.
  • Page 12 SECURING THE SPA COVER To secure the spa cover, snap the latches on the spa cover into the buckles on the side of the spa. To lock the buckles, insert the key and turn it clockwise 1/4 Latch turn. To unlock the buckles, insert the key and turn it coun- terclockwise 1/4 turn.

  • Page 13: Maintenance

    MAINTENANCE The RENEW 207 is designed to provide years of enjoyment. Follow the guidelines below to properly maintain the spa. MAINTENANCE SCHEDULE DAILY • Check the water level. If necessary, refill the spa to the level shown in step 3 on page 8. •...
  • Page 14 WATER CHEMISTRY The hydrotherapy spa comes with a starter chemical pack for maintaining the water in the spa. (See TEST- ING AND TREATING THE WATER on page 11.) Additional chemicals can be purchased at a pool and spa supply store. CAUTION: The chemicals used to maintain the pH balance of the water and to sanitize the water can be dangerous.
  • Page 15 To drain the RENEW 207, follow these steps: 1. Set the temperature control on the console to the lowest setting. 2. Unplug the power cord. 3. Remove the access cover from the spa. 4. Remove the drainage hose from the clip and attach a garden hose to the valve on the drainage hose.

  • Page 16: Trouble-Shooting

    TROUBLE - SHOOTING Most problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, call our Customer Service Department toll-free at 1-877-897-7493, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time. 1.
  • Page 17 8. SYMPTOM: THE WATER PULSATES OR THERE IS MINIMUM WATER FLOW a. This usually occurs only when the water level is low. Add water to the level shown in step 3 on page 8. b. The filter may be dirty. Check the filter and clean it if necessary.

  • Page 18: Part List

    PART LIST Model No. IMSW20701, IMSG20701, IMSB20701 Key No. Qty. Description Buckle Screw Buckle 1/4” x 1.25” Bolt Lock Washer Heater Wire Harness Temperature/Hi Limit Probe Assembly Console Overlay Pressure Switch Control Box Removable Collar Pump Motor Insulating Liner Spa Cover Drowning Warning Decal Flat Washer Sun Warning Decal...

  • Page 19: Exploded Drawing

    EXPLODED DRAWING Model No. IMSW20701, IMSG20701, IMSB20701 R0401A 34 33...

  • Page 20: Ordering Replacement Parts

    • The MODEL NUMBER of the product (IMSW20701, IMSB20701, IMSG20701) • The NAME of the product (IMAGE • The SERIAL NUMBER of the product (see the front cover of this manual) • The KEY NUMBER and DESCRIPTION of the desired part(s) (see the PART LIST on page 18).
